INSPECTION AND TRANSPORTATION

All activated carbon towers are tested and inspected at the factory prior to shipping. Thoroughly inspect and verify the
integrity of the packaging upon receipt and note any damage on the freight bill. Place the unit as close as possible to the
installation point before unpacking the contents and inspect for concealed damage. Freight claims are to be filed with
the carrier immediately and the manufacturer's technical service department notified thereafter.
+
To move the packaged unit, we suggest the use of a suitable crane or forklift. We do not recommend moving the
unit by any hand operated or manual mechanism.
+
Handle with care. Heavy blows could cause irreparable damage.
+
Even when packaged, keep the machine protected from severe weather.
The packaging materials are recyclable. Each material must be properly disposed in a manner complying
with the rules and regulations of the local municipality government.
3.

TECHNICAL SPECIFICATIONS AND GENERAL FUNCTION

3.1

Technical Data by Model Size

CLEARPOINT® V
Flow Rate
Inlet / Outlet Connection (Flange)
Height (A)
Width (B)
Depth (C)
Adsorbent Material
Total Weight
Maximum Inlet Relative Humidity
Maximum Inlet Oil Aerosol
Content
Minimum Ambient Temperature
Maximum Ambient Temperature
Standard Inlet Air Temperature
Maximum Inlet Air Temperature
Standard Air Pressure
Maximum Air Pressure
Activated carbon tower flow ratings adhere to the following conditions:
+
Inlet Compressed Air Temperature 100 °F (38 °C)
+
Inlet Compressed Air Pressure 100 psig (7 bar)
+
Ambient Air Temperature 100 °F (38 °C)
SCFM is defined as the volume of free air in cubic feet per minute measured at 14.5 psia (1.013 bar) at 68 °F (20 °C)
temperature with 0% relative humidity (0 WVP).
CLEARPOINT® V Series Activated Carbon Tower
1000
Model / Size
1000
scfm
2-1/2"
in.
86
in.
24
in.
27
in.
Activated Carbon
354
lbs.
%
3
mg/m
°F
°F
°F
°F
psig
psig
(Rev. B)
1200 1900
1500
1200 1900
1500
2-1/2" 3"
3"
85 78
90
26 36
28
28 36
29
1/8"
428 536 729
30
0.01
40
120
100
120
100
150
2300 2800
2300 2800
4" 4"
93 83
36 40
35 41
853 1105
6
