2.
INSPECTION AND INSTALLATION
2.1
Incoming Inspection and Transportation
All adsorbers are tested and inspected at the factory prior to shipping. Thoroughly inspect and verify the integrity
of the packaging upon receipt and note any damage on the freight bill. Place the unit as close as possible to the
installation point before unpacking the contents and inspect for concealed damage. Freight claims are to be filed with
the carrier immediately and the manufacturer's technical service department notified thereafter.
To move the packaged unit, we suggest the use of a suitable crane or forklift. We do not recommend moving
+
the unit by any hand operated or manual mechanism.
Handle with care. Heavy blows could cause irreparable damage.
+
Even when packaged, keep the machine protected from severe weather.
+
The packaging materials are recyclable. Each material must be properly disposed in a manner complying
with the rules and regulations of the local municipality government.
3.
TECHNICAL SPECIFICATIONS AND GENERAL FUNCTION
3.1
Technical Data by Model Size
CLEARPOINT V
Flow Rate
Inlet / Outlet Connection
Height (A)
Width (B)
Depth (C)
Adsorbent Material
Total per Adsorber
Maximum Inlet Relative Humidity
Maximum Inlet Oil Aerosol Content
Minimum Ambient Temperature
Maximum Ambient Temperature
Standard Inlet Air Temperature
Maximum Inlet Air Temperature
Standard Air Pressure
Maximum Air Pressure
Model Size
80
scfm
80
in. (NPT) 3/4
in.
58
in.
11
in.
16
Activated Carbon
Lbs.
41
%
mg/m
3
°F
°F
°F
°F
psig
psig
CLEARPOINT V
100 120 160 200 250 300 400 500 650 800
100 120 160 200 250 300 400 500 650 800
1
1
1 ¼ 1 ¼ 1 ½ 1 ½
70
70
70
70
77
11
14
14
16
11
17
19
19
23
17
⅛"
51
51
77
77
127 127 149 225 271 338
30
0.01
40
120
100
120
100
150
Series Activated Carbon Tower
®
2
2
2 ½ 2 ½
77
68
78
74
72
16
17
19
22
24
23
24
26
29
31
(Rev. D)
6
