Daewoo DSL-19M1WC Service Manual page 43

54 TDO V_ADIN7
Note:
1. The Main column is the main function, Alt. Means alternative function.
2. The multi-function GPIO pins are set to green characters.
3. The video input port and external TV encoder mode can not both use CCIR-601 mode, at least one of them should be
in CCIR-656 mode.
4. Following is a summary of modified pins.
(a) Pin 48, 49, 50, 51 are no longer for JTAG functions.
(b) V_ADIN0 and V_ADIN3 is not available.
4. BA5954
1) Serial interface port 3 chip-select
Input Non-pull
2) Version AD input port 7
3) GPO
42
