Aseptico AEU-14CF Operations Manual & Parts List

Emergency field dental unit
Hide thumbs Also See for AEU-14CF:
Table of Contents

Advertisement

Quick Links

Download this manual
AEU-14CF
Emergency Field Dental Unit
xpedition
OPERATION MANUAL
& PARTS LIST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AEU-14CF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aseptico AEU-14CF

Summary of Contents for Aseptico AEU-14CF

  • Page 1 AEU-14CF Emergency Field Dental Unit xpedition OPERATION MANUAL & PARTS LIST...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS: SPECIFICATIONS: Case Dimensions: 17.5 in x 11.6 in x 6.9 in Introduction ......1 (44.5 cm X 29.5 cm X Package Contents .

  • Page 3: Introduction

    Your new Aseptico Expedition Emergency Field Dental Unit is the most compact, full-featured portable electric dental system available. The AEU-14CF Expedition features an “E” type autoclavable 30,000 RPM brushless micromotor with 1/1 ratio straight handpiece and 5/1 increaser contra-angle with fiberoptic light & water, a 3-way air/water syringe, a self contained water system, and oil-less air compressor.

  • Page 4: Setting Up The Unit

    MOTOR / HANDPIECE ALIGNMENT draw power from the highest source. It is not advised to operate off all sources at one time. The AEU-14CF Expedition circuitry allows the unit to operate while using an AC power source that is either 120V or 230V, and either 50Hz or 60 Hz.
  • Page 5 FIG. 2 - Setup Handpiece / Motor 3-Way Air/Water Syringe Motor Connector Water Supply Battery Pack Cable Battery Pack 1 Battery Pack 2 Foot Control AC Power Receptacle Motor Receptacle Vehicle Battery Cable In Battery Pack In Foot Switch Receptacle FIG.

  • Page 6: Operation Functions

    OPERATION FUNCTIONS - REFER TO FIGURE 4 - 5/1 Ratio Handpiece: 1. Power On/Off Switch – Controls power on/off to chassis from 120V/220V AC Each push of up/down button will source. When DC power is turned on, with increase/decrease speed by 13,000 RPM. The LED speed display indicates relative AC power, the AC will override the DC speed from 20,000 RPM minimum to...
  • Page 7 11. Battery Level – Indicates level of charge the previously used intensity level (fiber optic light switch must be ‘On’) . When the for the battery pack that is connected to dental motor/handpiece is turned off, the the chassis. “FULL” is 32V, with a drop of handpiece light will stay on for thirteen 1V per LED.

  • Page 8: Operation

    Flow knob to desired setting. the operator must be in contact with the 7. Use the 3-Way Air/Water Syringe as vehicle, the AEU-14CF Expedition can be necessary for irrigation or drying. Use a safely powered by way of an inverter through sterile syringe tip for each operation.

  • Page 9: Battery Pack Removal & Installation

    BATTERY PACK REMOVAL & 9. When the fiber optic light LED is on, the light on the motor will turn on when either INSTALLATION: the manual mode selector switch or foot control is depressed. The motor light will 1. Remove shoulder screws from the front remain on for 13 seconds after the manual bracket.

  • Page 10: Sterilization & Maintenance

    STERILIZATION AND MAINTENANCE: W RNING 1. CHASSIS - The exterior of the chassis may be cleaned by wiping with a soft cloth moistened with mild detergent or Failure to comply with any of the following disinfecting solution. instructions may void your warranty 2.
  • Page 11 7. SYRINGE TIPS - The Three-Way Air/Water 4. MOTOR BULB - The motor light bulb may Syringe features quick-change become dirty in the autoclave and require autoclavable tips: To remove a tip, press cleaning or replacement. NOTE: Do Not on the locking collar surrounding the tip Handle Bulb With Bare Fingers.

  • Page 12: Charging The Battery Packs

    CHARGING THE BATTERY PACKS 1. The primary method for charging the 4. Charging From Vehicle Battery - The battery packs is through the built-in system is designed to charge from a charger in the chassis. vehicle battery, provided the vehicle battery has 11V and sufficient amperage.

  • Page 13: Re-Packing Unit

    230V: 0.6A, 250V slo-blo fuse (Fuse size: 5 x 20mm) 3. Reinstall the Fuse Holder. NOTE: The AEU-14CF is manufactured with 250V (1.25A rated) fuses installed, if operating with a 230V power source, change to the 0.6A rated fuses before...

  • Page 14: Safety Precautions

    WARNING: For use by qualified and trained personnel only. WARNING: Do not install where there is a risk of an explosion. The AEU-14CF is not intended for operation in the presence of flammable anesthetics or gases. SYMBOL DEFINITIONS: Type B Equipment...

  • Page 15: Troubleshooting

    TROUBLESHOOTING: Problem: Correction: Chassis does not light when turned on: Check chassis to power connection. Check that voltage is proper voltage. Check fuse. If blown, replace with 1.25A/250V slo-blo fuse for 120V operation, & 0.6A/250V slo-blo fuse for 230V operation. Chassis lights when turned on, but Check motor plug connection.

  • Page 16: Warranty

    Aseptico's sole obligation under product warranty is (at its sole option and discretion) to repair or replace any defective component or product in part or whole. Aseptico shall be the sole arbiter of such action.
