4.

INSTALLATION

4.1

Design and Use of the Activated Carbon Tower

The CLEARPOINT® V activated carbon tower has been designed, manufactured and tested to be used only to separate oil
aerosol and oil vapor contained in compressed air, any other use is considered to be improper. The manufacturer is not
responsible for any problems arising from the improper use of this machine. The end user, in any and all cases, is
responsible for any resulting damages.
Moreover, the correct use of this machine requires the verification of certain installation conditions, in particular:
+
Pressure, temperature, flow rate and chemical composition of the incoming compressed air
+
Ambient temperatures
The carbon tower is supplied with the only operations left for the end user to: fill the tower with activated carbon and
connect to the plant with the instructions given in this manual.
4.2 Location and Installation
Serious consideration should be given when selecting the installation site for the carbon tower, as an
improper location could directly affect the proper operation of the carbon tower.
This unit is not suitable to be used in explosive atmospheres, where risk of fire could exist, in the presence
of gaseous or solid pollutants or in outdoor applications or areas exposed to the elements.
Do not use water to extinguish fire on the dryer or in the surrounding area.
Machine level noise at the area of installation could be higher than 85 dBA. Install the unit in a dedicated
area where people are not normally present. The installer and/or end user is responsible to install proper
safety signs at the installation site.
Technicians that service the carbon tower in an area with excessive noise must wear hearing and eye
protection while servicing the in an area with. Each employee must select a proper personal protection
device (PPD) hearing protector such as earmuffs, ear canal caps or earplugs in order to prevent permanent
hearing damage or loss.
Minimum Installation Requirements:
+
Select a clean, dry room that is free of dust and protected from atmospheric disturbances.
+
The location must be smooth, horizontally level, able to bear the weight of the carbon tower and vibration free
+
The location area must fall within the ambient conditions as listed on page 6
+
Allow a clearance of at least 3' on all sides of the carbon tower in order easily facilitate all maintenance needs
+
While recommended, the carbon tower is not required to be anchored to the supporting surface
+
An upstream dryer and filtration must be installed
+
The location of an air receiver tank will vary depending on compressor type and application conditions
Incorrect installation may void warranty.
