- Page 1 AEU-14CF Emergency Field Dental Unit Expedition OPERATION MANUAL...
-
Page 2: Table Of Contents
TABLE OF CONTENTS: SPECIFICATIONS: Case Dimensions: 17.5 in x 11.6 in x 7.0 in Introduction ......1 (44.5 cm x 29.5 cm x Package Contents . -
Page 3: Introduction
Your new Aseptico Expedition Emergency Field Dental Unit is the most compact, full- featured portable electric dental system available. The AEU-14CF Expedition features an “E” type autoclavable 30,000 RPM brushless micromotor, a 3-way air/water syringe, a self contained water system, and oil-less air compressor. The light weight dual voltage system comes in a sturdy case for maximum portability. -
Page 4: Safety Precautions
WARNING: For use by qualified and trained dental professionals only. WARNING: Do not install where there is a risk of an explosion. The AEU-14CF is not intended for operation in the presence of flammable anesthetics or gases CAUTION: Use clean water only in water supply bottle. -
Page 5: Setting Up The Unit
MOTOR / HANDPIECE ALIGNMENT draw power from the highest source. It is not advised to operate off all sources at one time. The AEU-14CF Expedition circuitry allows the unit to operate while using an AC power source that is either 120V or 230V, and either 50Hz or 60 Hz. - Page 6 Motor FIG. 2 - Setup 3-Way Air/Water Syringe Motor Connector Water Supply Battery Pack Cable Battery Pack 1 Battery Pack 2 Foot Control AC Power Receptacle Motor Receptacle Vehicle Battery Cable In Battery Pack In Foot Switch Receptacle FIG. 3 -Chassis Inputs...
-
Page 7: Operation Functions
OPERATION FUNCTIONS - REFER TO FIGURE 4 Each push of up/down button will 1. Power On/Off Switch – Controls power increase/decrease speed by 325 RPM. on/off to chassis from 120V/230V AC The LED speed display indicates relative source. NOTE: If both AC and DC power speed from 500 RPM minimum to 3750 are supplied, power will be drawn from the RPM maximum. - Page 8 intensity setting is retained in memory until 10. Pump – When LED is on, power is applied to readjusted/changed. When the dental the pump to allow for air and water pressure. motor/handpiece is activated, either manually When LED is off, power is disengaged from or via the foot switch, the handpiece light will the pump to allow for water bottle removal automatically turn on at the previously used...
-
Page 9: Operation
OPERATION: REFER TO FIGURES 5 & 6 After the unit has been set up and you have made yourself familiar with the operation functions, you are ready for operation as follows: 1. Attach a sterile handpiece to the motor. 4. When Manual LED is on, dental motor will begin operation. -
Page 10: Battery Pack Removal & Installation
Fig. 6 - System Components BATTERY PACK REMOVAL & INSTALLATION: Motor 3-Way Air/Water Syringe 1. Release velcro strap and unbuckle it from the loop at the bottom of the battery bay. 2. Pull forward on the back right corner of the battery to remove it from the battery bay. -
Page 11: Sterilization & Maintenance
STERILIZATION AND MAINTENANCE: 1. CHASSIS - The exterior of the chassis, WARNING including air/water syringes and tubing, may be cleaned by wiping with a soft cloth Failure to comply with any of the following moistened with mild detergent or instructions may void your warranty disinfecting solution. - Page 12 autoclavable tips: To remove a tip, press 4. MOTOR BULB - The motor light bulb may on the locking collar surrounding the tip become dirty in the autoclave and require socket and pull the used tip straight out of cleaning or replacement. NOTE: Do not the socket (see Fig.
-
Page 13: Charging The Battery Packs
CHARGING THE BATTERY PACKS: 1. There are three methods for charging the Turn on the DC switch. If the battery is battery packs: The first method is through less than 28 VDC, the system will an AC source, the second method is automatically start charging the battery through a vehicle battery (DC source) and (the charge button LED will come on),... -
Page 14: Fuses
230V: 0.6A, 250V slo-blo fuse (Fuse size: 5 x 20mm) 3. Reinstall the Fuse Holder. NOTE: The AEU-14CF is manufactured with 1.25A rated fuses installed, for a 120V power source. If operating with a 230V power source, change to the 0.6A rated... -
Page 15: Re-Packing Unit
10. Fold solar panel and place on top of manuals. AEU-14CFH RE-PACKING UNIT: 1. Once the AEU-14CF is packed, place inside of AEU-14CFH transport case in the front slot. 2. Place backpack in slot directly behind the AEU-14CF. -
Page 16: Symbol Definitions
SYMBOL DEFINITIONS: Type B Equipment Alternating current Attention, consult Protective earth (ground) accompanying documents Dangerous Voltage Protected Against Dripping Water IPX1 IPX1 Do Not Throw Into Trash... -
Page 17: Troubleshooting
TROUBLESHOOTING: Problem: Chassis does not light when turned on: Chassis lights when turned on, but handpiece does not turn: Chassis does not light when 12V/24V power is applied: Chassis does not light when battery pack is applied: Motor slowing down or sluggish: Unit fails to build pressure: Battery fault light on: Unit fault light on:... -
Page 18: Warranty
(90) days from the date of return to Aseptico, whichever is later. This limited warranty applies only to the initial or first installation of the product or part. - Page 19 NOTES...
- Page 20 P.O. Box 1548 • Woodinville, WA 98072 P/N: 420382 8333 216th Street SE Woodinville, WA 98072 Rev. J ECO 15548 (425) 487-3157 (800) 426-5913 PRINTED IN www.aseptico.com • info@aseptico.com 07/2022 THE U.S.A.
