Summary of Contents for Pfeiffer Vacuum ACP 28R
- Page 1 SUPPLEMENTARY INFORMATION Translation of the Original ACP 28R / ACP 40R V6SRPSDxxx / V8SRRSDxxx...
- Page 2 These operating instructions describe all models and variants of your product. Note that your product may not be equipped with all features described in this document. Pfeiffer Vacuum constantly adapts its products to the latest state of the art without prior notice. Please take into account that online operating instructions can deviate from the printed operating instructions supplied with your product.
-
Page 3: About This Manual
6 Connecting cable connection socket - cabinet Pump inlet 7 Connecting cable Pump exhaust 1.3 Liability limits Pfeiffer Vacuum is unaware of the ionizing environment in which the pump is used. Use of the pump in such environment is the responsibility of the user and/or integrator. 3/12... - Page 4 About this manual The service life of certain components (fan, thermal sensor, elastomers, plastic cable ducts, etc.) de- pends on the nature and level of the radiation. Pfeiffer Vacuum does not guarantee the durability of the product’s performance. 4/12...
-
Page 5: Installation
► Check the compatibility of the cabinet with the pump model: – ACP 28R pump with cabinet for ACP 28R pump (label on the cabinet). – ACP 40R pump with cabinet for ACP 40R pump (label on the cabinet). - Page 6 Installation Connecting the pump/cabinet connection cable 1. Connect the female connector to the pump’s socket. 2. Lock the pump connector in place. 3. Completely unroll the cable between the pump and the cabinet. 4. Observe a minimum bend radius of 200 mm on the cable. 5.
-
Page 7: Maintenance
The customer is responsible for product maintenance, waste treatment and management and product disposal, according to local regulations. 3.1 Pump overhaul by the customer Pfeiffer Vacuum supplies spare parts. The results obtained after repair do not involve the responsibility of Pfeiffer Vacuum. For any order of spare parts: contact us. - Page 8 We are always focused on perfecting our core competence – servicing of vacuum components. Once you have purchased a product from Pfeiffer Vacuum, our service is far from over. This is often exactly where service begins. Obviously, in proven Pfeiffer Vacuum quality.
- Page 9 Service solutions by Pfeiffer Vacuum 5. Prepare the product for transport in accordance with the provisions in the contamination declaration. a) Neutralize the product with nitrogen or dry air. b) Seal all openings with blind flanges, so that they are airtight.
-
Page 10: Technical Data And Dimensions
Technical data and dimensions 5 Technical data and dimensions Models ACP 28R ACP 40R Pump weight 30 kg 31 kg Cabinet weight 4 kg Connecting cable weight 0.75 kg/m Connecting cable diameter 19 ± 0,5 mm Connecting cable length 100-1000 dm... -
Page 11: Declaration Of Conformity
The person responsible for drawing up the technical file is Mr. Frédéric Rouveyre, Pfeiffer Vacuum SAS, 98, avenue de Brogny B.P.2069, 74009 Annecy cedex, France. Multi-stage Roots Pump, air cooled ACP 28R ACP 40R Harmonized standards and national standards and specifications applied:...
