ECM-ALUC
12th Gen Intel® Core™ Soc BGA Processor 3.5" Micro
Module
User's Manual
Ed – 23 January 2025
st
1
Copyright Notice
Copyright © 2025 Avalue Technology Inc., ALL RIGHTS RESERVED.
Part No: E2047ECAU00R

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECM-ALUC and is the answer not in the manual?

Questions and answers

Summary of Contents for Avalue Technology ECM-ALUC

  • Page 1 ECM-ALUC 12th Gen Intel® Core™ Soc BGA Processor 3.5” Micro Module User’s Manual Ed – 23 January 2025 Copyright Notice Copyright © 2025 Avalue Technology Inc., ALL RIGHTS RESERVED. Part No: E2047ECAU00R...
  • Page 2: Document Amendment History

    ECM-ALUC User’s Manual Document Amendment History Revision Date Comment January 2025 Avalue Initial Release 2 ECM-ALUC User’s Manual...
  • Page 3: Declaration Of Conformity

    For detailed information, please always refer to the electronic user's manual. Copyright Notice © 2025 by Avalue Technology Inc. All rights are reserved. No parts of this manual may be copied, modified, or reproduced in any form or by any means for commercial use without the prior written permission of Avalue Technology Inc.
  • Page 4 ㆍDescription of your software (operating system, version, application software, etc.) ㆍA complete description of the problem ㆍThe exact wording of any error messages To receive the latest version of the user’s manual; please visit our Web site at: www.avalue.com 4 ECM-ALUC User’s Manual...
  • Page 5 On the other hand, if the new product defect is resulting from incorrect configuration or erroneous use by the user instead of any problem of the hardware itself, the customer will also be requested to pay for relevant handling fees. ECM-ALUC User’s Manual...
  • Page 6 Lacking detailed statement of fault steps also makes the problem hard to be identified, sometimes resulting in second-time repairs. 6 ECM-ALUC User’s Manual...
  • Page 7 • Product has been altered or its label of the serial number has been torn off. • Product functionality issues resulting from improper use by the user, unauthorized dismantle or alteration, unfit operation environment, improper maintenance, accident ECM-ALUC User’s Manual...
  • Page 8 If the customer demands an additional maintenance analysis report, a service fee of various level will be charged depending on the warranty status. In case the analysis result shows that the defect attributes to Avalue’s faulty design or process, the analysis fee will be exempted. 8 ECM-ALUC User’s Manual...
  • Page 9 9. Position the power cord so that people cannot step on it. Do not place anything over the power cord. 10. All cautions and warnings on the equipment should be noted. 11. If the equipment is not used for a long time, disconnect it from the power source to ECM-ALUC User’s Manual...
  • Page 10 The equipment has obvious signs of breakage. 14. CAUTION: Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the manufacturer. 15. Equipment intended only for use in a RESTRICTED ACCESS AREA. 10 ECM-ALUC User’s Manual...
  • Page 11 A NOTE provides additional information intended to avoid Note inconveniences during operation. Direct current. Alternating current Stand-by, Power on FCC Certification CE Certification Follow the national requirements for disposal of equipment. Stacking layer limit This side up ECM-ALUC User’s Manual 11...
  • Page 12 ECM-ALUC User’s Manual Fragile Packaging Beware of water damage, moisture-proof Carton recyclable Handle with care Follow operating instructions of consult instructions for use. 12 ECM-ALUC User’s Manual...
  • Page 13 EXPLOSION ou une fuite de liquide ou de gaz inflammable. - UNE BATTERIE soumise à une pression d'air extrêmement basse pouvant entraî ner une EXPLOSION ou une fuite de liquide ou de gaz inflammable. ECM-ALUC User’s Manual 13...
  • Page 14: Table Of Contents

    SIM card slot (J_SIM1) ......................39 2.3.22 General purpose I/O connector (J_GPIO1) ................40 2.3.23 Front Panel connector (F_PANEL1) ..................40 2.3.24 Battery connector (J_BAT1)....................... 41 3. Drivers Installation....................... 42 Install Chipset Driver ....................43 Install VGA Driver ....................44 14 ECM-ALUC User’s Manual...
  • Page 15 Power Control ........................67 4.6.2.9 S5 RTC Wake Settings ......................67 4.6.2.10 USB Configuration ......................... 68 4.6.2.11 Network Stack Configuration ....................69 4.6.2.12 NVMe Configuration ......................69 4.6.3 Chipset............................70 4.6.3.1 System Agent (SA) Configuration ..................70 ECM-ALUC User’s Manual 15...
  • Page 16 Save Changes ........................81 4.6.6.6 Discard Changes ........................81 4.6.6.7 Restore Defaults ........................81 4.6.6.8 Save as User Defaults ......................81 4.6.6.9 Restore User Defaults ......................81 4.6.6.10 Boot override ......................... 81 5. Mechanical Drawing ....................83 16 ECM-ALUC User’s Manual...
  • Page 17: Getting Started

    Item Description Q’ty ECM-ALUC Motherboard SATA Cable SATA Power Cable DB9M COM Cable Note: Before using the motherboard power, ensure the power pinout, cables, and voltage match to avoid equipment damage. ECM-ALUC User’s Manual 17...
  • Page 18: Manual Objectives

    We strongly recommend that you study this manual carefully before attempting to set up ECM-ALUC or change the standard configurations. Whilst all the necessary information is available in this manual, we would recommend that unless you are confident, you contact your supplier for guidance.
  • Page 19: System Specifications

    1 x M.2 Key-M 2280 (PCIe x4/SATA) slot for storage NVMe/SATA SSD *Default PCIe x4. Storage 1 x M.2 Key-M 2280 (PCIe x4/SATA) slot for storage NVMe/SATA SSD *Default PCIe x4. SATA 1 x SATA III (blue color connector) Edge I/O ECM-ALUC User’s Manual 19...
  • Page 20 2 x 4 pin, pitch 2.00mm Wafer for Front panel (F_PANEL1, white color connector) 1 x 2 pin, pitch 1.25mm Wafer horizontal type connector for CR2032 (J_BAT1) RTC Battery (-20~60C Battery) Battery 3V/220mAh 85mm CR2032 Lithium Coin Cell AT/ATX Only support ATX model, No HW and BIOS AT model 20 ECM-ALUC User’s Manual...
  • Page 21 1 x Intel® i226V 2.5 Gigabit Ethernet Controller (Only support 1G) LAN Chipset 1 x Intel® WGI219V Gigabit Ethernet Controller LAN1: Intel® I226V 10/100/1000 Base-Tx GbE compatible LAN Spec. LAN2: Intel® WGI219V 10/100/1000 Base-Tx GbE compatible ECM-ALUC User’s Manual 21...
  • Page 22 4. Test Axis: X,Y and Z axis Vibration Test 5. 30 min. per each axis 6. IEC 60068-2-64 Test:Fh Random Vibration Operation Reference IEC60068-2-64 Testing procedures Test Fh : Vibration broadband random Test 1. PSD: 0.00454G²/Hz, 1.5 Grms 2. Operation mode 22 ECM-ALUC User’s Manual...
  • Page 23 1 One corner, three edges, six faces 2 ISTA 2A, IEC-60068-2-32 Test:Ed Windows 10 IoT Enterprise 2021 LTSC, Windows 10 (21H2), OS Information Windows 11 (21H2) or later, Linux Kernel 5.17 or later Note: Specifications are subject to change without notice. ECM-ALUC User’s Manual 23...
  • Page 24: Architecture Overview-Block Diagram

    ECM-ALUC User’s Manual 1.5 Architecture Overview—Block Diagram The following block diagram shows the architecture and main components of ECM-ALUC. 24 ECM-ALUC User’s Manual...
  • Page 25: Hardware Configuration

    User’s Manual 2. Hardware Configuration ECM-ALUC User’s Manual 25...
  • Page 26: Product Overview

    ECM-ALUC User’s Manual 2.1 Product Overview Note: Before using the motherboard power, ensure the power pinout, cables, and voltage match to avoid equipment damage. 26 ECM-ALUC User’s Manual...
  • Page 27: Jumper And Connector List

    3 x 2 header, pitch 2.54mm Connectors Label Function Note Line-out & Mic-in audio jack R_USB1/2/3 6 x USB3.2 Gen1 connector DP++1 DP connector M.2 KEY-B 2242/3042/3052 M.2_KEYB_SSD/WWAN1 connector M.2_KEYM_PCIESSD1 M.2 KEY-M 2280 connector M.2_KEYE_WLAN1 M.2 KEY-E 2230 connector ECM-ALUC User’s Manual 27...
  • Page 28 6 x 1 wafer, pitch 1.25mm J_GPIO1 General purpose I/O connector 5 x 2 wafer, pitch 2.00mm F_PANEL1 Front Panel connector 4 x 2 wafer, pitch 2.00mm J_BAT1 Battery connector 2 x 1 wafer, pitch 1.25mm 28 ECM-ALUC User’s Manual...
  • Page 29: Setting Jumpers & Connectors

    User’s Manual 2.3 Setting Jumpers & Connectors 2.3.1 Clear CMOS (CLR_CMOS1) Normal* Clear CMOS * Default 2.3.2 LVDS VDD Select Jumper (JC_LVDS1) +3.3V* +12V * Default ECM-ALUC User’s Manual 29...
  • Page 30: Power Debug Connector (J_Prm1)

    ECM-ALUC User’s Manual 2.3.3 Power Debug connector (J_PRM1) Signal IMVP_PE VCCIN_SCL VCCIN_SDA 2.3.4 SYS fan connector (SYS_FAN1) Signal VCC12S SIO_FANTAC2 SIO_FANCTL2 30 ECM-ALUC User’s Manual...
  • Page 31: Cpu Fan Connector (Cpu_Fan1)

    User’s Manual 2.3.5 CPU fan connector (CPU_FAN1) Signal VCC12S SIO_FANTAC1 SIO_FANCTL1 2.3.6 Serial port 1 connector (J_COM1) Signal PIN1_COM1 COM_DSR#1 COM_SIN1 COM_RTS#1 COM_SOUT1 COM_CTS#1 COM_DTR#1 PIN9_COM1 ECM-ALUC User’s Manual 31...
  • Page 32: Serial Port 2 Connector (J_Com2)

    ECM-ALUC User’s Manual 2.3.7 Serial port 2 connector (J_COM2) Signal PIN1_COM2 COM_DSR#2 COM_SIN2 COM_RTS#2 COM_SOUT2 COM_CTS#2 COM_DTR#2 PIN9_COM2 2.3.8 Serial port 3 connector (J_COM3) Signal COM3_RXD COM3_TXD 32 ECM-ALUC User’s Manual...
  • Page 33: Serial Port 4 Connector (J_Com4)

    User’s Manual 2.3.9 Serial port 4 connector (J_COM4) Signal COM4_RXD COM4_TXD 2.3.10 Serial port 5 connector (J_COM5) Signal COM5_RXD COM5_TXD ECM-ALUC User’s Manual 33...
  • Page 34: Serial Port 6 In Rs-232 Mode (J_Com6)

    ECM-ALUC User’s Manual 2.3.11 Serial port 6 in RS-232 mode (J_COM6) Signal COM6_RXD COM6_TXD 2.3.12 Serial port 6 in RS-485 mode (J_COM6_1) Signal COM6_RS485+ COM6_RS485- 34 ECM-ALUC User’s Manual...
  • Page 35: Speaker Connector (J_Spk1)

    User’s Manual 2.3.13 Speaker connector (J_SPK1) Signal SPK_OUT_P SPK_OUT_N 2.3.14 USB2.0 connector (F_USB1) Signal PIN PIN Signal VCC5 VCC5 USB2.0_1- USB2.0_2- USB2.0_1+ USB2.0_2+ ECM-ALUC User’s Manual 35...
  • Page 36: Usb2.0 Connector (F_Usb2)

    Signal PIN PIN Signal VCC5 VCC5 USB2.0_1- USB2.0_2- USB2.0_1+ USB2.0_2+ 2.3.16 SATA Power connector (P_SATA1) Signal VCC12S VCC5S Note: Before using the motherboard power, ensure the power pinout, cables, and voltage match to avoid equipment damage. 36 ECM-ALUC User’s Manual...
  • Page 37: I2C Connector (J_I2C1)

    User’s Manual 2.3.17 I2C connector (J_I2C1) Signal TCH_I2C0_SDA TCH_I2C0_SCL TCH_RST_N TCH_INT_N VCC3P3S 2.3.18 ESPI connector (J_ESPI1) Signal PIN PIN Signal ESPI_IO0_SIO VCC3P3A ESPI_IO1_SIO ESPI_IO2_SIO ESPI_CLK_SIO ESPI_IO3_SIO ESPI_CS0_N VCC3P3S ESPI_ALERT0_N ESPI_RST0_N ECM-ALUC User’s Manual 37...
  • Page 38: Lvds Connector (Lvds1)

    LVDS connector (LVDS1) Signal PIN PIN Signal LVDS_DA_P3 38 LVDS_B_DATA3+ LVDS_DA_N3 LVDS_B_DATA3- EDP1_HPD_C LVDS_CLKA_P 27 LVDS_B_CLK+ LVDS_CLKA_N 25 LVDS_B_CLK- LVDS_DA_P2 22 LVDS_B_DATA2+ LVDS_DA_N2 LVDS_B_DATA2- LVDS_DA_P1 16 LVDS_B_DATA1+ LVDS_DA_N1 LVDS_B_DATA1- LVDS_DA_P0 PIN10 LVDS_DA_N0 PIN8 VDD_PANEL VDD_PANEL LVDS_PRSNT# VDD_PANEL VDD_PANEL 38 ECM-ALUC User’s Manual...
  • Page 39: Lvds Backlight Control Connector (Lvds_P1)

    User’s Manual 2.3.20 LVDS Backlight Control connector (LVDS_P1) Signal LVDS_BKLTCTL LVDS _BKLT_EN VCC12S VCC12S 2.3.21 SIM card slot (J_SIM1) Signal UIM1_PWR UIM1_DAT UIM1_CLK UIM1_RST UIM1_VPP ECM-ALUC User’s Manual 39...
  • Page 40: General Purpose I/O Connector (J_Gpio1)

    General purpose I/O connector (J_GPIO1) Signal PIN PIN Signal +3.3V SIO_GPI77 SIO_GPI76 SIO_GPI75 SIO_GPI74 SIO_GPI73 SIO_GPI72 SIO_GPI71 SIO_GPI70 2.3.23 Front Panel connector (F_PANEL1) Signal PIN PIN Signal PWR- RESET+ PWR+ RESET- PWR LED- HDD_LED- PWR LED+ HDD_LED+ 40 ECM-ALUC User’s Manual...
  • Page 41: Battery Connector (J_Bat1)

    User’s Manual 2.3.24 Battery connector (J_BAT1) Signal VCC_RTC ECM-ALUC User’s Manual 41...
  • Page 42: Drivers Installation

    Enter to find all the relevant software, utilities, and documentation. (For reference only) Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 42 ECM-ALUC User’s Manual...
  • Page 43: Install Chipset Driver

    Windows 10 operation system. If the warning message appears while the installation process, click Continue to go on. Step 3. Click Install. Step1. Click Next. Step 4. Click Finish to complete setup. Step 2. Click Accept. ECM-ALUC User’s Manual 43...
  • Page 44: Install Vga Driver

    Windows 10 operation system. Step 3. Click Accept. Step 1. Click Begin installation. Step 4. Click Start. Step 5. Click Finish to complete setup. Step 2. Click I agree. 44 ECM-ALUC User’s Manual...
  • Page 45: Install Me Driver

    Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Finish to complete setup. Step 2. Click Next. ECM-ALUC User’s Manual 45...
  • Page 46: Install Audio Driver

    All drivers can be found on the Avalue Official Website: www.avalue.com. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 3. Click Finish to complete setup. Step 1. Click Next. Step 2. Click Install. 46 ECM-ALUC User’s Manual...
  • Page 47: Install Serial Io Driver

    Windows 10 operation system. Step 3. Click Next. Step 1. Click Next to continue installation. Step 4. Click Next. Step 2. Click Next. Step 5. Click Finish to complete setup. ECM-ALUC User’s Manual 47...
  • Page 48: Install Ethernet Driver

    All drivers can be found on the Avalue Official Website: www.avalue.com. Step 3. Setup completed. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 1. Click Install Drivers. Step 2. Click OK. 48 ECM-ALUC User’s Manual...
  • Page 49: Install Intel_Isst Driver

    All drivers can be found on the Avalue Official Website: www.avalue.com. Note: The installation procedures and screen shots in this section are based on Windows 10 operation system. Step 1. Click Next. Step 2. Setup completed. ECM-ALUC User’s Manual 49...
  • Page 50: Bios Setup

    ECM-ALUC User’s Manual 4.BIOS Setup 50 ECM-ALUC User’s Manual...
  • Page 51: Introduction

    If the message disappears before you respond and you still wish to enter Setup, restart the system to try again by turning it OFF then ON or pressing the "RESET" button on the system case. You may also restart by simultaneously pressing <Ctrl>, <Alt>, and <Delete> keys. ECM-ALUC User’s Manual 51...
  • Page 52: Using Setup

    Note: Some of the navigation keys differ from one screen to another. • To Display a Sub Menu Use the arrow keys to move the cursor to the sub menu you want. Then press <Enter>. A “➢” pointer marks all sub menus. 52 ECM-ALUC User’s Manual...
  • Page 53: Getting Help

    BIOS Vendor and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. ECM-ALUC User’s Manual 53...
  • Page 54: Bios Setup

    Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com) to download the latest product and BIOS information. 54 ECM-ALUC User’s Manual...
  • Page 55: Advanced Menu

    Options Description Enabled[Default], Enable/Disable processor Turbo Mode (requires Turbo Mode Disabled EMTTM enabled too). AUTO means enabled. Intel (VMX) Virtualization Disabled When enabled, a VMM can utilize the additional Technology Enabled[Default] hardware capabilities provided by Vanderpool ECM-ALUC User’s Manual 55...
  • Page 56: Efficient-Core Information

    Eanble/Disable Intel® Speed Shift Technology Enabled[Default], Intel® Speed Shift Technology support. Enabling will expose the CPPC v2 Disabled interface to allow for hardware controlled P-states. Disabled, Hyper-Threading Enable or Disable Hyper-Threading Technology. Enabled[Default] 4.6.2.1.1 Efficient-core Information 4.6.2.1.2 Performance-core Information 56 ECM-ALUC User’s Manual...
  • Page 57: Config Tdp Configurations

    0= no custom override. For 12.50w, enter 12500. Overclocking SKU: Power Limit 1/2 Value must be between Max and Min Power Limits (specified by PACKAGE_POWER_SKU_MSR). Other SKUs: This value must be between Min Power Limit and Processor Base Power ECM-ALUC User’s Manual 57...
  • Page 58: Pch-Fw Configuration

    Custom value for Turbo Activation Ration. ConfigTDP Turbo Activation Needs to be configured with valid values Ratio from LFM to Max Turbo. 0 means don’t use custom value. 4.6.2.2 PCH-FW Configuration 4.6.2.3 Trusted Computing 58 ECM-ALUC User’s Manual...
  • Page 59: Acpi Settings

    Hibernate (OS/S4 Sleep State). This option Enabled[Default], may not be effective with some OS. Select the highest ACPI sleep state the Suspend Disabled, ACPI Sleep State system will enter when the SUSPEND button S3 (Suspend to RAM)[Default] is pressed. ECM-ALUC User’s Manual 59...
  • Page 60: Super Io Configuration

    Set Parameters of Serial Port 3 (COMC). Serial Port 4 Configuration Set Parameters of Serial Port 4 (COMD). Serial Port 5 Configuration Set Parameters of Serial Port 5 (COME). Serial Port 6 Configuration Set Parameters of Serial Port 6 (COMF). 60 ECM-ALUC User’s Manual...
  • Page 61: Serial Port 1 Configuration

    4.6.2.5.1 Serial Port 1 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 4.6.2.5.2 Serial Port 2 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled ECM-ALUC User’s Manual 61...
  • Page 62: Serial Port 3 Configuration

    4.6.2.5.3 Serial Port 3 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 4.6.2.5.4 Serial Port 4 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled 62 ECM-ALUC User’s Manual...
  • Page 63: Serial Port 5 Configuration

    Enable or Disable Serial Port (COM). Disabled 4.6.2.5.6 Serial Port 6 Configuration Item Option Description Enabled[Default], Serial Port Enable or Disable Serial Port (COM). Disabled RS232[Default] Change Settings Select an optimal settings for Super IO Device. RS485 DE#/RE ECM-ALUC User’s Manual 63...
  • Page 64: Hardware Monitor

    Full on Mode CPU_FAN1 Mode Automatic Mode[Default], CPU_FAN1 Mode Select. Manual Mode Fan will off when temperature lower than this Fan off temperature limit limit. Fan will work when temperature higher than Fan start temperature limit this limit. 64 ECM-ALUC User’s Manual...
  • Page 65 Fan will work when temperature higher than Fan start temperature limit this limit. Fan start PWM Fan will start with this PWM value. 1 PWM 2 PWM PWM SLOPE SETTING PWM SLOPE Selection. 3 PWM 4 PWM ECM-ALUC User’s Manual 65...
  • Page 66: Display Configuration

    1440x900 24 Dual 1366x768 24 Single 1366x768 18 Single LCD Panel Type Select LCD Panel Type. 1280x1024 24 Dual 1280x1024 18 Dual 1024x768 24 Single[Default] 1920x1080 24 Dual 1024x600 24 Single 1024x600 18 Single 800x600 24 Single 66 ECM-ALUC User’s Manual...
  • Page 67: Power Control

    Specify what state to got to when power is re-applied PowerOn after PowerFail Power Off after a power failure (G3 state). Last State Instant-Off[Default] Soft-Off by PWR-BTTN Soft-Off by PWR-BTTN. Delay 4 Sec. 4.6.2.9 S5 RTC Wake Settings ECM-ALUC User’s Manual 67...
  • Page 68: Usb Configuration

    Maximum time the device will take before it Auto[Default] properly reports itself to the Host Controller. Device power-up delay ‘Auto’ uses default value: for a Root port it is Manual 100ms, for a Hub port the delay is taken form 68 ECM-ALUC User’s Manual...
  • Page 69: Network Stack Configuration

    Optical drives are emulated as ‘CDROM’, drives with no media will be Hard Disk CD-ROM emulated according to a drive type. 4.6.2.11 Network Stack Configuration Item Options Description Enabled Network Stack Enable/Disable UEFI Network Stack. Disabled[Default] 4.6.2.12 NVMe Configuration ECM-ALUC User’s Manual 69...
  • Page 70: Chipset

    ECM-ALUC User’s Manual 4.6.3 Chipset 4.6.3.1 System Agent (SA) Configuration 70 ECM-ALUC User’s Manual...
  • Page 71: Memory Configuration

    IGFX Select which of IGFX/PEG/PCI Graphics device Primary Display PEG Slot should be Primary Display Or select HG for PCH PCI Hybrid Gfx. Auto[Default] Internal Graphics Disabled Keep IGFX enabled based on the setup options. Enabled ECM-ALUC User’s Manual 71...
  • Page 72: Vmd Setup Menu

    Enabled[Default] BIOS assignment. This is enabled automatically assignment Disabled when Aperture Size is set to 2048MB. 4.6.3.1.3 VMD setup menu Item Option Description Disabled[Default] Enable VMD controller Enable/Disable to VMD controller. Enabled 4.6.3.1.4 PCI Express Configuration 72 ECM-ALUC User’s Manual...
  • Page 73: Pch-Io Configuration

    User’s Manual 4.6.3.1.4.1 M.2_KEYM_PCIESSD1 Item Option Description Enabled[Default], M.2_KEYM_PCIESSD1 Control the PCI Express Root Port. Disabled Auto Gen1 Gen2 PCIe Speed Configure PCIe Speed. Gen3 Gen4[Default] Gen5 4.6.3.2 PCH-IO Configuration ECM-ALUC User’s Manual 73...
  • Page 74: Pci Express Configuration

    I2C Touch Panel Disabled connected to this SerialIO controller. 4.6.3.2.1 PCI Express Configuration 4.6.3.2.1.1 LAN1 Item Option Description Enabled[Default], LAN1 Control the PCI Express Root Port. Disabled Auto[Default] Gen1 PCIe Speed Configure PCIe Speed. Gen2 Gen3 74 ECM-ALUC User’s Manual...
  • Page 75 User’s Manual 4.6.3.2.1.2 M.2_KEYE_WLAN1 Item Option Description Enabled[Default], M.2_KEYE_WLAN1 Control the PCI Express Root Port. Disabled Auto[Default] Gen1 PCIe Speed Configure PCIe Speed. Gen2 Gen3 4.6.3.2.1.3 M.2_KEYB_SSD/WWAN1 ECM-ALUC User’s Manual 75...
  • Page 76: Sata Configuration

    Configure PCIe Speed. Gen2 Gen3 4.6.3.2.2 SATA Configuration Item Options Description Enabled[Default] SATA Controller(s) Enable/Disable SATA Device. Disabled, SATA Mode Selection AHCI[Default] Determines how SATA controller(s) operate. Enabled[Default] Port 1 Enable or Disable SATA Port. Disabled 76 ECM-ALUC User’s Manual...
  • Page 77: Security

    User’s Manual 4.6.4 Security ⚫ Administrator Password Set setup Administrator Password ⚫ User Password Set User Password 4.6.4.1 Secure Boot ECM-ALUC User’s Manual 77...
  • Page 78: Key Management

    Platform Key(PK) is enrolled and the System is in User Enabled mode. The mode change requires platform reset. Secure Boot mode selector: Standard/Custom. In Standard Secure Boot Mode Custom mode Secure Boot Variables can be configured Custom[Default] without authentication. 4.6.4.1.1 Key Management 78 ECM-ALUC User’s Manual...
  • Page 79: Boot

    Factory Key Provision the platform reset and while the System is in Enabled Setup mode. 4.6.5 Boot Item Option Description Number of seconds to wait for setup activation Setup Prompt Timeout 1~ 65535 key. 65535(0xFFFF) means indefinite waiting. ECM-ALUC User’s Manual 79...
  • Page 80: Save And Exit

    Set the system boot order. 4.6.6 Save and Exit 4.6.6.1 Save Changes and Exit Use the save changes and reset option to save the changes made to the BIOS options and to exit the BIOS configuration setup program. 80 ECM-ALUC User’s Manual...
  • Page 81: Discard Changes And Exit

    This option restores all BIOS settings to the user defaults. This option is useful for restoring previously preserved custom BIOS setup configurations. 4.6.6.10 Boot override This option lists all possible bootable devices and allows the user to override the Boot ECM-ALUC User’s Manual 81...
  • Page 82 If BIOS setup options have been changed and saved, a reboot will be required and the boot override selection will not be valid. 82 ECM-ALUC User’s Manual...
  • Page 83: Mechanical Drawing

    User’s Manual 5. Mechanical Drawing ECM-ALUC User’s Manual 83...
  • Page 84 ECM-ALUC User’s Manual Unit: mm 84 ECM-ALUC User’s Manual...
