Aseptico 1070 Series Quick Reference Manual

AEU-1070-70V • Quick Reference Guide
HOME SCREEN
The home screen displays the name of the active preset
current settings for each of the adjustable parameters
PRESET — This segment of the screen displays the active
preset name. Press here
Below is a table of the factory settings for each preset.
PRESET DIRECTION
PRST-1 FORWARD
PRST-2 FORWARD
PRST-3 FORWARD
PRST-4 FORWARD
PRST-5 REVERSE
PRST-6 FORWARD
PRST-7 FORWARD
PRST-8 FORWARD
MOTOR DIRECTION — This segment of the screen displays
the current motor rotation direction. Press here
between forward (F) and reverse (R).
SPEED / RATIO — This segment of the screen displays both
the current speed and ratio settings. The ratio setting (20:1
or 1:1) is indicated by the format (whole number or scientific
notation, respectively) in which the speed setting is displayed:
RATIO INDICATOR: The speed setting is displayed

as a whole number (e.g. 2000) to indicate when the
20:1 ratio is currently selected. The speed setting is
displayed in scientific notation (e.g. 40E3) to indicate
when the 1:1 ratio is currently selected. Replace "E3"
with "000" to calculate the speed of a 1:1 handpiece
(e.g. 40E3 = 40,000 RPM).
Press here to open the speed/ratio adjustment screen:
• SPEED SETTING: Press the  and  buttons to adjust the
speed setting in the following ranges, according to the
current ratio setting:
RATIO SETTING SPEED RANGE
20:1
1:1 1,000–40,000
! SEE USER MANUAL FOR COMPLETE INFORMATION !
to select presets sequentially.
SPEED RATIO TORQUE
1200 20:1 50
800 20:1 50
15 20:1 35
15 20:1 50
25 20:1 50
20 20:1 30
21 20:1 40
22 20:1 50
to alternate
SPEED DISPLAYED
15–2,000 15–2000
1E3–40E3
• RATIO SETTING: Press the number (1 or 20) that appears
between the  and  buttons to select the ratio setting:
and the
:
Press anywhere on the right side of the screen to return to the
home screen.
TORQUE — This segment of the screen displays the current
torque setting. Press here
screen, then press the  and  buttons to adjust the torque
setting in the following ranges, according to the current ratio
setting:
Press anywhere on the right side of the screen to return to the
home screen.

The speed and ratio settings determine whether the system
WATER
70
70
0
A torque warning tone will beep when the handpiece
0
torque reaches 75% of the torque setting. The handpiece
0
will slow down when a load greater than the torque setting
0
is reached. The handpiece will resume speed once the load
0
is removed.
0
A torque warning tone will beep when the handpiece
torque reaches 75% of the torque setting. The handpiece
will stop one second after the handpiece reaches the torque
setting. The handpiece will resume operation once the
footpedal is released and reapplied.

WATER — This segment of the screen displays the current
irrigation flow setting. Press here
adjustment screen, then press the  and  buttons to adjust
the flow setting (0–100%). A setting of 0% turns irrigation off.
Press anywhere on the right side of the screen to return to the
home screen.
1
RATIO SETTING NUMBER DISPLAYED
20:1
1:1
to open the torque adjustment
RATIO SETTING TORQUE RANGE
20:1
1:1
is in "Torque-Limit" mode or "Torque Auto-Stop" mode.
See the table below for details.
TORQUE-LIMIT MODE
When speed setting is ≥500 RPM @ 20:1 ratio
When speed setting is ≥10,000 RPM @ 1:1 ratio
TORQUE AUTO-STOP MODE
When speed setting is <500 RPM @ 20:1 ratio
When speed setting is <10,000 RPM @ 1:1 ratio
Pressing the Torque screen segment
Factory Restore, Handpiece Selection and Calibration screens, as
described in the sections below.
