Daewoo DSL-19M1WC Service Manual page 77

01.57.R.2.E101J
01.57.R.2.E103J
01.54.CS.2.E105Y16V
01.34.CL.D.E10U16VC
01.41.D.FD.E3RB
01.44.IC.D.E0038B
01.40.CON.S13.AY1.002
01.37.PCB.2.E3921C2
Bom No
MINV19-05QM1B03
Part No
01.57.R.2.E2R2J
01.57.R.2.E100J
01.57.R.2.E681J
01.57.R.2.E681F
01.57.R.2.E202J
01.57.R.2.E103J
01.57.R.2.E153J
01.57.R.2.E203J
01.57.R.2.E223J
01.57.R.2.E683J
01.57.R.2.E104J
01.57.R.2.E474J
01.57.R.4.E561J
01.57.R.4.E102J
01.54.CS.2.E101N
01.54.CS.2.E820N
01.54.CS.2.E821N
01.54.CS.2.E222X
01.54.CS.2.E472X
01.54.CS.2.E103X
01.54.CS.2.E223X
01.54.CS.2.E104Y
SMD resistor
SMD resistor
SMD capacitor
Electrolyse capacitor
Radiation diode
IC
Jack
Circuit board
Part No
02.07.MINV1905QM1
B03
Name
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD capacitor
SMD capacitor
SMD capacitor
SMD capacitor
SMD capacitor
SMD capacitor
SMD capacitor
SMD capacitor
0603-100Ω±5% 1 R16
0603-10KΩ±5% 1 R17
0603-105
Y5V-20+80%/16 1 C5
V
CD110-10UF/16
1 EC4
V 5*11
φ3 1 LED
HS0038B DIP 1 IR
1.25-6A( vertical
1 CON5
)DIP
Remote control
head
1
board3921C-V2.
0
Part Name QTY
Inverter 1
Specification QTY
0603-2.2Ω±5% 1 R21
0603-10Ω±5% 2 R10 R22
0603-680Ω±5% 4 R27 R30 R33 R36
0603-680Ω 1% 4 R28 R31 R34 R37
0603-2KΩ±5% 1 R9
0603-10KΩ±5% 3 R41 R17 R40
0603-15KΩ±5% 4 R23 R24 R25 R26
0603-20KΩ±5% 1 R14
0603-22KΩ±5% 4 R29 R32 R35 R38
0603-68KΩ±5% 2 R13 R18
0603-100KΩ±5
1 R20
%
0603-470KΩ±5
1 R19
%
1206-560Ω±5% 1 R4
1206-1KΩ±5% 1 R3
0603-100P
2 C13 C14
NPO±5%/50V
0603-82P
1 C6
NPO±5%/50V
0603-820P
1 C10
NPO±5%/50V
0603-222
4 C16 C17 C18 C19
X7R±10%/50V
0603-472
2 C27 C31 C35 C39
X7R±10%/50V
0603-103
5 C9 C28 C32 C36 C40
X7R±10%/50V
0603-223
1 C7
X7R±10%/50V
0603-104
Y5V-20+80%/50 1 C12
V
76
LOCA NO
