Tektronix TMT4 Installation And Safety Instructions page 2

Operating
Non-operating
Required instrument clearance
Rear
Bottom
Sides
Top
Humidity
Operating
Non-operating
Altitude
Operating
Non-operating
Physical
Measure
Weight
Dimension
Height
Width
Depth
0°C to +50°C, with 15°C/hour maximum gradient, non-condensing
-40°C to +71°C, with 30°C/hour maximum gradient
None
Feet provide sufficeint clearance. Do not operate instrument without feet.
50.8 mm (2 in)
None
5% to 95% relative humidity (% RH) at up to +30°C
5% to 75% RH above +30°C up to +40°C
45% RH above +40°C up to 50°C, non-condensing
5% to 95% RH (Relative Humidity) at up to +30°C
5% to 45% RH above +40°C up to +71°C, non-condensing
Up to 3,000 meters
Up to 12,000 meters
Instrument only
3.07 kg (6.77 lbs)
With protective cover, handle, and feet
220 mm (8.66 in)
200 mm (7.87 in)
147 mm (5.79 in)
Power, environmental, and physical specifications
No protective cover,with 50 Ω terminators
200 mm (7.87 in)
190 mm (7.48 in)
140 mm (5.51 in)
2
