Daewoo DSL-19M1WC Service Manual page 35

74 HIGHA1
73 HIGHA2
72 HIGHA3
71 HIGHA4
70 HIGHA5
69 HIGHA6
68 HIGHA7
89 AD7
86 AD6
85 AD5
84 AD4
83 AD3
82 AD2
80 AD1
79 AD0
92 IOA0
Pin Main Alt.
IOA1
77
Input
2~16MA, SR Microcontroller address 9
PU
Input
2~16MA, SR Microcontroller address 10
PU
Input
2~16MA, SR Microcontroller address 11
PU
Input
2~16MA, SR Microcontroller address 12
PU
Input
2~16MA, SR Microcontroller address 13
PU
Input
2~16MA, SR Microcontroller address 14
PU
Input
2~16MA, SR Microcontroller address 15
PU
Input 2~16MA, SR
Microcontroller address/data 7
Input 2~16MA, SR
Microcontroller address/data 6
Input 2~16MA, SR
Microcontroller address/data 5
Input 2~16MA, SR
Microcontroller address/data 4
Input 2~16MA, SR
Microcontroller address/data 3
Input 2~16MA, SR
Microcontroller address/data 2
Input 2~16MA, SR
Microcontroller address/data 1
Input 2~16MA, SR
Microcontroller address/data 0
Input
2~16MA, SR Microcontroller address 0 / IO
PU
Type Description
Input
2~16MA, SR Microcontroller address 1 / IO
PU
34
