Daewoo DSL-19M1WC Service Manual page 42

151 RA8
150 RA9
149 RA11
147 CKE
146 RCLK
144 RA3
143 RA2
141 RA1
140 RA0
139 RA10
138 BA1
137 BA0
136 RCS#
135 RAS#
134 CAS#
133 RWE#
132 DQM1
130 IO_18 (DQS1)
129 RD8
128 RD9
127 RD10
126 RD11
125 RD12
124 RD13
123 RD14
122 RD15
121 RD0
120 RD1
119 RD2
117 RD3
116 RD4
115 RD5
114 RD6
113 RD7
112 IO_19 (DQS0)
111 DQM0
51 TDI V_ADIN4
52 TMS V_ADIN5
53 TCK V_ADIN6
Input DRAM address 8
Input
DRAM address 9
Input
DRAM address bit 11
Pull-Down
output DRAM clock enable
Input Dram clock
Input
DRAM address 3
Input
DRAM address 2
Input
DRAM address 1
Input
DRAM address 0
Input
DRAM address 10
Input
DRAM bank address 1
Input
DRAM bank address 0
output DRAM chip select, active low
output DRAM row address strobe, active low
output DRAM column address strobe, active low
output DRAM Write enable, active low
Input
Data mask 1
Input Non-pull
GPIO
Input
DRAM data 8
Input DRAM data 9
Input
DRAM data 10
Input
DRAM data 11
Input
DRAM data 12
Input
DRAM data 13
Input
DRAM data 14
Input
DRAM data 15
Input
DRAM data 0
Input
DRAM data 1
Input
DRAM data 2
Input
DRAM data 3
Input
DRAM data 4
Input
DRAM data 5
Input
DRAM data 6
Input
DRAM data 7
Input
GPIO
Non-pull
Input
Data mask 0
JTAG Interface( 4 )
1) Serial interface port 3 data-out
2) Version AD input port 4
Input Non-pull
3) GPIO
1) Serial interface port 3 data-in
2) Version AD input port 5
Input Non-pull
3) GPIO
1) Serial interface port 3 clock pin
2) Version AD input port 6
Input Non-pull
3) GPIO
41
