MEMS Digital Portable Horizontal Inclinometer
V1.1
09/02/2022
8. SYSTEM ASSEMBLY AND OPERATION
8.1.
Assembling the System
Most of the components of the Inclinometer Readout System are contained within
the hard carry case. Only the cable, reel and its charger are housed within the soft
case.
5) Remove the probe from the hard case and remove the black cable connector
cap (Item F - Figure 10: Inclinometer Components)
6) Remove the cable reel from its case and remove the cable connector cover.
