SECTION 7
[CHASSIS-A UNIT]
REF PART
NO. NO.
W1 8920001880 CAB-1210
W2 8920003150 CAB-1382
W3 8920003160 CAB-1383
W5 8920003090 CAB-1376
MP1 8210031920 3589 FRONT PANEL (G)
MP2 8310093800 3589 WINDOW PLATE (H)
MP3 8930089751 3589 WINDOW SHEET-1
MP4 8930093860 3589 2-KEY (J)
MP5 8930093870 3589 2-KEY (K)
MP6 8610014730 KNOB N-418
MP8 8930084370 3405 LENS
MP9 8830003400 PIPE NUT M6 NI
MP10 8930051500 O-RING (AB)
MP12 8810009561 PH BT M2×6 NI-ZK3
MP13 8010023661 3825 CHASSIS-1
MP14 8930089500 3589 FRONT SEAL
MP15 8110010570 3589 U-COVER
MP16 8110010580 3589 L-COVER
MP17 8930089490 3589 MAIN SEAL
MP18 8930089690 3589 BUSH PLATE
MP20 8930089470 O-RING (CW)
MP22 8810008661 PH BT M3×8 NI-ZC3
MP23 8810009461 FLAT M3×8 ZK3
MP28 8930090310 SPONGE (MY)
MP30 8930093730 O-RING (CZ)
MP34 8810009511 PH BT M2×4 NI-ZC3 (3.6-4.0)
MP37 8930089480 3589 BUSH RUBBER
[MAIN-A UNIT]
REF PART
NO. NO.
S501* 2260003060 NANOSMDC016F-2
T951* 5910001180 ATPL-361R
MP1* 8510022870 3825 CPU CASE
MP2 8510022810 3825 CPU COVER
MP3* 8510022880 3825 SDRAM CASE
MP4 8510022820 3825 SDRAM COVER
MP5* 8510022890 3825 SHIELD CASE
[DISPLAY-C UNIT]
REF PART
NO. NO.
DS101 5030004540 882BH01042
S1* 2230001110 SKRPACE010
S2* 2230001110 SKRPACE010
S3* 2230001110 SKRPACE010
S4* 2230001110 SKRPACE010
MP1 8930100470 3589 A-LCD HOLDER
MP2 8210029840 3589 REFLECTOR
MP3 8930089880 3589 WHITE SHEET
[DISPLAY-D UNIT]
REF PART
NO. NO.
J1 6450002210 3017-8821
S1 2250000851 RH7NWBPHE20A-13F-3594
S2* 2260003180 MINISMDC050F-2
W1 8900016120 OPC-1683 (P0.5N50L80)
W2 8900012862 OPC-1305B
EP2* 3310004500 AH212M245001-T
MP1 8930095190 3825 EARTH SPRING
*: Refer to "BOARD LAYOUTS" for the location.
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head BS: Brass NI: Nickel ZU: Zinc SUS: Stainless

MECHANICAL PARTS

DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
DESCRIPTION QTY.
[ACCESSORIES]
REF PART
NO. NO.
1
F1 5210000061 FGB 5A PBF (FGB0 125V)
1
1
2
MC1 – HM-241
1
W1 8900022500 OPC-2414
1
1
1
EP1 6510019510 R2-6
1
EP2 0800016040 AA.162.501111.IB
1
EP3 3310005270 TC-821B-3M-RPSMA (M)
2
1
1
MOBIL BRACKET (See page 8-2 for details)
4
MP7 8810005841 PH A M5×20 ZC3
1
MP8 8810000471 PH M5×12 (+−) ZC3
1
MP9 8850000150 FLAT WASHER M 5 NI BS
1
MP10 8850000391 S-WASHER M5 ZC3
1
MP11 8830000121 NUT M5 ZC3
2
MP12 8950006871 2917 MIC HANGER-1
3
MP13 8810004700 PH A M3×16 SUS
3
MP14 8930098090 SPONGE (PI)
7
MP15 8930098100 INSULATION SHEET (OK)
8
Sold as an option.
†
2
3
3
1
MC1
1
1
1
1
1
1
1
EP2
1
MP14
1
1
1
1
MP7
1
1
1
MP9
1
1
1
1
1
1
1
7-1
DESCRIPTION
†
MOBILE BRACKET
EP3
W1
MP12
MP15 F1
MP8
MP10 MP11
QTY.
2
1
1
2
1
2
1
4
4
4
4
4
1
2
1
1
MP13
EP1
