Stirling - 3+3 Drawer Chest
Assembly Instructions -
Dimensions
Width - 105cm
Depth - 39cm
Height - 61.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
345/8312
357/6555
MADE IN
BRITAIN
Issue 1 - 11/11/14

Advertisement

loading
Need help?

Need help?

Do you have a question about the Stirling 345/8312 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Argos Stirling 345/8312

  • Page 1 Stirling - 3+3 Drawer Chest Assembly Instructions - 345/8312 Please keep for future reference 357/6555 Dimensions Width - 105cm Depth - 39cm MADE IN Height - 61.5cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 Issue 1 - 11/11/14...
  • Page 2: Care And Maintenance

    Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 35kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Note: Due to the manufacturing process, these 2 large holes can be on either surface of the upright.
  • Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the 2 large drawer fronts Screw 2 metal dowels into each of the large drawer fronts Note: Tighten the metal dowels up fully against the panels.
  • Page 6 Assembly Instructions Step 4 Fit the drawer bases Slide the drawer base down the grooves in the large drawer sides and down into the groove in the large drawer front Step 5 Fit the large drawer backs Fit the large drawer back between the large drawer sides Make sure that the...
  • Page 7 Assembly Instructions Step 7 Fit the wedgefixes Turn the 2 large drawer assemblies over and slide 2 wedgefixes into the front and back grooves, as shown, and tighten up the screws. Step 8 Prepare the 4 small drawer fronts Screw 2 metal dowels into each small drawer front Note: Tighten the metal...
  • Page 8 Assembly Instructions Step 10 Attach the small drawer sides to the small drawer fronts Push the small left drawer side and small right drawer side onto the back of the small drawer front Turn the small locking nuts on the small left drawer side small right drawer side Step 11...
  • Page 9 Assembly Instructions Step 13 Attach the handles Attach a handle each of the small drawer fronts using screws Step 14 Fit the wedgefixes Turn the small drawer assembies over and slide 2 wedgefixes into the front and back grooves, as shown, and tighten up the screws.
  • Page 10 Assembly Instructions Step 16 Prepare the left side Important: The left side and upright panels can look similar but, the left side is thinner and its Finished holes are not drilled all front edge the way through. Place 3 runners the left side .
  • Page 11 Assembly Instructions Step 17 Prepare the right side Important: The right side and upright panels can look similar but, the left side is thinner and its holes are not drilled all the way through. Place 3 runners the right side .
  • Page 12 Assembly Instructions Step 18 Join the sides to the Note: To make the assembly easier, place polystyrene blocks from the packaging underneath the side panels to raise them up. Push the left side and right side onto Polystyrene the top block Use a screwdriver to Polystyrene...
  • Page 13 Assembly Instructions Step 19 Prepare the upright Note: Due to the manufacturing process, the 2 holes for the large Finished front edge locking nuts can be on either surface of the upright. Place 3 runners the upright . Slide back the top of runner and use the 2nd hole from the front to fit the Finished...
  • Page 14 Assembly Instructions Step 20 Fit the upright Note: The 2 large locking nuts can be on either surface of the upright. Push the upright onto the top Use a screwdriver to tighten the 2 large locking nuts fitted to Polystyrene the upright block Polystyrene...
  • Page 15 Assembly Instructions Step 22 Fit the base Fit the base to the upright and side panels using 6 screws Step 23 The measurement from top corner X to bottom corner X must be equal to the measurement from top corner Y to bottom corner Y Fit the back Square up the unit by making sure that...
  • Page 16 If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800 and quote the reference numbers on the component pages. Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW ALR3108...
