UG237: EFM8BB2-SLSTK2021A User's Guide
Kit Block Diagram
2. Kit Block Diagram
An overview of the EFM8BB2 Starter Kit is shown in the figure below.
Board
EFM8BB2
Controller
Microcontroller
Joystick
Figure 2.1. EFM8BB2-SLSTK2021A Block Diagram
silabs.com | Building a more connected world.
Rev. 0.4 | 3
