Specifications - Geosense MEMS DPI I Instruction Manual

MEMS Digital Portable Horizontal Inclinometer
V1.1
09/02/2022

SPECIFICATIONS

MODEL
Orientation
Vertical
PROBE
Sensor type
Sensor accuracy
2
Sensor resolution
Sensor repeatability
Output signal
Output unit
Probe gauge length
Probe diameter
Probe length
Probe length
Probe weight
Enclosure rating
Materials
Probe carry case dimensions
Probe carry case weight
CABLE
Diameter
Weight
Minimum break load
Restraining member
Jacket
Depth markers
Lengths
Connector
CABLE REEL & CARRY BAG
Communication
Enclosure rating
Power supply
Operating time
Material
30 to 50m cable diameter
75 to 100m cable diameter
30m cable weight
50m cable weight
75m cable weight
100m cable weight
SYSTEM
Total system accuracy
Total system repeatability
Cat S42 readout unit
Readout data export
Operating temperature
COMPLIANCE
CE Directives
FCC certification
Full Scale Range
±30° from horizontal
Biaxial MEMS
±0.004° (±13.5 arc sec, ±0.07 mm/m) ±0.0125% FS
0.0005° (2 arc sec, 0.01 mm/m) 0.0017% FS
±0.002° (±7.2 arc sec, ±0.037 mm/m) ±0.007% FS
RS-485 Digital
Sine of angle
500mm
25mm
680mm
(including connector) 800mm
1.32kg
IP68 (24 bar)
316 stainless steel,
725 x 200 x 105mm
5.6kg
7.5mm
5.8kg/100m
400kgf
Double Kevlar reinforcement
Polyurethane
Every 500mm
30,50,75,100,150m (other available on request)
Piston & face seal with robust stainless-steel alignment keyway
(30 bar rated)
Bluetooth low energy
IP65
Ni-MH 12V 1000mAh rechargeable batteries
Minimum 15 hours continuous
Polycarbonate
310mm
380mm
5.92kg (including carry case)
7.2kg (including carry case)
9.5kg (including carry case)
10.85kg (including carry case)
± 3mm/30m (within 3° from vertical)
± 1mm/30m
mm
CSV (ASCII, Sine & mm) & RPP (Compatible with Sitemaster & Inclinalysis)
-40 to +85°C
EMC 2014/30/EU Industrial, RED 2014/53/EU, RoHS 2 2011/65/EU
Part 15
63
