- Page 1 EAX-R680P Intel® 12th Gen Core™ i9/i7/i5/i3/ Processor ATX Motherboard with Intel® R680E Chipset User’s Manual Ed –12 October 2022 Part No. E2047AR6800R...
- Page 2 Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
- Page 3 Applications that are described in this manual are for illustration purposes only. Avalue Technology Inc. makes no representation or warranty that such application will be suitable for the specified use without further testing or modification.
- Page 4 A product returned without proof of the purchase date is not eligible for warranty service. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. 4 EAX-R680P User’s Manual...
-
Page 5: Table Of Contents
2.3.21 USB connector 1 (JUSB1) ......................30 2.3.22 USB connector (JUSB2) ........................ 30 2.3.23 USB connector 4 (JUSB4) ......................31 2.3.24 J1RS2 connector (J1RS2) ......................31 2.3.25 J1RS3 connector (J1RS3) ......................32 2.3.26 Auxiliary Fan connector (AUXFAN1) ..................... 32 EAX-R680P User’s Manual... - Page 6 3.6.2.5.4 Serial Port 4 Configuration ....................51 3.6.2.5.5 Serial Port 5 Configuration ....................52 3.6.2.5.6 Serial Port 6 Configuration ....................52 3.6.2.6 NCT6126D HW Monitor ......................53 3.6.2.6.1 Smart Fan Configuration ....................... 53 3.6.2.7 S5 RTC Wake Settings ......................54 6 EAX-R680P User’s Manual...
- Page 7 3.6.6.3 Restore Defaults ........................78 3.6.6.4 Launch EFI Shell from filesystem device ................... 78 3.6.7 MEBx .............................. 78 4. Drivers Installation....................... 79 Install Chipset Driver ....................80 Install VGA Driver ....................81 Install ME Driver ...................... 82 EAX-R680P User’s Manual...
- Page 8 Install Audio Driver (For Realtek ALC888S HD Audio) ..........83 Install LAN Driver ....................84 Install RST Driver ....................86 Install Serial IO Driver ..................... 87 Install AscendingSortNetworkAdapterByMac ............88 5. Mechanical Drawing ....................89 Mechanical Drawing ....................90 Recommended Rubber Location ................91 8 EAX-R680P User’s Manual...
-
Page 9: Getting Started
1.2 Packing List Before you begin installing your single board, please make sure that the following materials have been shipped: 1 x EAX-R680P Motherboard 2 x SATA Cables 1 x I/O Shield ... -
Page 10: Document Amendment History
EAX-R680P User’s Manual 1.3 Document Amendment History Revision Date Comment October 2022 Avalue Initial Release 10 EAX-R680P User’s Manual... -
Page 11: Manual Objectives
We strongly recommend that you study this manual carefully before attempting to set up EAX-R680P or change the standard configurations. Whilst all the necessary information is available in this manual we would recommend that unless you are confident, you contact your supplier for guidance. -
Page 12: System Specifications
1 x 2 x 3 pin, pitch 2.00mm connector for COM1 pin9 RI/5V/12V jumper select (JRI1) COM2: by onboard pin-header support RS232/422/485 selected by BIOS 1 x 2 x 5 pin, pitch 2.00mm connector for COM2 to support RS232 12 EAX-R680P User’s Manual... - Page 13 1 x 2 x 5 pin, pitch 2.54mm pin-header for JME 1 x 5 pin, pitch 2.54mm pin-header for +3.3S Level SMBus Others 1 x 2 x 3pin, pitch 2.54mm pin-header for power f/w adjustment (not for user to modify) EAX-R680P User’s Manual 13...
- Page 14 PCB Material 6 Layers, NPG-170D Size (L x W) 12" x 9.6" (304.8mm x 243.84mm) Weight 1.54lbs (0.7kg) BIOS Support: OS Information 1. Win10 64bit UEFI 2. Linux Note: Specifications are subject to change without notice. 14 EAX-R680P User’s Manual...
-
Page 15: Architecture Overview-Block Diagram
User’s Manual 1.6 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of EAX-R680P. EAX-R680P User’s Manual 15... -
Page 16: Hardware Configuration
EAX-R680P User’s Manual 2. Hardware Configuration 16 EAX-R680P User’s Manual... -
Page 17: Product Overview
User’s Manual 2.1 Product Overview EAX-R680P User’s Manual 17... -
Page 18: Jumper And Connector List
CPU fan connector 4 x 1 wafer, pitch 2.54mm CPUFAN1 System fan connector 1 SYSFAN1 4 x 1 wafer, pitch 2.54mm (with smart fan function supported) JFP1 Front Panel connector 5 x 2 header, pitch 2.54 mm 18 EAX-R680P User’s Manual... - Page 19 FAUD1 connector 5 x 2 header, pitch 2.54mm FAUD1 JESPI1 connector 6 x 2 header, pitch 2.00 mm JESPI1 REAR1 connector 6 x 2 header, pitch 2.54mm REAR1 10GFAN1 10GFAN1 connector 2 x 1 wafer, pitch 2.00mm EAX-R680P User’s Manual 19...
-
Page 20: Setting Jumpers & Connectors
EAX-R680P User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 Serial port 3 pin9 signal select (JRI3) Ring* +12V * Default 2.3.2 Serial port 2 pin9 signal select (JRI2) Ring* +12V * Default 20 EAX-R680P User’s Manual... -
Page 21: Serial Port 1 Pin9 Signal Select (Jri1)
User’s Manual 2.3.3 Serial port 1 pin9 signal select (JRI1) Ring* +12V * Default 2.3.4 BIOS ME function configuration (JME1) Enable ME * Disable ME * Default EAX-R680P User’s Manual 21... -
Page 22: Clear Cmos (Jcmos1)
CPU TDP (Watts) (JCFGID1) 2.3.6 **The original setting is not allowed to be changed by user** Config ID1 * Config ID0 * Default Note: Config ID0: JCFGID1(1-2) (For debug only) Config ID1: JCFGID1(2-3) For CPU Power FW setting (Default). 22 EAX-R680P User’s Manual... -
Page 23: At/Atx Power Mode Select (Jsatx1)
User’s Manual 2.3.7 AT/ATX Power Mode Select (JSATX1) ATX* * Default 2.3.8 General purpose I/O connector (DIO1) Signal PIN PIN Signal Au/6 5V_SMB_CLK 17 18 5V_SMB_DATA EAX-R680P User’s Manual 23... -
Page 24: Atx Power Connector (Atxpwr1)
EAX-R680P User’s Manual 2.3.9 ATX Power connector (ATXPWR1) Signal PIN PIN Signal +3.3V +3.3V +3.3V -12V 16 ATX_PSON# ATX24_PWROK +V5A_SB +12V +12V +3.3V 2.3.10 Power connector (ATX12V1) Signal PIN PIN Signal ATX_2X4_DET +V12S_CPU +V12S_CPU +V12S_CPU +V12S_CPU 24 EAX-R680P User’s Manual... -
Page 25: Smbus Connector (Jsmb1)
User’s Manual 2.3.11 SMBus connector (JSMB1) Signal SMB_CLK SMB_DATA SMB_ALERT# +3.3V 2.3.12 Battery connector (BAT2) Signal +3.3V EAX-R680P User’s Manual 25... -
Page 26: Miscellaneous Setting Connector (Spi1)
EAX-R680P User’s Manual 2.3.13 Miscellaneous setting connector (SPI1) Signal PIN PIN Signal + V 3.3A_SPI SPI_CS0# SPI_CLK SPI_MISO SPI_MOSI SPI_HOLD# 2.3.14 Front Panel connector (JFP1) Signal PIN PIN Signal HDD_LED+ PWR_LED+ HDD_LED- PWR_LED- SYS_RST# PWRBTN# 26 EAX-R680P User’s Manual... -
Page 27: Cpu Fan Connector (Cpufan1)
User’s Manual 2.3.15 CPU fan connector (CPUFAN1) Signal +12V CPU_ FANIN CPU_FANOUT 2.3.16 System fan connector 1 (SYSFAN1) Signal +12V SYS_ FANIN SYS_FANOUT EAX-R680P User’s Manual 27... -
Page 28: External Speaker Connector (Jbz1)
EAX-R680P User’s Manual 2.3.17 External Speaker connector (JBZ1) Signal 2.3.18 Auxiliary Panel connector (JAUXP1) Signal PIN PIN Signal SMB_CLK CASEOPEN# ERROR_LED+ SMB_DATA ERROR_LED- FRONT_LAN1_ FRONT_LAN1_ACT 13 LINK100_1000# FRONT_LAN1_ LINK2500# FRONT_LAN2_ FRONT_LAN2_ACT 17 LINK100_1000# FRONT_LAN2_ LINK2500# 28 EAX-R680P User’s Manual... -
Page 29: Auxiliary Panel Connector (Jauxp2)
Auxiliary Panel connector (JAUXP2) Signal PIN PIN Signal FRONT_LAN3B_ACT FRONT_LAN3A_ACT FRONT_LAN3B_ FRONT_LAN3A_ LINK100_5G# LINK100_5G# FRONT_LAN3B_ FRONT_LAN3A_ LINK10G# LINK10G# 2.3.20 Serial port 2 connector (COM2) Signal PIN PIN Signal NRIB# NCTSB# NRTSB# NDSRB# NDTRB# NTXDB NRXDB NDCDB# EAX-R680P User’s Manual 29... -
Page 30: Usb Connector 1 (Jusb1)
EAX-R680P User’s Manual 2.3.21 USB connector 1 (JUSB1) Signal PIN PIN Signal USB_14P USB_13P USB_14N USB_13N +V5A_USBD-E +V5A_USBD-E 2.3.22 USB connector (JUSB2) Signal USB_P6 USB_N6 +V5A_USB5-6 30 EAX-R680P User’s Manual... -
Page 31: Usb Connector 4 (Jusb4)
User’s Manual 2.3.23 USB connector 4 (JUSB4) Signal Signal USB_12P USB_11P USB_12N USB_11N +5A_USBB-C +5A_USBB-C 2.3.24 J1RS2 connector (J1RS2) Signal PIN PIN Signal A422RX- A422RX+ A485TX+ A485TX- EAX-R680P User’s Manual 31... -
Page 32: J1Rs3 Connector (J1Rs3)
EAX-R680P User’s Manual 2.3.25 J1RS3 connector (J1RS3) Signal PIN PIN Signal B422RX- B422RX+ B485TX+ B485TX- 2.3.26 Auxiliary Fan connector (AUXFAN1) Signal +12V AUX_R_FANIN 32 EAX-R680P User’s Manual... -
Page 33: Jpc1 Connector (Jpc1) **The Original Setting Is Not Allowed To Be Changed By User
User’s Manual 2.3.27 JPC1 connector (JPC1) **The original setting is not allowed to be changed by user** Signal PIN PIN Signal VCCCORE_nPMALERT VCCCORE_PMSDA VCCCORE_PMSCL +V3.3_EXT 2.3.28 Speaker connector (SPK1) Signal LSPK+ LSPK- RSPK+ RSPK- EAX-R680P User’s Manual 33... -
Page 34: S/Pdif Connector (Jspdif1)
EAX-R680P User’s Manual 2.3.29 S/PDIF connector (JSPDIF1) Signal SPDIF_OUT 2.3.30 FAUD1 connector (FAUD1) Signal PIN PIN Signal MIC2_LIN MIC2_RIN ACZ_DET# LINE2_RIN MIC2_JD SENSE_B LINE2_LIN LINE2_JD 34 EAX-R680P User’s Manual... -
Page 35: Jespi1 Connector (Jespi1)
2.3.31 JESPI1 connector (JESPI1) Signal PIN PIN Signal ESPI_ALERT# ESPI_RST# ESPI_CS1# ESPI_DEG_CLK ESPI_IO3 ESPI_CS# ESPI_IO2 PLT_RST#_BUF ESPI_IO1 +V3P3A ESPI_IO0 2.3.32 REAR1 connector (REAR1) Signal PIN PIN Signal MIC1_JD LINE1_JD AMP_DIS_JD MIC1_LIN MIC1_RIN LINE1_LIN LINE1_RIN FRONT_LIN FRONT_RIN EAX-R680P User’s Manual 35... -
Page 36: 10Gfan1 Connector (10Gfan1)
Signal PIN PIN Signal NDCDC# NRXDC NTXDC NDTRC# NDSRC# NRTSC# NCTSC# NRIC# NDCDD# NRXDD NTXDD NDTRD# NDSRD# NRTSD# NCTSD# NRID# NDCDE# NRXDE NTXDE NDTRE# NDSRE# NRTSE# NCTSE# NRIE# NDCDF# NRXDF NTXDF NDTRF# NDSRF# NRTSF# NCTSF# NRIF# 36 EAX-R680P User’s Manual... -
Page 37: Bios Setup
User’s Manual 3.BIOS Setup EAX-R680P User’s Manual 37... -
Page 38: Introduction
If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 38 EAX-R680P User’s Manual... -
Page 39: Using Setup
Note: Some of the navigation keys differ from one screen to another. To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “” pointer marks all sub menus. EAX-R680P User’s Manual 39... -
Page 40: Getting Help
BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 40 EAX-R680P User’s Manual... -
Page 41: Bios Setup
<Enter> to accept and enter the sub-menu. 3.6.1 Main Menu This section allows you to record some basic hardware configurations in your computer and set the system clock. EAX-R680P User’s Manual 41... -
Page 42: System Language
Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. 3.6.2 Advanced Menu This section allows you to configure your CPU and other system devices for basic operation through the following sub-menus. 42 EAX-R680P User’s Manual... -
Page 43: Cpu Configuration
Number of E-cores to enable in each All[Default], processor package. Note: Number of Cores Active Efficient-cores /7/6/5/4/3/2/1/0 and E-cores are looked at together. When both are {0,0}, Pcode will enable all cores. Disabled Enable or Disable Hyper-Threading Hyper-Threading Enabled[Default], Technology. EAX-R680P User’s Manual 43... -
Page 44: Efficient-Core Information
EAX-R680P User’s Manual 3.6.2.1.1 Efficient-core Information 3.6.2.1.2 Performance-core Information 44 EAX-R680P User’s Manual... -
Page 45: Cpu - Power Management Control
P-states. Enable/Disable processor Turbo Mode Disabled Turbo Mode (requires EMTTM enabled too). AUTO means Enabled[Default], enabled. Enable/Disable CPU Power Management. Disabled Allows CPU to go to C states when it’s not C states Enabled[Default], 100% utilized. EAX-R680P User’s Manual 45... -
Page 46: Pch-Fw Configuration
AMT BIOS Features Enabled[Default], Setup. Note: This option does not disable Manageability Features in FW. 3.6.2.2.1 AMT Configuration Item Option Description Disabled[Default], Unconfigure ME with resetting MEBx password Unconfigure ME Enabled to default on next boot. 46 EAX-R680P User’s Manual... -
Page 47: Firmware Update Configuration
Enable/Disable Me FW Image Re-Flash function. Enabled 3.6.2.2.3 PTT Configuration Item Option Description Selects TPM device: PTT or dTPM. PTT - dTPM[Default], TPM Device Selection Enables PTT in SkuMgr dTPM 1.2 - Disables PTT in SkuMgr Warning ! PTT/dTPM will be EAX-R680P User’s Manual 47... -
Page 48: Trusted Computing
3.6.2.3 Trusted Computing Item Options Description Enables or Disables BIOS support for security device. Security Device Disabled O.S. will not show Security Device. TCG EFI protocol and Support Enabled[Default], INT1A interface will not available. 3.6.2.4 ACPI Settings 48 EAX-R680P User’s Manual... -
Page 49: Super Io Configuration
Set Parameters of Serial Port 3 (COMC). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COMF). EAX-R680P User’s Manual 49... -
Page 50: Serial Port 1 Configuration
3.6.2.5.1 Serial Port 1 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 3.6.2.5.2 Serial Port 2 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 50 EAX-R680P User’s Manual... -
Page 51: Serial Port 3 Configuration
3.6.2.5.3 Serial Port 3 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], RS232[Default] UART 232 422 485 RS422 Set COM Port as RS232, RS422 or RS485 mode. RS485 3.6.2.5.4 Serial Port 4 Configuration EAX-R680P User’s Manual 51... -
Page 52: Serial Port 5 Configuration
Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 3.6.2.5.5 Serial Port 5 Configuration Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 3.6.2.5.6 Serial Port 6 Configuration 52 EAX-R680P User’s Manual... -
Page 53: Nct6126D Hw Monitor
User’s Manual Item Option Description Disabled Serial Port Enable or Disable Serial Port (COM). Enabled[Default], 3.6.2.6 NCT6126D HW Monitor 3.6.2.6.1 Smart Fan Configuration EAX-R680P User’s Manual 53... -
Page 54: S5 Rtc Wake Settings
Avalue Smart Fan Mode Select: Mode 01 to Mode SYS FAN Mode /Mode 10/Mode 11 20 Or Manual (No Smart Fan) /Mode 12/Mode 13 /Mode 14/Mode 15 /Mode 16/Mode 17 /Mode 18/Mode 19 /Mode 20 3.6.2.7 S5 RTC Wake Settings 54 EAX-R680P User’s Manual... -
Page 55: Serial Port Console Redirection
Select Dynamic Time, System will wake on Dynamic Time the current time + Increase minute(s). 3.6.2.8 Serial Port Console Redirection Item Options Description Disabled[Default], Console Redirection Console Redirection Enable or Disable. Enabled Disabled[Default], Console Redirection EMS Console Redirection Enable or Disable. Enabled EAX-R680P User’s Manual 55... -
Page 56: Usb Configuration
Mass storage device emulation type. ‘AUTO’ Auto[Default] Floppy enumerates devices according to their media format. Optical drives are emulated as ‘CDROM’, Mass Storage Devices Forced FDD Hard Disk drives with no media will be emulated according CD-ROM to a drive type. 56 EAX-R680P User’s Manual... -
Page 57: Network Stack Configuration
User’s Manual 3.6.2.10 Network Stack Configuration Item Options Description Disabled[Default], Network Stack Enable/Disable UEFI Network Stack. Enabled 3.6.2.11 NVMe Configuration EAX-R680P User’s Manual 57... -
Page 58: Chipset
EAX-R680P User’s Manual 3.6.3 Chipset 3.6.3.1 System Agent (SA) Configuration Item Option Description Disabled VT-d VT-d capability Enabled[Default] 58 EAX-R680P User’s Manual... -
Page 59: Memory Configuration
User’s Manual 3.6.3.1.1 Memory Configuration 3.6.3.1.2 Graphics Configuration Item Option Description Auto[Default] Select which of IGFX/PEG Graphics Primary Display IGFX device should be Primary Display. PEG/PCIE GTT Size Select the GTT Size 8MB[Default] EAX-R680P User’s Manual 59... -
Page 60: Dmi/Opi Configuration
EAX-R680P User’s Manual 3.6.3.1.3 DMI/OPI Configuration 3.6.3.1.4 VMD Configuration Item Option Description Disabled[Default] Enable VMD controller Enable/Disable to VMD controller Enabled 60 EAX-R680P User’s Manual... -
Page 61: Pci Express Configuration
Control the PCI Express Root Port. Enabled[Default], Disabled[Default] Set the ASPM Level: Force L0s - Force all ASPM links to L0s State AUTO - BIOS auto configure DISABLE - Disables ASPM L0sL1 L1 Substates Disabled PCI Express L1 Substates settings.L1SS EAX-R680P User’s Manual 61... -
Page 62: Pci Express Slot 1 (Peg1)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4/Gen5 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. 62 EAX-R680P User’s Manual... -
Page 63: Pci Express Slot 2 (Peg2)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4/Gen5 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. EAX-R680P User’s Manual 63... -
Page 64: Pch-Io Configuration
EAX-R680P User’s Manual 3.6.3.2 PCH-IO Configuration 3.6.3.2.1 PCI Express Configuration 64 EAX-R680P User’s Manual... -
Page 65: Pci Express Slot 1 (Pci-E Port 21~24)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. EAX-R680P User’s Manual 65... -
Page 66: Pci Express Slot 2 (Pci-E Port 25~28)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. 66 EAX-R680P User’s Manual... -
Page 67: Pci Express Slot 3 (Pci-E Port 1~4)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. EAX-R680P User’s Manual 67... -
Page 68: Pci Express Slot 4 (Pci-E Port 5~6)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. 68 EAX-R680P User’s Manual... -
Page 69: Intel I225/I226 Lan Chip (Pci-E Port 7)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. EAX-R680P User’s Manual 69... -
Page 70: Intel I225/I226 Lan Chip (Pci-E Port 8)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. 70 EAX-R680P User’s Manual... -
Page 71: Intel X550-At2 Lan Chip (Pci-E Port 9~12)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. EAX-R680P User’s Manual 71... -
Page 72: Keym 1 (Pci-E Port 13~16)
PCIe Speed /Gen1/Gen2 Configure PCIe Speed /Gen3/Gen4 The number of milliseconds reference code will wait for link to exit Detect state for Detect Timeout enabled ports before assuming there is no device and potentially disabling the port. 72 EAX-R680P User’s Manual... -
Page 73: Sata And Rst Configuration
Test Mode Enable/Disable (Loop Back). Disabled[Default], Disabled SATA Port Enable or Disable SATA Port Enabled[Default], Hard Disk Drive[Default], Identify the SATA port is connected to Solid SATA Device Type Solid State Drive State Drive or Hard Disk Drive EAX-R680P User’s Manual 73... -
Page 74: Hd Audio Configuration
Control Detection of HD-Audio device. Disabled HD Audio Disabled = HDA will be unconditionally disabled Enabled[Default], Enabled = HDA will be unconditionally enabled. 3.6.3.3 Board Configuration Item Option Description Disabled[Default], ErP Function ErP Function (Deep S5). Enabled 74 EAX-R680P User’s Manual... -
Page 75: Security
Enable/Disable USB Standby Power during S3/S4/S5 Enabled[Default], Disabled[Default], Case Open Warning Enable/Disable Case Open Warning. Enabled Disabled[Default], SHOW DMI INFO SHOW DMI INFO Enabled 3.6.4 Security Item Description Administrator Set Administrator Password Password User Password Set User Password EAX-R680P User’s Manual 75... -
Page 76: Secure Boot
The mode change requires platform reset Secure Boot mode options: Standard or Custom. In Standard Custom mode, Secure Boot Policy variables can be Secure Boot Mode Custom[Default], configured by a physically present user without full authentication 3.6.5 Boot 76 EAX-R680P User’s Manual... -
Page 77: Save & Exit
65535(0xFFFF) means indefinite waiting. On[Default] Bootup NumLock State Select the keyboard NumLock state. Disabled[Default] Quiet Boot Enable or disable Quiet Boot option. Enabled Boot Option Sets the system boot order 3.6.6 Save & Exit EAX-R680P User’s Manual 77... -
Page 78: Save Changes And Reset
BIOS setting. 3.6.6.4 Launch EFI Shell from filesystem device Attempts to Launch EFI Shell application (Shellx64.efi) from one of the available filesystem devices. 3.6.7 MEBx Item Description Intel(R) ME Password MEBx Login 78 EAX-R680P User’s Manual... -
Page 79: Drivers Installation
User’s Manual 4. Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. EAX-R680P User’s Manual 79... -
Page 80: Install Chipset Driver
Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step1. Click Next. Step 3. Click Install. Step 2. Click Accept. Step 4. Complete setup. 80 EAX-R680P User’s Manual... -
Page 81: Install Vga Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 1. Click Begin installation. Step 3. Click Start. Step 4. Click Finish to complete setup. Step 2. Click I agree. EAX-R680P User’s Manual 81... -
Page 82: Install Me Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next Step 1. Click Next to continue setup. Step 4. Click Finish to complete the Step 2. Click Next. setup 82 EAX-R680P User’s Manual... -
Page 83: Install Audio Driver (For Realtek Alc888S Hd Audio)
All drivers can be found on the Avalue Official Website: http://www.avalue.com.tw. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 2. Select Finish to complete Step 1. Click Next to Install. Installation. EAX-R680P User’s Manual 83... -
Page 84: Install Lan Driver
Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next. Step 1. Click Install Drivers and Software. Step 4. Click Next. Step 2. Click Next. Step 5. Click Install. 84 EAX-R680P User’s Manual... - Page 85 User’s Manual Step 6. Click Finish to complete setup. EAX-R680P User’s Manual 85...
-
Page 86: Install Rst Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. 86 EAX-R680P User’s Manual... -
Page 87: Install Serial Io Driver
Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. EAX-R680P User’s Manual 87... -
Page 88: Install Ascendingsortnetworkadapterbymac
All drivers can be found on the Avalue Official Website: http://www.avalue.com.tw. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 1. Step 3. Step 2. Step 4. 88 EAX-R680P User’s Manual... -
Page 89: Mechanical Drawing
User’s Manual 5. Mechanical Drawing EAX-R680P User’s Manual 89... -
Page 90: Mechanical Drawing
EAX-R680P User’s Manual 5.1 Mechanical Drawing Unit: mm Unit: mm 90 EAX-R680P User’s Manual... -
Page 91: Recommended Rubber Location
(Avalue p/n: E199RR00086R) will be shipped w/ all standard package, recommended location as shown in the drawing. 2. Thickness: 6.5mm (suitable for the chassis stand-off in this height – measuring from chassis base to the bottom of PCBA) 3. Dimensions: 40*8*6.5 (L*W*H in mm) EAX-R680P User’s Manual 91...
