Channels Mode - ColorKey Mover Wash HEX 12 User Manual

9 Channels Mode

Channel
1
2
3
4
5
6
7
8
9
15 Channels Mode
CH
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
Value Function
0-255 Pan motor adjustment
0-255 Tilt motor adjustment
0-199 Dimmer from dark to bright
200-250 Strobe from slow to fast
251-255 All bright
0-255 Red
0-255 Green
0-255 Blue
0-255 White
0-255 Amber
0-255 UV
Value Function
0-255 Pan motor adjustment
0-255 Fine pan motor adjustment
0-255 Tilt motor adjustment
0-255 Fine tilt motor adjustment
0-255 Pan & Tilt speed
0-255 Dimmer from dark to bright (Ch 14 Must be Open)
0-255 Red
0-255 Green
0-255 Blue
0-255 Amber
0-255 White
0-255 UV
008-255 Auto color programs
008-131 Strobe from slow to fast
132-139 Open
140-181 Strobe effect 1
182-189 Open
190-231 Strobe effect 2
232-239 Open
240-247 Random flashes
248-255 Open
128-255 Sound active (001-127 No function)
