[FRONT-C UNIT]
REF
PART
NO.
NO.
Q3
1590004090 S.TRA LDTC114YET1G
Q4
1590004090 S.TRA LDTC114YET1G
Q5
1590004090 S.TRA LDTC114YET1G
Q6
1590004090 S.TRA LDTC114YET1G
Q7
1520001010 S.TRA 2SB1132G-R-AB3-R
Q8
1590003800 S.TRA KTC811U-GR-RTK/P
Q10
1590004090 S.TRA LDTC114YET1G
D1
1790002170 S.VAR LXES15AAA1-133
D2
1790002170 S.VAR LXES15AAA1-133
D3
1790002170 S.VAR LXES15AAA1-133
D4
1790002170 S.VAR LXES15AAA1-133
R3
7030016560 S.RES RMC1/16SJPTH
R4
7030016560 S.RES RMC1/16SJPTH
R5
7030016020 S.RES RMC1/16S-104JTH (100 k)
R6
7030016020 S.RES RMC1/16S-104JTH (100 k)
R7
7030016020 S.RES RMC1/16S-104JTH (100 k)
R9
7030015970 S.RES RMC1/16S-103JTH (10 k)
R11
7030016560 S.RES RMC1/16SJPTH
R13
7030016480 S.RES RMC1/16S-821JTH (820)
R14
7030016300 S.RES RMC1/16S-332JTH (3.3 k)
R15
7030016020 S.RES RMC1/16S-104JTH (100 k)
R16
7030016300 S.RES RMC1/16S-332JTH (3.3 k)
R17
7030016050 S.RES RMC1/16S-102JTH (1 k)
R18
7030016360 S.RES RMC1/16S-123JTH (12 k)
R19
7030016360 S.RES RMC1/16S-123JTH (12 k)
R20
7030016560 S.RES RMC1/16SJPTH
R21
7030015970 S.RES RMC1/16S-103JTH (10 k)
R27
7030016050 S.RES RMC1/16S-102JTH (1 k)
R28
7030015970 S.RES RMC1/16S-103JTH (10 k)
R29
7030015970 S.RES RMC1/16S-103JTH (10 k)
R30
7030016080 S.RES RMC1/16S-822JTH (8.2 k)
R31
7030016080 S.RES RMC1/16S-822JTH (8.2 k)
R32
7030016080 S.RES RMC1/16S-822JTH (8.2 k)
R33
7030016080 S.RES RMC1/16S-822JTH (8.2 k)
R39
7030016080 S.RES RMC1/16S-822JTH (8.2 k)
R40
7030016480 S.RES RMC1/16S-821JTH (820)
R41
7030016360 S.RES RMC1/16S-123JTH (12 k)
R42
7030016360 S.RES RMC1/16S-123JTH (12 k)
R51
7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R52
7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R53
7030016420 S.RES RMC1/16S-182JTH (1.8 k)
R54
7030016420 S.RES RMC1/16S-182JTH (1.8 k)
C5
4030022150 S.CER GRM033B31E103KA12D
C6
4030025410 S.CER GRM188B31E105KAADD
Eqv.
4030019120 S.CER GRM188B31E105KA75D
Eqv.
4030025230 S.CER TMK107BJ105KAHT
C7
4030025410 S.CER GRM188B31E105KAADD
Eqv.
4030019120 S.CER GRM188B31E105KA75D
Eqv.
4030025230 S.CER TMK107BJ105KAHT
C8
4030025410 S.CER GRM188B31E105KAADD
Eqv.
4030019120 S.CER GRM188B31E105KA75D
Eqv.
4030025230 S.CER TMK107BJ105KAHT
C9
4030025410 S.CER GRM188B31E105KAADD
Eqv.
4030019120 S.CER GRM188B31E105KA75D
Eqv.
4030025230 S.CER TMK107BJ105KAHT
C10
4030025410 S.CER GRM188B31E105KAADD
Eqv.
4030019120 S.CER GRM188B31E105KA75D
Eqv.
4030025230 S.CER TMK107BJ105KAHT
C11
4030019620 S.CER GRM188B31C225KE14D
C12
4030019620 S.CER GRM188B31C225KE14D
C13
4030019620 S.CER GRM188B31C225KE14D
C14
4030019620 S.CER GRM188B31C225KE14D
C24
4030022150 S.CER GRM033B31E103KA12D
J1
6510029350 S.CON 30P4.0-JMCS-G-B-TF (N)
J2
6510029010 S.CON 20FHSY-RSM1-GAN-TB (LF) (SN) B
DS1
5040004390 S.LED NSSW306GT
DS2
5040003890 S.LED B1931TX--05P-000412
DS3
5040003890 S.LED B1931TX--05P-000412
DS4
5040003790 S.LED SML-522MU8WT86
DS6
5040004390 S.LED NSSW306GT
DS7
5040003890 S.LED B1931TX--05P-000412
DS8
5040003890 S.LED B1931TX--05P-000412
DS9
5040003790 S.LED SML-522MU8WT86
DS10
5040003890 S.LED B1931TX--05P-000412
DS11
5040003890 S.LED B1931TX--05P-000412
DS12
5040003890 S.LED B1931TX--05P-000412
DS13
5040003890 S.LED B1931TX--05P-000412
DS101
5030004540 LCD
882BH01042
S1
2230001110 S.SWI SKRPACE010
S2
2230001110 S.SWI SKRPACE010
S3
2230001110 S.SWI SKRPACE010
S4
2230001110 S.SWI SKRPACE010
Eqv.= This component is equivalent to the REF No. component listed above,
and may be substituted on parts orders and repairs.
.
DESCRIPTION
M
LOCATION
B
B
13.4/17.5
B
B
B
83.0/14.7
B
B
14.9/20.0
T
23.5/16.4
T
T
87.7/15.1
T
B
35.0/10.8
B
B
B
B
B
B
B
B
10.2/20.8
B
B
B
87.5/17.1
B
87.5/18.0
B
86.0/14.5
B
35.0/12.9
B
B
82.3/10.0
B
B
B
15.0/17.5
B
B
B
B
16.5/20.1
B
12.6/20.8
B
85.8/18.0
B
86.6/16.2
T
T
T
80.2/13.9
T
81.2/13.5
B
B
B
B
B
B
B
B
36.2/15.2
B
38.3/14.8
B
36.2/14.0
B
79.9/12.5
B
T
36.5/10.5
T
26.9/13.3
T
T
T
74.7/10.5
T
26.9/18.3
T
T
12.2/19.6
T
T
T
84.3/18.3
T
84.3/13.3
T
26.9/15.8
T
T
84.3/15.8
T
H/V
72.5/6.6
6.0/19.5
6.0/17.5
84.1/9.2
23.5/6.9
87.8/6.9
35.0/6.1
37.4/8.0
38.9/7.4
40.5/6.8
35.9/7.5
37.6/9.5
9.3/20.8
35.0/8.9
11.1/20.8
85.9/8.0
82.4/7.7
83.3/6.8
7.6/19.6
7.6/17.5
71.1/6.9
31.1/7.4
30.2/7.3
38.5/9.0
65.9/1.9
66.6/3.1
67.0/4.3
66.5/5.5
67.0/6.7
64.0/7.0
76.2/11.8
55.6/3.2
84.3/8.8
3.0/19.6
84.3/3.8
26.9/8.8
26.9/3.8
26.9/6.3
84.3/6.3
M.= Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
H/V LOCATION=See the BOARD LAYOUTS for details.
