Specification - SC&T HE02P User Manual

Specification

ITEM NO.
Support
Compliance
Max. Video Resolution
Max. Transmission Distance
Video Bandwidth
Audio Format
Network Bandwidth
IR Support
RS232 Baud Rate
Ports & Interfaces
Video Input
Video Output
Ethernet Interface
RS232 Interface
IR Interface
Power
Power Supply
Power Consumption
Ambient Temperature
Operation
Storage
Humidity
Physical Characteristics
Dimensions
Weight
5
HE02PT
HDMI 1.4, HDCP, DVI
4K@30Hz 4:4:4
100M over CAT6 or greater cable
10.2 Gbps
7.1 LPCM 192KHz, Dolby TrueHD, DTS-HD MA
10/ 100Mbps
30-60Khz, ±15°, 5M, Bi-directional
115200 bps/ Full Duplex
1 x HDMI Type A
1 x HDBaseT
1 x RJ45
1 x DB9 Female
1 x 3.5mm Phone Jack
DC 24V 1A
Regulated
15W (Max), 5W (Low Power) in Total
0 to 55℃
-20 to 85℃
up to 95%
88 x 135 x 30mm
300g
User Manual
HE02PR
30-60Khz, ± 55°,
Bi-directional
1 x HDBaseT
2 x HDMI Type A
1 x RJ45
1 x DB9 Male
1 x 3.5mm Phone Jack
Power from HE02PT
88 x 135 x 30mm
300g
HE02P
5M,
