New Hallingford -
Assembly Instructions -
Dresser
Dimensions
Width - 99.5cm
Depth - 40cm
Height - 78.5cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
Please keep for future reference
Stool
Dimensions
Width - 51.5cm
Depth - 35.5cm
Height - 45cm
Dresser, Stool & Mirror
346/9727
330/6086
357/1268
356/3537
357/0290
MADE IN
BRITAIN
Issue 1 - 16/12/14
Advertisement
Related Manuals for Argos New Hallingford 346/9727
Summary of Contents for Argos New Hallingford 346/9727
- Page 1 New Hallingford - Dresser, Stool & Mirror Assembly Instructions - 346/9727 Please keep for future reference 330/6086 357/1268 356/3537 357/0290 Dresser Stool Dimensions Dimensions Width - 99.5cm Width - 51.5cm Depth - 40cm Depth - 35.5cm MADE IN Height - 78.5cm Height - 45cm BRITAIN Important -...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 34kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Dresser Divider Left Mirror Right Mirror (DF1865) (162 x 355mm) Support Support (DF1868)
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers below) Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Note: The small right drawer fronts have an identification mark hole. Prepare the 2 drawer fronts Screw 2 metal dowels into the left drawer front and the right drawer front...
- Page 6 Assembly Instructions Step 4 Fit the drawer base Slide the drawer base down the grooves in the drawer sides and down into the groove in the drawer front 9 10 Step 5 Fit the drawer back Fit the drawer back between the drawer sides Make sure that the...
-
Page 7: Modesty Panels
Assembly Instructions Step 8 Runners must be Fit runners to the pushed up against the drawer front drawers Fit runner , marked with ‘R’, to the bottom edge of the right drawer side , as shown, making sure that it is pushed up against the back of the drawer fronts . - Page 8 Assembly Instructions Step 10 screw screw screw Prepare the left side Fit a runner the left side The 1st screw uses the 1st hole in from the front of the runner. Finished front edge The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 9 Assembly Instructions Step 11 Prepare the right side Fit a runner the right side Finished front edge The 1st screw uses the 1st hole in from the front of the runners. screw screw screw The 2nd and 3rd screws use the holes that line up with the other panel holes.
- Page 10 Assembly Instructions Step 12 Fit the modesty panels to the right side Push the 2 modesty panels onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to each of the modesty panels Finished Note: Support the 2 front edge Note: Turn the large modesty panels until the...
- Page 11 Assembly Instructions Step 15 Note: Due to the manufacturing process, the 2 holes for the large locking nut can be on either surface of the divider. Prepare the divider Fit a runner the divider screw screw screw The 1st screw uses the 1st hole in from the front of the runner.
- Page 12 Assembly Instructions Step 16 Reminder: The 2 large locking nuts may be on Fit the divider onto either surface of the divider the top Push the divider onto the top Use a screwdriver to Finished tighten the 2 large front edge locking nuts fitted to Rounded...
- Page 13 Assembly Instructions Step 19 Remember: The small right drawer front has an Fit the drawers identification mark hole. Slide the wheels of the runners fitted to the drawers, over the wheels of the runners fitted to the side panels and push the drawers into position.
- Page 14 Assembly Instructions Step 22 Prepare the stool drawer front Screw 2 metal dowels into the stool drawer front Step 23 Prepare the stool drawer sides Insert a small locking into the hole shown on the stool left drawer side and stool right drawer side Note: Arrow on locking nut must point towards...
- Page 15 Assembly Instructions Step 25 Fit the stool drawer base Slide the stool drawer base down the grooves in the stool drawer sides . and down into the groove in the stool drawer front Step 26 Fit the stool drawer back Fit the stool drawer back down onto the stool drawer base...
- Page 16 Assembly Instructions Step 28 Prepare the stool rails Tap 2 wooden dowels into each of the stool rails Insert 4 large locking nuts into each of the stool rails Step 29 Prepare the stool left side Place a runner onto the stool left side Slide back the top of runner and use the 2nd hole from the front to fit...
- Page 17 Assembly Instructions Step 30 Prepare the stool right side Place a runner onto the stool right side . Slide back the top of runner and use the 2nd hole from the front to fit the 1st screw Slide the runner back the other way and use the 2nd hole from the back to fit the 2nd...
- Page 18 Assembly Instructions Step 31 Fit a stool rail to the stool left side Push a stool rail onto the stool left side Use a screwdriver to tighten the 2 large locking nuts fitted to the stool rail Step 32 Plain Prepare the stool chipboard surface...
- Page 19 Assembly Instructions Step 34 Fit the other stool rail Push the other stool rail onto the stool left side Use a screwdriver to tighten the 2 large locking nuts fitted to the stool rail Step 35 Fit the stool right side Push the stool right side onto the stool base and the 2 stool rails...
- Page 20 Assembly Instructions Step 37 Fit the 4 plastic nails Tap 2 plastic nails into the bottom edge of each of the stool sides and . Step 38 Plain chipboard Prepare the stool top surface Screw 4 metal dowels into the stool top Step 39 Fit the stool seat pad Fit the stool seat pad...
- Page 21 Assembly Instructions Step 40 Fit the stool top Lower the stool top down onto the assembly. Use a screwdriver to tighten the 4 large locking nuts fitted to the stool left side stool right side Step 41 Fit the stool drawer Slide both the runners forward and locate the drawer sides...
- Page 22 Assembly Instructions Step 42 Example Attach the Attach the Fit the overbalance Screw strap to the wall strap to the unit protector Washer Wall fixing Strap To prevent possible Strap (not supplied) overbalancing we Washer recommend that the dresser is secured to a Screw suitable wall by use of (not supplied)
- Page 23 If you need help or have damaged or missing parts, call the Customer Helpline: 0870 112 1928 or email: Help@ClickSpares.co.uk (quoting your original order number and the reference numbers on the component pages) Argos Ltd, 489-499 Avebury Boulevard, Central Milton Keynes, MK9 2NW...
- Page 24 ALR3138...
