Summary of Contents for Caple C950i

  • Page 2: Table Of Contents

    SUMMARY SUMMARY ..........................2 DESCRIPTION OF THE APPLIANCE ..................3 ................. 3 PPLIANCES AND INSTALLATION DIMENSIONS INSTALLATION OF THE MULTIZONES ..................4 ..........................4 NSTALLATION ..........................4 ENTILATION ....................... 5 NSTALLATION INSTRUCTIONS CONNECTING THE DIFFERENT ELEMENTS ................6 ....................6 ONNECTING THE COOKING ZONES CONFIGURATION PROCEDURE ....................

  • Page 3: Description Of The Appliance

    NOTE: The C950I is a four-zone induction hob. It is not possible to install less than four zones, all cooking zones must be connected and installed for this product to function correctly.

  • Page 4: Installation Of The Multizones

    INSTALLATION OF THE MULTIZONES Installation Unpack all the components. • The installation and connection of the appliance must be done by approved specialists. • The manufacturer cannot be held responsible for damage caused by the installation or any connection errors. The appliance must be installed into a kitchen unit and an adapted and approved work •...

  • Page 5: Installation Instructions

    • NOTE: Please refer to the worktop manufacturer for the minimum spacing required be- tween each zone cut out to maintain the required supporting strength. • If any of the above is unclear, please contact Caple Service for advice on the installaiton before begining the proceedure.

  • Page 6: Connecting The Different Elements

    CONNECTING THE DIFFERENT ELEMENTS The installation of this appliance and the connection to the electrical network should be made by an electrician perfectly aware, and in respect of the normative regulations Connecting the cooking zones Each connector of the cooking zones, is located by a sticker with the classification from 5 to 8 corresponds to: •...

  • Page 7: Configuration Procedure

    CONFIGURATION PROCEDURE The table must be configured. Please implement the following steps: Important! Before you start, make sure there are no pots or pans on the hob Procedure: * Use an induction compatible pan with a minimum diameter of 16 cm * Start the procedure within 2 minutes after reconnecting the hob to the electrical supply * Don’t switch the hob one using the [ ] button.

  • Page 8: What To Do In Case Of A Problem

    WHAT TO DO IN CASE OF A PROBLEM The symbol [ E4] appears: • Reconfigure the hob, starting from the beginning. If the symbol persists, contact Caple Service. T - 0117 938 7420 E - service@caple.co.uk.

  • Page 9: Electrical Connection

    ELECTRICAL CONNECTION • The installation of this appliance and the connection to the electrical network should be en- trusted only to an electrician who will comply to the normative regulations and who re- spects them scrupulously. • Protection against parts under tension must be ensured after the installation. •...
  • Page 12 Caple Service Fourth Way Avonmouth Bristol BS11 8DW t: 0117 938 7420 e: service@caple.co.uk www.caple.co.uk 19565-5 Please keep this instruction manual for future reference...
