Nexa™ Customer Service Reference Guide
10. Lock and Key
The optional lock and key kit can be used to lock the dispenser.
a. The lock can be inserted at the top of the backplate. There is a vertical mark on
the lock that points to lock/unlock graphics on the backplate.
b. You can switch between the two configurations by rotating the lock 180 degrees.
c. If the dispenser is locked, you must open it using the key provided in the kit or a
paperclip.
d. The key or paperclip can be inserted into the hole on the top exterior of the
backplate and this will allow the cover to open.
INDICATOR LINE-
POINTS TO LOCKED OR
UNLOCKED
KEY OPENING
UNLOCKED
LOCK STRADLES THIS
CONFIDENTIAL
January 2014
LOCKED
BEAM
KEY AND PAPERCLIP
