SECTION 8

BOARD LAYOUTS

• FRONT-C UNIT (B-8944A/B-9169: TOP VIEW)
DS7
S1
DS2
DS10
S2
DS11
8-1
The actual configuration of the PC board can be seen by viewing the top and bottom BOARD LAYOUT pages together.
The serial numbers of transceivers used this PCB.
VERSION PCB
NUMBER NUMBER
#31
B-8944A
#41
B-9169
#51
B-8944A
See the PARTS LIST H/V location on the PARTS LIST for location details.
DS12
S3
DS13
DS3
S4
DS8
SERIAL NUMBERS
Future production
(Plan: 382531001001 and above)
382541001001~382541001100
and
Future production
(Plan: 382541001601 and above)
382541001101~382541001600
Future production
(Plan: 382551001001 and above)
