MEMS Digital Portable Horizontal Inclinometer
V1.1
09/02/2022
30) Once you reach the top/access end with the probe, the survey needs to be
repeated, with the probe rotated 180 degrees around the Z-Axis.
Figure 24: Probe rotated around Z-axis 180 degrees between
surveys.
First Survey
Orientation – 1 ring end connected to reel
Second Survey
Orientation – 2 ring end connected to reel
36
