Page 1: User Guide
XPress-Pro SW 52000 User Guide Part Number 900-509 Revision A May 2007... - Page 2 Copyright & Trademark © 2005, Lantronix. All rights reserved. No part of the contents of this book may be transmitted or reproduced in any form or by any means without the written permission of Lantronix. Printed in the United States of America.
-
Page 3: Table Of Contents
DIN Rail Mounting ___________________________________________________ 9 Connecting to Power ________________________________________________ 10 DC Terminal Block Power Inputs ___________________________________________ 10 Connecting to Your Network __________________________________________ 11 Cable Type & Length ____________________________________________________ 11 Cabling _______________________________________________________________ 11 A: Specifications and Standards B: Connector Pinouts XPress-Pro SW 52000 User Guide... -
Page 4: 1: Preface
1: Preface A member of the growing family of rugged switches, this switch addresses a need for a smaller switch. This switch provides an affordable solution for rugged and outdoor environment, transportation road-side cabinet, industrial floor shop, multitenant dwellings or Fiber To The Home (FTTH) applications. -
Page 5: 2: Product Overview
Package Contents When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report any apparent damage or missing items immediately to your authorized reseller. This Switch User’s Manual XPress-Pro SW 52000 User Guide... -
Page 6: Product Highlights
Power consumption: 10.56W Max. Power Supply: DC Terminal Block power input, 10-48VDC with polarity protection. Plastic compact DIN-Rail Industrial case design. DIN-Rail mounting ability. Front Panel Display XPress-Pro SW 52000 User Guide 2: Product Overview 12VDC @ 0.71A, 24VDC @... -
Page 7: P Ower Status (Pwr)
P ower Status (PWR) This LED comes on when the switch is properly connected to power and turned on. P ort Status LEDs The LEDs display status for each respective port. 10/100TX or 100FX LNK/ACT (Green) (Yellow) Physical Ports... -
Page 8: 3: Installation
This chapter gives step-by-step instructions about how to install the switch: Selecting a Site for the Switch As with any electric device, you should place the switch where it will not be subjected to extreme temperatures, humidity, or electromagnetic interference. Specifically, the site you select should meet the following requirements: The ambient temperature should be between -10 to 60 degrees Celsius. -
Page 9: Connecting To Power
Connecting to Power DC Terminal Block Power Inputs 1. Connect the DC power cord to the plug-able terminal block on the switch, and then plug it into a standard DC outlet. 2. Disconnect the power cord if you want to shut down the switch. -
Page 10: Connecting To Your Network
5. Consult the previous section for cabling requirements based on connectors and speed. 6. Connect one end of the cable to the switch and the other end to a desired device. Once the connections between two end devices are made successfully, turn on the power and the switch is operational. -
Page 11: A: Specifications And Standards
Burst Standards (IEC 61000-4-4) Surge Standards (IEC 61000-4-5) Induced (Conducted) RFE Standards (IEC 61000-4-6) Magnetic Field Standards (IEC 61000-4-8) Voltage Dips Standards (IEC 61000-4-11) Environmental Test Standards: Vibration Resistance (IEC 60068-2-6) Shock (IEC 60068-2-27) Free Fall (IEC 60068-2-32) XPress-Pro SW 52000 User Guide... -
Page 12: B: Connector Pinouts
B: Connector Pinouts The following table lists the pinout of 10/100BaseT/TX ports. Pin Regular Ports XPress-Pro SW 52000 User Guide Pin Arrangement of RJ45 Connectors: Uplink port Input Receive Data + Output Transmit Data + Input Receive Data - Output Transmit Data -...
