- Page 1 SCLS IV/ AQUANOMIC EU IV DISPENSING MODULE Installation and Operation Manual Retain this manual for installation, operation, and servicing information. 370 Wabasha Street N. St. Paul, MN 55102 www.ecolab.com © 2016 Ecolab Inc. All rights reserved 29516/0407/0117 Part No. 9259-2002...
-
Page 2: Table Of Contents
2.3.1 Dimensions ....................2-2 3.1 System Installation ............. 3-1 3.2 Installation Procedure..............3-1 3.1.1 Mounting the SCLS IV to the SCLS ..........3-1 3.3 Wiring (wiring diagram below Figure 3-2) .......... 3-2 3.4 Plumbing ..................3-3 4.0 System Programming ..........4-1 5.0 Startup and Operation .......... -
Page 3: System Introduction
The installation must be made in accordance with local plumbing and electrical codes. 1.3 System Features The SCLS IV/AQUANOMIC EU IV DISPENSING MODULE unit offers the following features: • Addition of a fourth product will give improved application flexibility. - Page 4 SCLS IV/ AQUANOMIC Vacuum EU IV Breaker Pre & Post Dispensing Module Sour/ Product Nozzle Flush Detergent Pre & Post Bleach Softene Nozzle Nozzle Flush Nozzle Nozzle r Nozzle Sump Sump Detergent Solenoid Valve Bleach Solenoid Valve Softene Control N.O.
- Page 5 SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual...
-
Page 6: Requirements/Specifications
2.2.3 Electrical The SCLS IV/AQUANOMIC EU IV does not require any additional electrical or water service relative to the main dispenser. The SCLS IV/AQUANOMIC EU IV runs on 24 volt electrical service originating from the main dispenser cabinet. The SCLS IV/AQUANOMIC EU IV uses water from the main dispenser and therefore does not require additional water hook up. -
Page 7: Specifications
• Width ....10 1/4” • Depth .....11” • Weight....15 lbs. (with product up to 21 lbs.) • Product clearance needs to be 8” above the cabinet to replace product capsules. Figure 2-1 SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual... -
Page 8: System Installation
SCLS/AQUANOMIC EU Bracket Figure 3-1 2. Hang cabinets on the brackets with the SCLS IV/AQUANOMIC EU IV to the left of the SCLS/AQUANOMIC EU cabinet. NOTE: Remove the protective label from the left side of the SCLS/Aquanomic EU cabinet prior to... - Page 9 SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual...
-
Page 10: Wiring (Wiring Diagram Below Figure 3-2)
5. Connect the red and the white/red wires to the open tabs on the flush valve. SAFETY FLUSH 4TH PRODUCT VA LV E VA LV E 12–PIN CONNECTOR TO J7, ON CPU BOARD WHT/ORG SCLS IV/AQUANOMIC EU IV cabinet SCLS/AQUANOMIC EU cabinet Figure 3-2 SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual... -
Page 11: Plumbing
2. Insert a tube insert into each end of the 1/4” white tubing just cut and insert the tube ends into the T connector. 3. Feed the 1/4” white tubing from the SCLS IV/AQUANOMIC EU IV cabinet through the top hole on the left side of the SCLS IV/AQUANOMIC EU IV cabinet. - Page 12 SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual...
- Page 13 Figure 3-4 below. Be sure drain tube is not kinked. Shorten length if necessary. 4TH PRODUCT SUMP OUTLET SUMP HOSE HOSE CLAMP CLAMPS 4TH PRODUCT DRAIN TUBE DRAIN TUBE TUBE INSERT PUMP INLET SCLS IV (9259- SCLS CABINET/ 1097)/ AQUANOMIC AQUANOMIC EU EU IV CABINET Figure 3-4 (9259–1000)
- Page 14 SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual...
-
Page 15: System Programming
4.0 System Programming All SCLS IV/AQUANOMIC EU IV programming is carried out at the SCLS/AQUANOMIC EU dispenser according to the following steps. 1. Enter programming mode of the SCLS/AQUANOMIC EU dispenser by pressing the [Program] key, your password (default is 12345) and then the [Enter] key. -
Page 16: Startup And Operation
5.0 Startup and Operation 1. If both the SCLS/AQUANOMIC EU and the SCLS IV/AQUANOMIC EUIV are being installed at the same time, complete the startup and operation of the SCLS/AQUANOMIC EU (Section 5.0, SCLS /AQUANOMIC EU I/O Manual) prior to proceeding to step 2. -
Page 17: Troubleshooting
Remove the leads from the coil to test. d. If 24 VAC is present, replace the coil. e. If 24 VAC is not present, replace the CPU module. SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual... -
Page 18: Replacement Parts
13, 14 14 9321-2135 TEE, 3/8T X 3/8T X 3/8T • 9258-1005 DRAIN TUBE ASSEMBLY • 9258-4291 LOCKOUT & SUMP LUGS • PART NOT SHOWN SPRAY TUBE DETAIL FLUSH TUBE DETAIL SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual... - Page 19 370 Wabasha Street N. St. Paul, MN 55102 www.ecolab.com © 2016 Ecolab Inc. All rights reserved. 29516/0406/0216 Part No. 9259-2002 SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual...
