Daewoo DSL-19M1WC Service Manual page 36

56 IOA2
57 IOA3
58 IOA4
59 IOA5
60 IOA6
61 IOA7
67 A16
91 A17
63 IOA18
64 IOA19
75 IOA20
87 IOA21
88 ALE
Pin Main Alt.
78 IOOE#
Input
2~16MA, SR Microcontroller address 2 / IO
PU
Input
2~16MA, SR Microcontroller address 3 / IO
PU
Input
2~16MA, SR Microcontroller address 4 / IO
PU
Input
2~16MA, SR Microcontroller address 5 / IO
PU
Input
2~16MA, SR Microcontroller address 6 / IO
PU
Input
2~16MA, SR Microcontroller address 7 / IO
PU
Output 2~16MA,
Flash address 16
SR
Output 2~16MA,
Flash address 17
SR
Input
2~16MA, SR Flash address 18 / IO
SMT
Input
2~16MA, SR Flash address 19 / IO
SMT
Input
2~16MA, SR Flash address 20 / IO
SMT
Input 1) Flash address 21 / IO
2~16MA, SR 2) While External FLASH size <= 2MB:
SMT I) GPIO
Input
2~16MA, SR Microcontroller address latch enable
PU, SMT
Type Description
Input
2~16MA, SR Flash output enable, active low / IO
SMT
35
