Evelyn Double Bed
Assembly Instructions
Dimensions
Width - 147cm
Depth - 202cm
Height - 112cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Homebase = 0345 0778888
- Please keep for future reference
340/3790
343/2833
Issue 1 - 10/12/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos Evelyn 340/3790
Summary of Contents for Argos Evelyn 340/3790
- Page 1 Evelyn Double Bed Assembly Instructions 340/3790 - Please keep for future reference 343/2833 Dimensions Width - 147cm Depth - 202cm Height - 112cm Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: Homebase = 0345 0778888 Issue 1 - 10/12/14...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • During assembly do not stand • To reduce • Check you have all the components and tools listed on or put weight on the product, the likelihood of the following pages.
- Page 3 Components - Panels If you have damaged or missing components, call the Customer Helpline: Homebase = 0345 0778888 Please check you have all the panels listed below Footboard frame Side rail x 2 Headboard frame (192.1 x 9cm) (143.2 x 70cm) (143.2 x 67.5cm) Headboard post x 2 Slat x 4...
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. 16mm Bolt x 4 46mm Bolt x 24 54mm Bolt x 4 30mm Bolt x 8 Large plain washer x 8...
- Page 5 Assembly Instructions Step 1 Assemble headboard Assemble headboard post onto headboard frame using bolts and secure tightly. Step 2 Assemble side rails Three people are needed here. Assemble side rails to headboard post and footboard frame using bolts , spring washers , large plain washers...
- Page 6 Assembly Instructions Step 3 Assemble slats Assemble slats onto the unit using bolts , small plain washers and nuts Step 4 Assemble center support slats and legs Use bolts and small plain washers and center support slats onto slats...
- Page 7 Assembly Instructions Step 5 into the headboard frame and footboard frame. Note: Re-tighten all the bolts. Assembly is complete. Customer Helpline: If you need help or have damaged or missing parts, call the Homebase = 0345 0778888...
