ProLights SmartBat PlusG2 User Manual page 18

2 SETUP
3 ADVANCED
16
WIRELESS WDMX ON/OFF
WDMX MODE
TX LINK
TX UNLINK
RX RESET
DMX TO WDMX
(TX)
WDMX TO DMX
(RX)
SCREEN BACKLIGHT
FLIP DISPLAY
KEY LOCK
TEMPERATURE
UNIT
TRANSFER WITHOUT DMX
CONFIGURATION ADDRESS
WITH DMX
ADDRESS
WHITE OFF
CALIBRATION
STUDIO
MANUAL
CALIBRATED
DIMMER LINEAR
CURVE
S-CURVE
SQUARE LAW
INVERSE SQUARE
LAW
PROLIGHTS - SmartBat PlusG2
MANUAL
COLORS
BASIC
STANDARD
EXTENDED
ON
OFF
TRANSMITTER
RECEIVER
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
10S
20S
30S
ON
OFF
ON
OFF
°C
°F
RED <125-255>
GREEN <125-255>
BLUE <125-255>
WARM WHITE <125-255>
RED <0-255>
GREEN <0-255>
BLUE <0-255>
WARM WHITE <0-255>
4500K
5000K
5600K
6000K
6500K
7000K
8000K
9000K
10000K
RED
GREEN
BLUE
WHITE
Enable/Disable the wireless card.
Choose whether
the wireless
Transmitter
WDMX mode is unlocked only if
WDMX ON / OFF is ON.
TX link unlock when the unit is set
as a transmitter.
Disconnect the transmitter from
all receivers.
TX unlink unlocks only if WDMX
mode is on transmitter.
Total reset of the receiver.
RX reset unlocks only if WDMX
mode is receiver.
Enable/Disable the transmission
of the dmx from the transmitter
to the receiver via wdmx.
Enable/Disable the retransmis-
sion of the DMX from the receiv-
er to the other units connected
by cable to the receiver itself.
Select the timing after that dis-
play will switch automatically off
when unactive.
Allows you to rotate the display
by 180°.
Lock the buttons on the control
panel by a password.
Press following
(password) in order to access to
the user menu : UP, DOWN, UP,
DOWN, ENTER.
Allows you to choose tempera-
ture unit showed in home screen.
To transfer the same menu
settings of one fixtures to all the
other in the daisy chain, including
or not the dmx address.
Choose dimmer curve.
to set
card as
or Receiver.
combinations
