Avalue Technology ESM-CN700 Series User Manual

Onboard via eden v4 1 ghz som-etx cpu module
Hide thumbs

Advertisement

Quick Links

Download this manual
ESM-CN700 Series
Onboard VIA Eden V4 1 GHz SOM-ETX CPU Module
User's Manual
st
1
Ed – 26 October 2006
Part No. 2047274100R

Advertisement

loading
Need help?

Need help?

Do you have a question about the ESM-CN700 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Avalue Technology ESM-CN700 Series

Summary of Contents for Avalue Technology ESM-CN700 Series

  • Page 1 ESM-CN700 Series Onboard VIA Eden V4 1 GHz SOM-ETX CPU Module User’s Manual Ed – 26 October 2006 Part No. 2047274100R...
  • Page 2 For detailed information, please always refer to the electronic user's manual. Copyright Notice Copyright © 2007 Avalue Technology Inc., ALL RIGHTS RESERVED. No part of this document may be reproduced, copied, translated, or transmitted in any form or by any means, electronic or mechanical, for any purpose, without the prior written permission of the original manufacturer.

  • Page 3: Life Support Policy

    User’s Manual Disclaimer Avalue Technology Inc. reserves the right to make changes, without notice, to any product, including circuits and/or software described or contained in this manual in order to improve design and/or performance. Avalue Technology assumes no responsibility or liability for the...
  • Page 4 Room 909, 9F, Section B, No.900, Suite 210, 200 Tornillo Way, Yisan Road, Caohejing Hi-tech Park, Tinton Falls, NJ 07712 Shanghai 200233, China Tel : +86-21-5423-4170 Tel: +1-732-578-0200 Fax : +86-21-5423-4171 Fax: +1-732-578-0250 http://www.avalue.com.tw http://www.avalue.com.tw E-mail: service.china@avalue.com.tw E-mail: service.usa@avalue.com.tw 4 ESM-CN700 Series User’s Manual...
  • Page 5 A product returned without proof of the purchase date is not eligible for warranty service. 5. Write the RMA number visibly on the outside of the package and ship it prepaid to your dealer. ESM-CN700 Series User’s Manual 5...

  • Page 6: Table Of Contents

    Signal Description – ETX Connector X4 (ETX1D) ................. 43 BIOS Setup........................45 Starting Setup ......................46 Using Setup ......................47 Getting Help ......................48 In Case of Problems....................48 Main Menu ......................49 3.5.1 Standard CMOS Features......................50 3.5.2 Advanced BIOS Features ......................52 6 ESM-CN700 Series User’s Manual...
  • Page 7 Memory Address Error at ......................92 Memory parity Error at ........................92 MEMORY SIZE HAS CHANGED SINCE LAST BOOT ..............92 Memory Verify Error at ........................92 OFFENDING ADDRESS NOT FOUND ..................92 ESM-CN700 Series User’s Manual 7...
  • Page 8 Keyboard is locked out - Unlock the key..................94 Keyboard error or no keyboard present..................94 Manufacturing POST loop......................94 BIOS ROM checksum error - System halted................. 94 Memory test fail..........................94 POST Codes ..........................95 8 ESM-CN700 Series User’s Manual...

  • Page 9: Getting Started

    1 x ESM-CN700 Onboard VIA Eden V4 1 GHz SOM-ETX CPU Module 1 x Quick Installation Guide 1 x CD-ROM contains the followings: — User’s Manual (this manual in PDF file) — VGA drivers and utilities — Audio drivers and utilities — Ethernet driver and utilities ESM-CN700 Series User’s Manual 9...

  • Page 10: Document Amendment History

    ESM-CN700 Series 1.3 Document Amendment History Revision Date Comment Oct. 2006 Lingo Tsai Initial Release Jun. 2007 Lingo Tsai Logo Changed 10 ESM-CN700 Series User’s Manual...

  • Page 11: Manual Objectives

    User’s Manual 1.4 Manual Objectives This manual describes in detail the Avalue Technology ESM-CN700 SOM-ETX CPU Module. We have tried to include as much information as possible but we have not duplicated information that is provided in the standard IBM Technical References, unless it proved to be necessary to aid in the understanding of this board.

  • Page 12: System Specifications

    CRT + LVDS, or TV out + LVDS, or CRT + TV out Dual Independent Display AGP 8x VGA/LCD interface VGA/LCD Interface Dual-channel 18/24-bit LVDS LVDS VIA VT1622A TV encoder supports both NTSC/PAL TV-Out Supports both S-video and composite video 12 ESM-CN700 Series User’s Manual...
  • Page 13 Mechanical & Environmental AT/ATX Power Type 0~60° C (32~140° F) Operation Temperature 0%~90% relative humidity, non-condensing Operating Humidity 4.5" x 3.7” (114 mm x 95 mm) Size ( L x W ) 0.22 lbs (0.1 Kg) Weight ESM-CN700 Series User’s Manual 13...

  • Page 14: Architecture Overview

    ESM-CN700 Series 1.6 Architecture Overview 1.6.1 Block Diagram The following block diagram shows the architecture and main components of ESM-CN700. The following sections provide detail information about the functions provided onboard. 14 ESM-CN700 Series User’s Manual...

  • Page 15: Via Cn700 And Vt8237R

    VESA DPMS (Display Power Management Signaling) CRT power-down is supported. Coupled with the VT8237R Plus South Bridge chip, a complete power conscious PC main board can be implemented with no external glue logic. ESM-CN700 Series User’s Manual 15...
  • Page 16 (CRT-only) configuration. In the value system configurations, the external AGP upgrade capability is not normally required by the system, allowing all the AGP pins to be used for implementing very flexible display functions. 16 ESM-CN700 Series User’s Manual...

  • Page 17: Via Vt1616 Audio Codec

    When used with a 3.3V analog supply, power consumption is further reduced. The primary applications for this part are desktop and portable personal computers multimedia subsystems. However, it is suitable for any system requiring 6-channel audio output for home theater systems at competitive prices. ESM-CN700 Series User’s Manual 17...

  • Page 18: Via Vt1636 Lvds Transmitter

    525p progressive scan output. The Macrovision anticopy process provides a means to deter the unauthorized copying of copy protected analog video signals onto a videocassette. All features are software programmable through a serial bus interface that provides read/write access to all registers. 18 ESM-CN700 Series User’s Manual...

  • Page 19: Ethernet

    UARTs perform asynchronous communication; One VFIR interface compliant with IrDA; One MIDI interface; One game port with built-in 558 and buffer chips to support direct connect of 2 joysticks; One Hardware Monitor; and Seven GPIO ports (56 GPIO pins). ESM-CN700 Series User’s Manual 19...

  • Page 20: Ite It8888G Pci To Isa Bridge

    The Serial IRQ is also implemented in the device for sending and receiving ISA IRQs & IOCHCK#. The device includes an ISA interface which supports full ISA compatible functions. The IT8888G is available in 160-pin TFBGA package. 20 ESM-CN700 Series User’s Manual...

  • Page 21: Hardware Configuration

    User’s Manual 2. Hardware Configuration ESM-CN700 Series User’s Manual 21...

  • Page 22: Product Overview

    ESM-CN700 Series 2.1 Product Overview 22 ESM-CN700 Series User’s Manual...

  • Page 23: Installation Procedure

    Window must be entered and configured correctly to match the particular system configuration. 7. If TFT panel display is to be utilized, make sure the panel voltage is correctly set before connecting the display cable and turning on the power. ESM-CN700 Series User’s Manual 23...

  • Page 24: Main Memory

    1GB. DIMM1 Make sure to unplug the power supply before adding or removing SODIMMs or other system components. Failure to do so may cause severe damage to both the board and the components. 24 ESM-CN700 Series User’s Manual...
  • Page 25 (2) Static electricity can damage the electronic components of the computer or optional boards. Before starting these procedures, ensure that you are discharged of static electricity by touching a grounded metal object briefly. ESM-CN700 Series User’s Manual 25...

  • Page 26: Jumper And Connector List

    Serial ATA connector 2 Serial ATA connector 1 200-pin DDR2 SODIMM socket DIMM1 ETX connector X1 HIROSE FX8-100P-SV ETX1A ETX connector X2 HIROSE FX8-100P-SV ETX1B ETX connector X3 HIROSE FX8-100P-SV ETX1C ETX connector X4 HIROSE FX8-100P-SV ETX1D 26 ESM-CN700 Series User’s Manual...

  • Page 27: Setting Jumpers & Connectors

    Pin Definition – ETX Connecter X1 (ETX1A) Signal Signal PCICLK3 PCICLK4 PCICLK1 PCICLK2 REQ3# GNT3# GNT2# +3.3V REQ2# GTN1# REQ1# +3.3V GNT0# SERIRQ REQ0# (Rear side) +3.3V CBE0# AD10 AUXAL AD11 AD12 AUXAR AD13 ASVCC AD14 SNDL AD15 ASGND CBE1# SNDR ESM-CN700 Series User’s Manual 27...
  • Page 28 USB3- IRDY# STOP# FRAME# USB2 AD16 CBE2# AD17 USB3 (Rear side) AD19 AD18 AD20 USB0# AD22 AD21 AD23 USB1# AD24 CBE3# AD25 AD26 AD28 USB0 AD27 AD29 AD30 USB1 PCIRST# AD31 INTC# INTD# INTA# INTB# 28 ESM-CN700 Series User’s Manual...

  • Page 29: Signal Description - Etx Connector X1 (Etx1A)

    Cycle Frame of PCI Buses. This indicates the beginning and duration of a PCI FRAME# access. The access will be either an output driven by the Northbridge on behalf of the CPU, or an input during PCI master access. ESM-CN700 Series User’s Manual 29...
  • Page 30 Analog supply voltage for sound controller. This is an output which is used for ASVCC production test only. Do not make external connections to this pin. 30 ESM-CN700 Series User’s Manual...

  • Page 31: Etx Connector X2 (Etx1B)

    MASTER# SD12 DREQ7 SD11 DACK7# SD10 DREQ6 DACK6# DREQ5 MEMW# DACK5# MEMR# DREQ0 LA17 DACK0# LA18 IRQ14 (Rear side) LA19 IRQ15 LA20 IRQ12 LA21 IRQ11 LA22 IRQ10 LA23 IO16# SBHE# M16# BALE DACK2# IRQ3 IRQ4 ESM-CN700 Series User’s Manual 31...
  • Page 32 ESM-CN700 Series Signal Signal IRQ5 IRQ6 IRQ7 SYSCLK SA10 REFSH# SA11 DREQ1 SA12 DACK1# SA13 DREQ3 SA14 DACK3# (Rear side) SA15 IOR# SA16 IOW# SA18 SA17 SA19 SMEMR# IOCHRDY SMEMW# NOWS# DREQ2 IRQ9 IOCHK# RSTDRV 32 ESM-CN700 Series User’s Manual...

  • Page 33: Signal Description - Etx Connector X2 (Etx1B)

    SMEMW# is active for all memory write cycles to address below 1MB. I/O read instructs an I/O device to drive its data onto the data bus. It may be IOR# driven by the CPU or by the DMA controller. IOR# is inactive (high) during refresh cycles. ESM-CN700 Series User’s Manual 33...
  • Page 34 16 bit width. REFSH# is pulled low whenever a refresh cycle is initiated. A refresh cycle is REFSH# activated every 15.6 us in order to prevent loss of DRAM data. 34 ESM-CN700 Series User’s Manual...
  • Page 35 16-bit I/O adapters and system memory. DRQ4 is not available externally. All DRQ pins have pull-up resistors on the CPU modules. DACK DMA acknowledge 0..3 and 5.7 are used to acknowledge DMA requests. They [0, 1, 2, 3, 5, 6, 7]# are active-low. ESM-CN700 Series User’s Manual 35...
  • Page 36 IRQ3 through IRQ7 have the lowest priority (IRQ7 is the lowest). An interrupt request is generated when an IRQ line is raised from low to high. The line must be held high until the CPU acknowledges the interrupt request (interrupt service routine). 36 ESM-CN700 Series User’s Manual...

  • Page 37: Etx Connector X3 (Etx1C)

    ETX Connector X3 (ETX1C) Signal Signal DDCK DDDA E_Txclk# E_Txout3# E_Txclk E_Txout3 E_Txout1 E_Txout2 E_Txout1# E_Txout2# Txout3# E_Txout0 (Rear side) Txout3 E_Txout0# Txout2# Txclk Txout2 Txclk# Txout0 Txout1 Txout0# Txout1# C_DAT C _CLK ENBKL# BIASON DIGON SYNC ESM-CN700 Series User’s Manual 37...
  • Page 38 ESM-CN700 Series Signal Signal STB# AFD# IRRX ERR# IRTX RXD2 INIT# RTS2# DTR2# SLIN# DCD2# (Rear side) DSR2# CTS2# TXD2# RI2# RXD1 ACK# RTS1# BUSY# DTR1# DCD1# SLCT# DSR1# MSCLK CTS1# MSDAT TXD1 KBCLK RI1# KBDAT 38 ESM-CN700 Series User’s Manual...

  • Page 39: Signal Description - Etx Connector X3 (Etx1C)

    DCD1#, DCD2# signal is detected by the modem. This active-low input is for serial port. Handshake signals are use to notify the DSR1#, DSR2# UART that the modem is ready to establish the communication link. ESM-CN700 Series User’s Manual 39...
  • Page 40 This active-low signal is used to initiate the printer when low. SLIN# This active-low signal selects the printer. This active-low output from the printer indicates that it has received the previous ACK# data and that it is ready to receive new data. 40 ESM-CN700 Series User’s Manual...

  • Page 41: Etx Connector X4 (Etx1D)

    PWRBTN# BATT KBINH LILED RSMRST# ACTLED SPEEDLED I2CLK OVCR# EXTSMI# I2DAT SMBCLK SMBDATA (Rear side) SIDE_CS3# SMBALRT# SIDE_CS1# NCDASP_S SIDE_A2 PIDE_CS3# SIDE_A0 PIDE_CS1# PDIAG_S PIDE_A2 SIDE_A1 PIDE_A0 SIDE_INTRQ PIDE_A1 SIDE_AK# PIDE_INTRQ SIDE_RDY PIDE_AK# SIDE_IOR# PIDE_RDY ESM-CN700 Series User’s Manual 41...
  • Page 42 P IDE_D0 SIDE_D1 PIDE_D14 SIDE_D13 PIDE_D1 SIDE_D2 PIDE_D13 SID E_D12 PIDE_D2 SIDE_D3 PIDE_D12 (Rear side) SIDE_D11 PIDE_D3 SIDE_D4 PIDE_D11 SIDE_D10 PIDE_D4 SIDE_D5 PIDE_D10 SIDE_D9 PIDE_D5 SIDE_D6 PIDE_D9 SIDE_D8 PIDE_D6 GPE2# RXD# PIDE_D8 SIDE_D7 TXD# PIDE_D7 HDRST# 42 ESM-CN700 Series User’s Manual...

  • Page 43: Signal Description - Etx Connector X4 (Etx1D)

    IDE device that the available Write Data is already asserted by the IDE SIDE_IOW# Busmaster in PIO and DMA mode. In Ultra-33 mode, this pin has different functions. PIDE_INTRQ/ Interrupt request signal from the IDE device. SIDE_INTRQ HDRST# Low-active hardware reset (RSTDRV inverted). ESM-CN700 Series User’s Manual 43...
  • Page 44 Resume Reset input. This input may be driven low by external circuitry in order to RSMRST# reset the power management logic on the ETX module. System management interrupt input. May be driven low by external circuitry to EXTSMI initiate an SMI. 44 ESM-CN700 Series User’s Manual...

  • Page 45: Bios Setup

    User’s Manual 3 BIOS Setup Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. ESM-CN700 Series User’s Manual 45...

  • Page 46: Starting Setup

    If you do not press the keys at the correct time and the system does not boot, an error message will be displayed and you will again be asked to. Press F1 to Continue, DEL to enter SETUP 46 ESM-CN700 Series User’s Manual...

  • Page 47: Using Setup

    Save all the CMOS changes, only for Main Menu • Navigating Through The Menu Bar Use the left and right arrow keys to choose the menu you want to be in. Note: Some of the navigation keys differ from one screen to another. ESM-CN700 Series User’s Manual 47...

  • Page 48: Getting Help

    Award and your systems manufacturer to provide the absolute maximum performance and reliability. Even a seemingly small change to the chipset setup has the potential for causing you to use the override. 48 ESM-CN700 Series User’s Manual...

  • Page 49: Main Menu

    Note: The BIOS setup screens shown in this chapter are for reference purposes only, and may not exactly match what you see on your screen. Visit the Avalue website (www.avalue.com.tw) to download the latest product and BIOS information. ESM-CN700 Series User’s Manual 49...

  • Page 50: Standard Cmos Features

    CGA 80 MONO All Errors No Errors Select the situation in which you want the BIOS Halt On All, but Keyboard to stop the POST process and notify you All, but Diskette All, but Disk/Key 50 ESM-CN700 Series User’s Manual...
  • Page 51 **** Warning: Setting a value of 65535 Precomp Max = 65535 means no hard disk Min = 0 Landing zone **** Max = 65535 Min = 0 Sector Number of sectors per track Max = 255 ESM-CN700 Series User’s Manual 51...

  • Page 52: Advanced Bios Features

    3.5.2.1 CPU Feature This item allows you to select the CPU feature. Item Option Description 4 Min 8 Min Delay Prior to Thermal 16 Min 32 Min 52 ESM-CN700 Series User’s Manual...
  • Page 53 No warning message will appear when anything attempts to access the boot sector or Disabled hard disk partition table. 3.5.2.4 CPU L1 & L2 Cache This item allows you to speed up memory access. However, it depends on CPU design. Item Description Enabled Enable cache Disabled Disable cache ESM-CN700 Series User’s Manual 53...
  • Page 54 USB CDROM Device USB-HDD USB Hard Disk Device Legacy LAN Network Device Disabled Disabled any boot device 3.5.2.9 Boot Other Device This item allows you to enable the system to boot from other device. Item Description 54 ESM-CN700 Series User’s Manual...
  • Page 55 Multi-Processor Specification (MPS) that the board will use. The choice: 1.4, 1.1. 3.5.2.17 OS Select for DRAM > 64MB Select the operating system that is running with greater than 64MB of RAM on the system. Item Description ESM-CN700 Series User’s Manual 55...
  • Page 56 Enable OS for over 64 MB DRAM 3.5.2.18 Video BIOS Shadow To allow copying Video BIOS into shadow RAM to improve video performance. Item Description Enable Copy Video BIOS into shadow RAM Disable Do not copy Video BIOS into shadow RAM 56 ESM-CN700 Series User’s Manual...
  • Page 57 3.5.2.20 Small Logo (EPA) Show This item allows you enabled/disabled the small EPA logo show on screen at the POST step. Item Description Enabled EPA Logo show is enabled Disabled EPA Logo show is disabled ESM-CN700 Series User’s Manual 57...

  • Page 58: Advanced Chipset Features

    Such a scenario might well occur if your system had mixed speed DRAM chips installed so that greater delays may be required to preserve the integrity of the data held in the slower memory chips. 58 ESM-CN700 Series User’s Manual...
  • Page 59 (Twr) to set the timing by dram SPD. 2T Command DRAM Command Rate Allows to set the DRAM Command Rate. 1T Command Manual RDSAIT mode Auto RDSAIT selection Key in a HEX number (Min = 0000, Max = 003F) ESM-CN700 Series User’s Manual 59...
  • Page 60 1024x768 1x24B 1024x768 2x24B 1280x768 1x24B 1280x1024 2x24B 1400x1050 2x24B 1600x1200 2x24B Outport Port DI0, DI1 This item allows you to select the outport port. Dithering Enabled, Disabled This item allows you to enable dithering. 60 ESM-CN700 Series User’s Manual...
  • Page 61 This item allows you to select the input HDTV_type HDTV 1080I resolution of HDTV HDTV 1080P R / G / B This item allows you to select the input HDTV_Connector Pr / Y / Pb connector of HDTV ESM-CN700 Series User’s Manual 61...
  • Page 62 The feature is to toggle the V-Link bus mode between the VLink 8X Support Disabled original V-Link and the newer and faster 8X V-Link. Slowest This item allows you to set the DDRY timing. DDRY_Timing Default Optimize 62 ESM-CN700 Series User’s Manual...
  • Page 63 Item Description Enabled Cacheable Disabled Non-Cacheable 3.5.3.7 PCI Slot, AGP This item allows you to decide to active whether PCI Slot or Onboard/AGP first. The choices: PCI Slot, Onboard, AGP, PCIE Slot. ESM-CN700 Series User’s Manual 63...

  • Page 64: Integrated Peripherals

    ESM-CN700 Series 3.5.4 Integrated Peripherals Use this menu to specify your settings for integrated peripherals. 3.5.4.1 VIA OnChip IDE Device 64 ESM-CN700 Series User’s Manual...
  • Page 65 If the IDE hard drive supports block Enabled IDE HDD Block Mode mode (most new drives do), select Enabled for Disabled automatic detection of the optimal number of block read/writes per sector the drive can support. ESM-CN700 Series User’s Manual 65...
  • Page 66 OFF: It does not support any USB device on DOS. USB Emulation KB / MS KB/MS: It supports USB legacy keyhoard and mouse except for USB storage. ON: It supports USB legacy keyboard, mouse and storage. 66 ESM-CN700 Series User’s Manual...
  • Page 67 This item is to set the Onboard Fast IR function Onboard Fast IR: Disabled Enabled/ Disabled. 11, 5 Fast IR IRQ: Select a corresponding interrupt for Fast IR. 3, 4 Fast IR DMA: 6, 5 Select a DMA channel for Fast IR. ESM-CN700 Series User’s Manual 67...

  • Page 68: Power Management Setup

    HDD Power Down There are three selections for Power Management Option; both of them have fixed mode settings. The choices: Disabled, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10, 11, 12, 13, 14, 15 Min. 68 ESM-CN700 Series User’s Manual...
  • Page 69 This item is to set whether to run VGABIOS if S3 resume. The choices: Auto, Yes, No 3.5.5.11 Ac Loss Auto Restart: This item is to set whether to run Ac Loss Auto Restart. The choices: Off, On, Former-Sts. ESM-CN700 Series User’s Manual 69...
  • Page 70 COM, LPT/COM component is detected. Disabled PowerOn by PCI Card Allows you to set power on by PCI card Enabled Disabled Modem Ring Reume Allows you to resume modem ring Enabled 70 ESM-CN700 Series User’s Manual...
  • Page 71 IRQ activity is detected from any of the Primary INTR enabled channels Off, On IRQ3 ~ IRQ5: Enables or disables the monitoring of the IRQ3 ~ IRQ15 Enabled, Disabled specified IRQ line. These fields are only available if “Primary INTR” is on. ESM-CN700 Series User’s Manual 71...

  • Page 72: Pnp / Pci Configuration

    Plug and Play operating system such as Windows®95. If you set this field to “manual” choose specific resources by going into each of the sub menu that follows this field (a sub menu is preceded by a “ ”). The choices: Auto(ESCD), Manual. 72 ESM-CN700 Series User’s Manual...
  • Page 73 While the system has one USB controller and more than one USB devices are connected, then “Enabled” is set. If the system USB controller is not used, then “Disabled” is set. The choices: Enabled, Disabled. ESM-CN700 Series User’s Manual 73...

  • Page 74: Pc Health Status

    ESM-CN700 Series 3.5.7 PC Health Status This section shows the status of your CPU. 74 ESM-CN700 Series User’s Manual...

  • Page 75: Frequency / Voltage Control

    3.5.8.3 Spread Spectrum This item is to adjust extreme values of the pulse for EMI test. The choices: Enabled, Disabled. 3.5.8.4 CPU Clock This item allows you to select the CPU clock. The choices: 100~132Mhz ESM-CN700 Series User’s Manual 75...

  • Page 76: Load Fail-Safe Defaults

    While Award has designed the custom BIOS to maximize performance, the factory has the right to change these defaults to meet their needs. Press <Y> to load the default values setting for optimal performance system operations. 76 ESM-CN700 Series User’s Manual...

  • Page 77: Set Supervisor / User Password

    Type the password, up to eight characters in length, and press <Enter>. The password typed now will clear any previously entered password from CMOS memory. You will be asked to confirm the password. Type the password again and press <Enter>. You may also ESM-CN700 Series User’s Manual 77...
  • Page 78 Features Setup Menu and its Security option (see Section 3). If the Security option is set to “System”, the password will be required both at boot and at entry to Setup. If set to “Setup”, prompting only occurs when trying to enter Setup 78 ESM-CN700 Series User’s Manual...

  • Page 79: Save & Exit Setup

    Setup selection stored in CMOS when boot the computer next time. The system is restarted after saving the values. 3.5.13 Exit Without Save Abandon all CMOS value changes and exit setup, and the system is restarted after exiting. ESM-CN700 Series User’s Manual 79...

  • Page 80: Drivers Installation

    ESM-CN700 Series 4 Drivers Installation Note: Installation procedures and screen shots in this section are for your reference and may not be exactly the same as shown on your screen. 80 ESM-CN700 Series User’s Manual...

  • Page 81: Install Chipset Driver (For Via Cn700)

    Step 3. Select I Agree and click Next to the following step. Step 4. Select both items and click Next to Step 1. Locate 「\Driver_Audio\VIA\CN700\ run the setup. VIA_HyperionPro_V508A\setup.exe」. Step 2. Click Next. Step 5. Click Next. ESM-CN700 Series User’s Manual 81...
  • Page 82 ESM-CN700 Series Step 6. Click Next. Step 7. Click Finish to restart the PC. 82 ESM-CN700 Series User’s Manual...

  • Page 83: Install Display Driver (For Via Cn700)

    Note: The installation procedures and screen shots in this section are based on Windows XP operation system. Step1. Locate 「\Driver_Chipset\VIA \CN700\P4M800CE_16944451_XP _wIShld_logod\Setup.exe」. Step 2. Setup will run the installation automatically, then click Finish to complete. ESM-CN700 Series User’s Manual 83...

  • Page 84: Install Audio Driver (For Via Vt1616)

    Next to the following step. Step 4. Click Continue Anyway to run the Step 1. Locate 「\Driver_Audio\VIA\VT1616 setup. \A1u590b\setup.exe」. Step 2. Click Next. Step 5. Click Finish to complete the setup and restart the PC. 84 ESM-CN700 Series User’s Manual...

  • Page 85: Install Ethernet Driver (For Realtek Rtl810X, Rtl813X Family)

    Step 3. Click Yes to continue the based on Windows XP operation installation. system. Step 1. Locate \Driver_Network\Realtek\ Step 4. Click Finish to complete the RTL810x_813X Family\Setup.exe. setup. Step 2. Setup executing. ESM-CN700 Series User’s Manual 85...

  • Page 86: Measurement Drawing

    ESM-CN700 Series 5 Measurement Drawing 86 ESM-CN700 Series User’s Manual...
  • Page 87 User’s Manual Unit: mm ESM-CN700 Series User’s Manual 87...

  • Page 88: Appendix A: Bios Revisions

    ESM-CN700 Series Appendix A: BIOS Revisions BIOS Rev. New Features Bugs/Problems Solved Known Problems 88 ESM-CN700 Series User’s Manual...

  • Page 89: Appendix B: Award Bios Post Messages

    User’s Manual Appendix B: AWARD BIOS POST Messages ESM-CN700 Series User’s Manual 89...

  • Page 90: Overview

    Then reboot the system. DISKETTE DRIVES OR TYPES MISMATCH ERROR - RUN SETUP Type of diskette drive installed in the system is different from the CMOS definition. Run Setup to reconfigure the drive type correctly. 90 ESM-CN700 Series User’s Manual...

  • Page 91: Display Switch Is Set Incorrectly

    Cannot find or initialize the floppy drive controller. Make sure the controller is installed correctly and firmly. If there are no floppy drives installed, be sure the Diskette Drive selection in Setup is set to NONE. ESM-CN700 Series User’s Manual 91...

  • Page 92: Invalid Eisa Configuration Please Run Eisa Configuration Utility

    ERROR messages when the segment that has caused the problem cannot be isolated. 19. OFFENDING SEGMENT: This message is used in conjunction with the I/O CHANNEL CHECK and RAM PARITY ERROR messages when the segment that has caused the problem has been isolated. 92 ESM-CN700 Series User’s Manual...
  • Page 93 EISA Configuration Utility. 26. SYSTEM HALTED, (CTRL-ALT-DEL) TO REBOOT ... Indicates the present boot attempt has been aborted and the system must be rebooted. Press and hold down the CTRL and ALT keys and press DEL. ESM-CN700 Series User’s Manual 93...
  • Page 94 This is also used for M/B burn in test. 38. BIOS ROM checksum error - System halted. The checksum of ROM address F0000H-FFFFFH is bad. 39. Memory test fail. BIOS reports the memory test fail if the onboard memory is tested error. 94 ESM-CN700 Series User’s Manual...
  • Page 95 Use walking 1’s algorithm to check out interface in CMOS circuitry. Also set real-time clock power status, and then check for override. Reserved Program chipset default values into chipset. Chipset default values are MODBINable by OEM customers. ESM-CN700 Series User’s Manual 95...
  • Page 96 1. Program CPU internal MTRR (P6 & PII) for 0-640K memory address. 2. Initialize the APIC for Pentium class CPU. 3. Program early chipset according to CMOS setup. Example: onboard IDE controller. 4. Measure CPU speed. 5. Invoke video BIOS. Reserved Reserved Reserved 96 ESM-CN700 Series User’s Manual...
  • Page 97 3. Initialize the APIC for P6 class CPU. 4. On MP platform, adjust the cacheable range to smaller one in case the cacheable ranges between each CPU are not identical. Reserved Initialize USB ESM-CN700 Series User’s Manual 97...
  • Page 98 1. Assign resources to all ISA PnP devices. 2. Auto assign ports to onboard COM ports if the corresponding item in Setup is set to “AUTO”. Reserved 1. Initialize floppy controller 2. Set up floppy related fields in 40:hardware. Reserved Reserved Reserved 98 ESM-CN700 Series User’s Manual...
  • Page 99 5. Invoke ISA adapter ROMs 6. Assign IRQs to PCI devices 7. Initialize APM 8. Clear noise of IRQs. Reserved Reserved Reserved Reserved Reserved Reserved Reserved Read HDD boot sector information for Trend Anti-Virus code ESM-CN700 Series User’s Manual 99...
  • Page 100 1. Update keyboard LED & typematic rate 1. Build MP table 2. Build & update ESCD 3. Set CMOS century to 20h or 19h 4. Load CMOS time into DOS timer tick 5. Build MSIRQ routing table. Boot attempt (INT 19h) 100 ESM-CN700 Series User’s Manual...
