Copyright
All rights are reserved. No part of this publication may be reproduced, transmitted,
transcribed, stored in a retrieval system or translated into any language or computer
language, in any form or by any means, electronic, mechanical, magnetic, optical,
chemical, manual or otherwise, without the prior written permission of the company.
Brands and product names are trademarks or registered trademarks of their respective
companies.
The vendor makes no representations or warranties with respect to the contents herein
and especially disclaim any implied warranties of merchantability or fitness for any
purpose. Further the vendor reserves the right to revise this publication and to make
changes to the contents herein without obligation to notify any party beforehand.
Duplication of this publication, in part or in whole, is not allowed without first obtaining
the vendor's approval in writing.
Trademark
All the trademarks or brands in this document are registered by their respective owner.
Disclaimer
We make no warranty of any kind with regard to the content of this user's manual. The
content is subject to change without notice and we will not be responsible for any
mistakes found in this user's manual. All the brand and product names are trademarks of
their respective companies.
FCC Compliance Statement
This equipment has been tested and found to comply with the limits of a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user will be required to correct the interference
at his own expense. However, there is no guarantee that interference will not occur in a
particular installation.
CE Mark
The device is in accordance with 89/336 ECC-ENC Directive.
KM333 Series
120410122M1N

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KM333 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Albatron KM333 Series

  • Page 1 KM333 Series Copyright All rights are reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of the company.
  • Page 2 # FDC Cable # USB Bracket (optional) # Game Port Bracket (optional) # IEEE 1394 Bracket (optional) # Installation and Setup Driver CD # KM333 Series User Manual Symbols Attention … Following the procedures … Troubleshooting … Please refer to …...
  • Page 3 KM333 Series KM266 PRO & VT8235 ® Supports Socket 462 Athlon XP/ Athlon / Duron / Barton Processors ® User Manual Dimensions (ATX form-factor): 244mm x 244mm ( W x L ) Operating System: Supports most popular operating systems: Windows® 98/ ME/ 2000/ XP...
  • Page 4: Table Of Contents

    Contents CHAPTER 1. GETTING STARTED .............1 ......................1 NTRODUCTION ......................2 PECIFICATION ....................... 5 ONFIGURATION Layout of KM333 PRO-1394 ................5 Layout of KM333 PRO ..................6 Layout of KM333 ....................7 ..................8 ARDWARE NSTALLATION CPU Processor Installation ................... 8 Back Panel Configuration...................
  • Page 5: Chapter 1. Getting Started

    KM333 Series Chapter 1. Getting Started Introduction Congratulations on choosing from the KM333 series of mainboards! The KM333 series includes the KM333 PRO-1394, KM333 PRO and KM333. These mainboards are based on the ® KM266 PRO Northbridge chipsets and the VIA ®...
  • Page 6: Specification

    KM333 Series Specification CPU: Supports Socket 462 AMD ® Athlon XP/ Athlon / Duron / Barton processors 200/ 266/ 333 MHz FSB (Front Side Bus) frequencies Chipset: Northbridge Chipset – VIA® KM266 PRO Southbridge Chipset – VIA® 8235 I/O Controller – Winbond W83697HF AC’97 Codec –...
  • Page 7 KM333 Series LAN Controller onboard: (for KM333 PRO-1394/ KM333 PRO) 10/ 100 MHz full and half duplex operation Independent 2 KB FIFOs for receive and transmit Magic packet and wake-on-address filtering Software controllable power down Onboard Video Graphic Acceleration: MPEG-2/1 Video Decoder...
  • Page 8 KM333 Series I/O facilities: multi-mode Parallel Port capable supporting following specifications: 1. Standard & Bi-direction Parallel Port 2. Enhanced Parallel Port (EPP) 3. Extended Capabilities Port (ECP) Contains two serial port, 16550 UART (one on back panel and one on front panel)
  • Page 9: Configuration

    KM333 Series Configuration Layout of KM333 PRO-1394...
  • Page 10: Layout Of Km333 Pro

    KM333 Series Layout of KM333 PRO...
  • Page 11: Layout Of Km333

    KM333 Series Layout of KM333...
  • Page 12: Hardware Installation

    KM333 Series Hardware Installation This section will assist you in quickly installing your system hardware. Wear a wrist ground strap before handling components. Electrostatic discharge may damage the system’s components. CPU Processor Installation This mainboard supports AMD Athlon XP / Athlon...
  • Page 13 KM333 Series FAN Headers Three power headers are available for the cooling fans. Cooling fans play an important role in maintaining the ambient temperature in your system. Attention: This system has a BIOS configuration feature that issues a warning (during POST) when the CPU fan is not plugged in or is not functioning.
  • Page 14 KM333 Series RAM Module Installation: The following instructions explains memory module installation for these mainboards: 1. Pull the white plastic tabs at both ends of the slot away from the slot. 2. Match the notch on the RAM module with the corresponding pattern in the DIMM slot.
  • Page 15: Back Panel Configuration

    The serial interface port is sometimes referred to as an RS-232 port or an asynchronous communication port. Mice, modems and other peripheral serial devices can be connected to this port. Video Graphics Accelerator Port: VGA The KM333 series has built in video facilities. Your monitor attached directly to the VGA connector on this mainboard.
  • Page 16 KM333 Series USB & LAN Connectors: USB & USB/(LAN is for KM333 PRO-1394 & KM333 PRO) These mainboards come with 4 USB ports. And the KM333 PRO-1394/ KM333 PRO have a 10/100 Mbit/s LAN port. The USB connectors are used to attach to keyboards, mice and other USB devices.
  • Page 17: Connectors

    KM333 Series Connectors Floppy Disk Connector: FDC These mainboards provide a standard floppy disk connector (FDC) that supports 360K, 720K, 1.2M, 1.44M and 2.88M floppy diskette drives. This connector supports the floppy drive ribbon cables provided in the packaging. Hard Disk Connectors: IDE1/ IDE2 The mainboard has a 32-bit Enhanced PCI IDE Controller that supports Ultra ATA 33, Ultra ATA 66, Ultra ATA 100 and Ultra ATA 133.
  • Page 18: Front Panel Indicator: Sw/Led、Pwrled、Speaker

    KM333 Series Front Panel Indicator: SW/LED、PWRLED、SPEAKER HD LED (Hard Drive LED Connector/ red) This connector can be attached to an LED on the front panel of a computer case. The LED will flicker during any disk activity. RST SW (Reset Connector/ blue) This connector can be attached to a momentary SPST switch.
  • Page 19: Headers & Jumpers

    KM333 Series Headers & Jumpers Infrared Header: IrDA You can attach an infrared device to this connector and use this connector for connectionless infrared data transfers. Game Port Header: GAME PORT There is a game port header on these mainboards. To use this header, you must attach a game port bracket-cable so that you can interface to gaming devices (game port bracket is optional).
  • Page 20 KM333 Series Case Open Warning Header: CASE OPEN This connector is used to warn the user that the computer case has been previously opened. To use this functionality, you have to enable the CASE OPEN warning function in the BIOS Setup Utility. When your computer case is opened, your system will show alert messages during boot up.
  • Page 21 KM333 Series IEEE1394 Headers: 1394CN1/ 1394CN2 The IEEE1394 high-speed serial bus provides enhanced PC connectivity for consumer electronics audio/ video (A/V) appliances, storage peripherals, other PCs, and portable devices. The KM333 PRO-1394 supports up to two IEEE1394 devices. You can connect the IEEE1394 bracket to these headers (1394CN1 &...
  • Page 22 KM333 Series CPU Clock Select Jumper: JP5、JP6 Use the jumper “JP5”、”JP6” to select the CPU Clock. If you are installing a CPU that has a 133 MHz CPU clock, you also set the “FSB Frequency” to 133 MHz in the BIOS Setup Utility.
  • Page 23: Audio Connectors

    KM333 Series Audio Connectors CD-ROM Audio-In Header: CD-IN This header is used to connect to the CD-ROM/DVD audio cable Front Panel Audio Header (Orange): FRONT AUDIO If your computer case has been designed with embedded audio equipment. You can attach these components to the FRONT_AUDIO panel of the mainboard. First remove the jumper caps covering the FRONT_AUDIO pins.
  • Page 24: Slots

    KM333 Series Slots These slots are designed for expansion cards to complement and enhance the functionality of the mainboard. AGP slot: AGP The mainboard is equipped with a 4X & 1.5V only Accelerated Graphics Port (AGP) to support video cards.
  • Page 25: Chapter 2. Bios Setup

    KM333 Series Chapter 2. BIOS Setup Introduction This section describes PHOENIX-AWARD™ BIOS Setup program which resides in the BIOS firmware. The Setup program allows users to modify the basic system configuration. The configuration information is then saved to CMOS RAM where the data is sustained by battery after power-down.
  • Page 26 KM333 Series Supported CPUs This PHOENIX-AWARD™ BIOS supports the AMD CPUs. ® Key Function In general, you can use the arrow keys to highlight items, press <Enter> to select, use the <PgUp> and <PgDn> keys to change entries, press <F1> for help and press <Esc>...
  • Page 27: Main Menu

    KM333 Series Main Menu When you enter the PHOENIX-AWARD™ BIOS Utility, the Main Menu will appear on the screen. The Main menu allows you to select from several configuration options. Use the left/right arrow keys to select a particular configuration screen from the top menu bar...
  • Page 28 KM333 Series Main Menu Setup Configuration Options Item Options Description Set the system date. Note that the ‘Day’ automatically Date mm dd yyyy changes when you set the date. Time Hh: mm: ss Set the current time of the system.
  • Page 29: Advanced Bios Features

    KM333 Series Advanced BIOS Features First /Second/Third Boot Device Select the order in which devices will be searched in order to find a boot device. Options: Floppy (default for first boot device)、LS120、HDD-0 (default for third boot device)、SCSI、CDROM (default for second boot device)、HDD-1、HDD-2、HDD-3、ZIP100、...
  • Page 30 KM333 Series CPU Internal Cache Make CPU internal cache active or inactive. System performance may degrade if you disable this item. Options: Enabled (default)、Disable. External Cache This option allows you to enable or disable “Level 2” secondary cache on the CPU to enhance performance.
  • Page 31 KM333 Series MPS Version Control For OS The 1.1 version is the older version that supports 8 more IRQs in the Windows NT environment. Choose the new 1.4 version for Windows 2000 and Windows XP. Options: 1.4 (default)、1.1 OS Select For DRAM > 64MB Select “OS2”...
  • Page 32 KM333 Series DRAM Command Rate This item determines DRAM Command Rate. Options: 2T Command (default)、1T Command AGP & P2P Bridge Control Press <Enter> to enter next page for AGP & P2P Bridge Control. AGP Aperture Size Select the size of the Accelerated Graphics Port (AGP) aperture. The aperture is a portion of the PCI memory address range dedicated for graphics memory address space.
  • Page 33 KM333 Series CPU & PCI Bus Control PCI1/2 Master 0 WS Write When enabled, writes to the PCI bus are executed with zero-wait states. Options: Enabled (default)、Disabled PCI Delay Transaction The chipset has an embedded 32-bit post write buffer to support delay transactions cycles.
  • Page 34 KM333 Series IRQ Resources When resources are controlled manually, you can assign each system interrupt a type, depending on the type of device using the interrupt. This is only configurable when “Resources Controlled By” is set to “Manual”. IRQ-3/4/5/7/9/10/11/12/14/15 assigned to: PCI device...
  • Page 35: Integrated Peripherals

    KM333 Series Integrated Peripherals Init Display First With systems that have multiple video cards, this option determines whether the primary display uses a PCI slot or an AGP slot. Options: AGP、PCI Slot (default) VIA OnChip IDE Device If you highlight the “OnChip IDE Device” label and then press the enter key, it will take you...
  • Page 36 KM333 Series Primary / Secondary /Master / Slave UDMA Ultra DMA/133 functionality can be implemented if it is supported by the IDE hard drives in your system. As well, your operating environment requires a DMA driver (Windows 95 OSR2 or a third party IDE bus master driver). If your hard drive and your system software both support Ultra DMA/133, select “Auto”...
  • Page 37 KM333 Series USB Device Support Enables support for USB attached devices. Options: Disabled (default)、Enabled Super IO Device If you highlight the literal “Press Enter” next to the “Super IO Device” label and then press the enter key, it will take you a submenu with the following options:...
  • Page 38 KM333 Series Parallel Port Mode This option allows you to select an operating mode for the on board parallel port. Options: ECP(default) Extended Capabilities Port. Enhanced Parallel Port. Standard Printer Port. ECP+EPP ECP & EPP mode. Normal EPP Mode Select Select EPP port type 1.7 or 1.9.
  • Page 39: Power Management

    KM333 Series Power Management The Power Management Setup Menu allows you to configure your system to utilize energy conservation features as well as power-up/ power-down options. ACPI Suspend Type The item allows you to select the suspend type using the ACPI operating system.
  • Page 40 KM333 Series When this option is enabled, the “suspend mode” time is configurable from 1 minute to 1 hour. The HDD Power Down, which ranges from 1 min. to 15 min. and includes a “disable” option. Note: If you select Min. or Max. Power Saving modes, the “HDD Power Down” value and the “Suspend Mode”...
  • Page 41 KM333 Series Wake Up Control If you highlight the “Wake Up Control” label and then press the enter key, it will display a submenu with the following options: PWRON After PWR-Fail This option determines whether you want to restart the system after a power failure.
  • Page 42 KM333 Series PCI Master When set to “On”, you need a LAN add-on card which supports the power on function. It should also support the wake-up on LAN jumper. Options: OFF (default)、ON PCI PME Wake Up When you select “Enabled”, a PME signal from any PCI card will awaken the system from suspend mode.
  • Page 43: Hardware Monitor

    KM333 Series Hardware Monitor CPU FAN Warning This item is used to monitor the “CPUFAN” header on the mainboard and warn the user (during POST) if the CPU fan is not operational or not plugged in. If you are not using the “CPUFAN”...
  • Page 44: Load Defaults

    KM333 Series Load Defaults Load System Default Settings Load System Default Settings. Load System turbo Settings Load System Turbo Settings.
  • Page 45: Exit Menu

    KM333 Series Exit Menu Save & Exit Setup Save all configuration changes to CMOS (memory) and exit setup. A confirmation message will be displayed before proceeding. Exit Without Saving Abandon all changes made during the current session and exit setup. A confirmation...
  • Page 46: Chapter 3: Software Setup

    KM333 Series Chapter 3: Software Setup Software List Category Platform VIA 4 IN 1 Driver Windows 98 /ME /2000 /XP VIA LAN Driver Windows 98 /ME /2000 /XP VIA Audio Driver Windows 98 /ME /2000 /XP VIA VGA Driver Windows 98 /ME /2000 /XP VIA USB2.0 Driver...
  • Page 47 KM333 Series 2. On the next screen, click the drivers that you want to install. 3. If you click the “VIA USB2.0 Driver” from the screen in step 2, it will display the screen as left. 4. Back to the main screen, click the “Tool Page”...
  • Page 48: Chapter 4: Troubleshooting

    KM333 Series Chapter 4: Troubleshooting Problem 1: No power to the system. Power light does not illuminate. Fan inside power supply does not turn on. Indicator lights on keyboard are not lit. Causes: 1. Power cable is unplugged. 2. Defective power cable.
  • Page 49 KM333 Series Problem 4: System only boots from the CD-ROM. The hard disk can be read and applications can be used but booting from the hard disk is impossible. Causes: Hard Disk boot sector has been corrupted. Solutions: Back up data and applications files. Reformat the hard drive. Re-install applications and data using backup disks.
  • Page 50 KM333 Series Problem 10: Keyboard failure. Causes: Keyboard is disconnected. Solutions: Reconnect keyboard. Replace keyboard if you continue to experience problems. Problem 11: No color on screen. Causes: 1. Faulty Monitor. 2. CMOS incorrectly set up. Solutions: 1. If possible, connect monitor to another system. If no color appears, replace monitor.
  • Page 51: Appendix I: Super 5.1 Channel Setup

    KM333 Series Appendix I: Super 5.1 Channel Setup This appendix describes the installation procedures for 5.1 Channel Setup. Note that if your operating system is Windows 98/ ME/ 2000, go directly to step 3. 1. Beginning with the “Start” button, select Setting & Control Panel & Sounds, Speech, and Audio Devices &...
  • Page 52 KM333 Series 4. On the “Front Speaker” screen, select “Options & Properties”, then check “Rear Speaker” item and click OK. 5. Also on the “Front Speaker” screen, select “Options & Advanced Controls”. 6. Next, click the “Advanced” button of the Front Speaker, then check the “Smart5.1 Enable”.
