Page 1: Instruction Manual
Gas on glass hob instruction manual C786G / C787G / C789G Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk... -
Page 2: Table Of Contents
Parts of the appliance How to use your appliance Care and maintenance Practical advice Troubleshooting Installation instructions Gas connection Replacement burner injector Valve adjustment Flame selection Caple contact details Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 3: Warnings
- This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 4: Installation Warnings
- Ensure that the gas and electrical supply complies with the type stated on the rating label - Do not attempt to modify the hob in any way. Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 5: Important Safety Instructions
- Do not stand on your hob. - Do not use scourers or any other harsh abrasive cleaning agents to clean your hob, as these can scratch glass. Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... - Page 6 Keep handles out of reach of children. - Failure to follow this advice could result in burns and scalds. Please keep this instruction manual for future reference Instruction manual C786G C787G C789G...
-
Page 7: Environmental Protection
CE DECLARATIONS OF CONFORMITY This appliance has been manufactured to the strictest standards and complies with all applicable legislation, Low Voltage Directive (LVD) and Electromagnetic Compatibility (EMC). Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 8: Parts Of The Appliance
4. Triple ring burner 5. Ignitor 6. Safety Device - Activates if the flame accidentally goes out (spills, drafts, etc.), interrupting the deliveryof gas to the burner. 7. Control Knobs Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 9: How To Use Your Appliance
High setting, keeping it pressed in until the burner lights. As a safety device is fitted, the knob must be pressed in for about 6 seconds, until the device that keeps the flame lighted warms up. Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 10: Care And Maintenance
Over time, the gas valves may stick or become difficult to turn. If this is the case, they must be cleaned on the inside and the re-greased. NOTE: This procedure must be performed by a Caple approved engineer or similar qualified persons Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 11: Practical Advice
Triple Ring 24 - 26 Rapid 24 - 26 To identify the type of burner, refer to the diagram in the section entitled, ‘Parts of the appliance’. Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 12: Troubleshooting
TROUBLESHOOTING It may occur that the hob does not function or does not function properly. Before calling Caple service for assistance, lets see what can be done. First of all, check to see that there are no interruptions in the gas and electrical supplies, and, in particular, that the gas valves for the mains are open. -
Page 13: Installation Instructions
- The room must be fitted with a ventilation system which vents smoke and gases from combustion to the outside. This must be done by means of a hood or electric ventilator that turns on automatically each time the hood is operated. Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 14: Gas Hob Installation
Fig. 6).To obtain a of the hob plate it is advisable to use all the fixing supplied. Fig.6 Please keep this instruction manual for future reference Instruction manual C786G C787G C789G Hook position for Hook position for Hook position for... - Page 15 This panel must be placed at least 20 mm from the bottom of the hob itself. When installing above a built-in oven without forced ventilation, ensure that there are air inlets and outlets for ventilating the interior of the cabinet adequately. Please keep this instruction manual for future reference Instruction manual C786G C787G C789G...
-
Page 16: Gas Connection
2000 mm. Once the connection has been made, ensure that the flex oes not touch any moving parts and is not crushed. Please keep this instruction manual for future reference Installation Instruction manual C786G C787G C789G ppliance has been installed, make sure all the connections are properly sealed, using liq... - Page 17 - That the plug or switch are easily accessible. Important: The wires in the mains lead are coloured in accordance with the following code: Earth Green & Yellow Blue Neutral Live Brown Please keep this instruction manual for future reference Instruction manual C786G C787G C789G...
- Page 18 30.98 MJ/m³ 1.05* Triple Ring 0.68* 0.68* P.C.I.G2.350 27.20MJ/ m³ P.C.I.G30 49.47MJ/Kg 2/0.6 (C787G & 2/0.45 2/0.45 C789G) Triple Ring 1.0*2 0.68* 0.68* /0.68 2/0.45 2/0.45 (C786G) Please keep this instruction manual for future reference Instruction manual C786G C787G C789G...
-
Page 19: Adapting To Different Types Of Gas
0.64*2/0.4 — 3096 1634 Natural 1.05*2/0.6 — 3612 1634 Triple-ring Natural — 3440 1634 （4.2kW） G25.3 0.68*2/0.4 (C787G & — 3612 1634 C789G) 0.68*2/0.4 — 3612 1634 Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 20: Replacement Burner Injector
Please keep this instruction manual for future reference injector, readjust the valves. Note. Instruction manual C786G C787G C789G It is up to the user to request converting the appliance to another gas type if so required by the local conditions at a licensed gas fitter/ service. -
Page 21: Valve Adjustment
It is up to the user to request converting the appliance to another gas type if so required censed gas fitter/ service. licensed gas fitter/ service. Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... -
Page 22: Flame Selection
It is a prerequisite for efficient and energy-saving operation of the hob that the burners are kept clean at all times (in particular the flame slots and injectors). Please keep this instruction manual for future reference Instruction manual C786G C787G C789G... - Page 23 Please keep this instruction manual for future reference Instruction manual C786G C787G C789G...
-
Page 24: Caple Contact Details
Caple Service Fourth Way Avonmouth Bristol BS11 8DW t: 0117 938 7420 e: service@caple.co.uk www.caple.co.uk Version 1 Please keep this instruction manual for future reference Instruction manual C786G C787G C789G...
