Aseptico AEU-14CF Operation, Service Manual & Parts List

Emergency field dental unit
Hide thumbs Also See for AEU-14CF:
Table of Contents

Advertisement

Quick Links

Download this manual
AEU-14CF
Emergency Field Dental Unit
xpedition
SERVICE MANUAL
& PARTS LIST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEU-14CF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aseptico AEU-14CF

Summary of Contents for Aseptico AEU-14CF

  • Page 1 AEU-14CF Emergency Field Dental Unit xpedition SERVICE MANUAL & PARTS LIST...

  • Page 2: Table Of Contents

    Battery Pack Board (Fig. 10) ..... . .10 P.O. Box 1548 • Woodinville, WA 98072-1548 (800) 426-5913 • (425) 487-3157 • Fax: 425-487-2608 www.aseptico.com • info@aseptico.com Page 2 Printed In The USA...

  • Page 3: General Service Information

    If bulb is okay, then work Plumbing parts are called out by Aseptico part number in the your way back through the connectors. If water fails to come assembly drawings.

  • Page 4: Cleaning & Lubrication

    Cleaning and Lubrication ESD PRECAUTIONS When servicing the AEU-14CF Emergency Field Dental The following electrostatic controls must be used when Unit, the parts of any component disassembled should be working on this unit: thoroughly cleaned and inspected before reassembly. A hot...

  • Page 5: Chassis Removal

    DISASSEMBLY NOTE: This system consists of two main assemblies: the THREE-WAY SOLENOID - Fig. 2 chassis assembly and the battery packs. All operating Remove pump cover as previously described (refer to “Power functions of the system are encased in the chassis and can be Supply”...

  • Page 6: Battery Receptacle (Fig. 3)

    DISASSEMBLY - Continued MOTOR RECEPTACLE - Fig. 3 BATTERY RECEPTACLE - Fig. 3 Remove the pump cover as previously described under Remove the pump cover as previously described under “Power Supply” disassembly procedure. Remove the nuts “Power Supply” disassembly procedure. Remove the screws holding the pump to gain access to the ground stud.

  • Page 7: Power Board (Fig. 4)

    POWER BOARD - Fig. 4 Remove the pump cover as previously described under power board. Remove the ribbon cable at the power board. “Power Supply” disassembly procedure. Remove the two NOTE: The cable connector has been sealed at the factory screws that hold the power cord receptacle and pull the with RTV - remove the RTV from cable.

  • Page 8: Display Board (Fig. 5)

    DISPLAY BOARD - Fig. 5 Remove the pump cover as previously described under board and ensure that the cable is oriented and seated “Power Supply” disassembly procedure. Remove all the properly in the connector. The socket requires that both sides components to the power board as previously described of the connector be pushed closed at the same time.

  • Page 9: Overlay

    WATER RESERVOIR CAP - Fig. 6 OVERLAY Remove the pump cover as previously described under The chassis does not have to be removed to replace the “Power Supply” disassembly procedure. Disconnect the overlay. Peel a corner of the overlay away from the chassis pressure gauge tubing at the 4-way connector.

  • Page 10: Battery Pack Disassembly

    DISASSEMBLY - Continued BATTERY PACK DISASSEMBLY • SOLAR PANEL RECEPTACLE - Fig.9 • BATTERY PACK - Fig. 8 Remove top cover as previously described under “Battery Remove the four thumbscrews from the hold-down Receptacle” disassembly procedure. Remove battery pack brackets. Remove the hold-down brackets from the battery connector from the battery pack board.
  • Page 11 Linecord Remote US 10Ft Gry 840001 Motor/Cable Assy w/Light & Water AE-200-30 Bottle, 16oz. Pet 730427 HPCE 1:1 Strt Low Speed Doriot AHP-101 Manual, AEU-14CF Operation 420382 HPCE 1:5 Contra Increaser w/Fiberoptics w/water AHP-72MBFO-XL Manual, AEU-14CF Service 420417 Syringe, 3-Way Air Water TA-90D...
  • Page 12 Spacer, Nyl 1/4Rndx.210Lx.14ID 510022 Fuse, 5 Amp 250V 830110 Insulator, AEU-14 Power Board 461199 Fuse, 12 Amp 250V 830084 Shield, Power Board AEU-14CF 461357 Power Supply, 48VDC 2.3A Medica Grade 730525 Bottle, 16oz. Pet 730427 Fuse Block, 12 Pole 830064 0.167...
  • Page 13 Motor Brkt Mount 9/16x1/2 730413 C/S SocHd Stnls 4-40 x 5/8 510610 C/S Btnsoc Stnls 8-32 x 3/8 510404 Bracket Heat Sink Clamping AEU-14CF 461650 C/S BtnSoc Blk 4-40 X 3/8 510031 Washer, Int Star S/S #8 510420 Standoff Nylon 4-40 X 1/2 L X 1/4 Hex...
  • Page 14 Fan, 12 VDC 70mA 8.0 CFM 540010 Filter 10-32 Thread Stainless 730326 Conn Recpt Wall-Mntg 8Pin 860165 Ftn Barb 10-32 x 1/8 Brt/Nkl 730073 Brkt AEU-14CF Cap Cmpl 461179-08 Washer, Flat Stnls #4 510192 C/S BtnSoc Stnls 8-32 x 3/8 510404 Holder AEU-14 Filter 461180...
  • Page 15 (Not Shown) Foot, Case AEU-14 461290 Hold-Down Bracket 461459-08 M/S Stnls PhdPhl 6-32x3/8 Self Sealing 510561 (Not Shown) Label AEU-14CF Repackaging 420460 Battery Pack Assy AEU-14 330365 Chassis AEU-14 Cage Battr Cmpl 461175-08 M/S PnHd Ph SS 6-32 x 1/4 Sealing...
  • Page 16 Chassis AEU-14 Batry Base Cmpl 461195-08 Tubing Silicone .281IDx.375OD 70 Duro Gray 730489 Conn Recpt Wall-Mntg 8Pin 860165 Battery Pack AEU-14CF 27.6V 2600mA-h Ni-CD 820042 Pad, AEU-14CF Battery Heatsink 461334 Nut, Nyloc 4-40 Stnls Hex 510394 PCB Assy AEU-14 Temperature...

  • Page 17: Troubleshooting Guide

    TROUBLESHOOTING GUIDE PROBLEM CORRECTION Chassis does not light when turned on: Check chassis to power connection. Check that voltage is proper voltage. Check fuse. If blown, replace with 1.25A/250V slo-blo fuse for 120V operation, & 0.6A/250V slo-blo fuse for 230V operation. Chassis lights when turned on, but handpiece does not turn: Check motor plug connection.

  • Page 18: Specifications

    SPECIFICATIONS SYMBOL DEFINITIONS: Size: ......17.5” x 11.6” x 6.9” (44.5 cm x 29.5 cm x Type B Equipment 17.5 cm) Volume: .

  • Page 19: Warranty

    Aseptico does not assume, under this warranty, any risks or liabilities arising from the clinical use of its products, whether or not such use involves coincidental utilization of products manufactured by others.
  • Page 20 For Further Service And/Or Technical Assistance Contact: P.O. Box 1548 • Woodinville, WA 98072-1548 (800) 426-5913 • (425) 487-3157 • Fax: 425-487-2608 www.aseptico.com • info@aseptico.com P/N: 420417 Rev. G ECO 13123 06/2013 PRINTED IN THE USA...
