INTRODUCTION
This service manual describes the latest technical
information for the IP501M IP ADVANCED RADIO
SYSTEM at the time of publication.
MODEL VERSION
IP501M
To upgrade quality, any electrical or mechanical parts and
internal circuits are subject to change without notice or
obligation.
ORDERING PARTS
Be sure to include the following four points when
ordering replacement parts:
1. 10-digit Icom part number
2. Component name
3. Equipment model name and unit name
4. Quantity required
<ORDER EXAMPLE>
1130018740 RX8130CE
8930084370 3405 LENS IP501M
Addresses are provided on the inside back cover for
your convenience.
Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorporated (Japan) in Japan, the United States, the
United Kingdom, Germany, France, Spain, Russia, Australia, New Zealand, and/or other countries.
VERSION
NUMBER
USA-31 #31
EXP-41 #41
AUS-51 #51
TRANSCEIVER
IP501M
IP501M MAIN-A UNIT 5 pieces
CHASSIS-A 1 piece
SERVICE CAUTION
NEVER connect the transceiver to an AC outlet or
to a DC power supply that outputs more than the
specified voltage. This will ruin the transceiver.
DO NOT expose the transceiver to rain, snow or
liquids.
DO NOT reverse the polarity of the DC power cable
when directly connecting to the transceiver.
DO NOT apply an RF signal of more than 20 dBm
(100 mW) to the antenna connector. This could
damage the transceiver.
MICROPHONE
HM-241
REPAIR NOTES
1. Make sure that the problem is internal before
disassembling the transceiver.
2. DO NOT open the transceiver until the transceiver
is disconnected from its power source.
3. DO NOT keep power ON for a long time when the
transceiver is defective.
4. READ the instructions of the test equipment
thoroughly before connecting it to the transceiver.
