234 XTALI
201 GPIO_3
200 GPIO_4
199 RCLKB GPIO_5
198 RVREF GPIO_6
IO_0
176 C_0
(RD16)
IO_1
175 C_1
(RD17)
IO_2
173 C_2
(RD18)
IO_3
172 C_3
(RD19)
IO_4
171 C_4
(RD20)
IO_5
169 C_5
(RD21)
IO_6
168 C_6
(RD22)
IO_7
167 C_7
(RD23)
177 IO_17 (DQM2)
IO_8
166 YUVCLK
(DQM3)
IO_9
165 Y_0
(RD24)
IO_10
164 Y_1
(RD25)
IO_11
163 Y_2
(RD26)
IO_12
162 Y_3
(RD27)
IO_13
161 Y_4
(RD28)
IO_14
159 Y_5
(RD29)
IO_15
158 Y_6
(RD30)
IO_16
157 Y_7
(RD31)
155 RA4
154 RA5
153 RA6
152 RA7
Input
27M crystal in
Input
GPIO
Pull-Down
Input
GPIO
Pull-Down
Input
GPIO
Pull-Up
Input
GPIO
Pull-Up
Dram Interface ( 58 ) ( Sorted by position )
Input 1) Digital Video output C bit 0
Non-pull 2) GPIO
Input 1) Digital Video output C bit 1
Non-pull 2) GPIO
Input 1) Digital Video output C bit 2
Non-pull 2) GPIO
Input 1) Digital Video output C bit 3
Non-pull 2) GPIO
Input 1) Digital Video output C bit 4
Non-pull 2) GPIO
Input 1) Digital Video output C bit 5
Non-pull 2) GPIO
Input 1) Digital Video output C bit 6
Non-pull 2) GPIO
Input 1) Digital Video output C bit 7
Non-pull 2) GPIO
Input
GPIO
Non-pull
Input 1) Digital Video output Clock
Non-pull 2) GPIO
1) Digital Video output Y bit 0
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 1
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 2
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 3
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 4
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 5
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 6
Input
2) GPIO
Non-pull
1) Digital Video output Y bit 7
Input
2) GPIO
Non-pull
Input
DRAM address 4
Input
DRAM address 5
Input
DRAM address 6
Input
DRAM address 7
