Compak BOLT User Manual page 29

12.4. REPLACING THE SILICONE
CURTAIN
The silicon curtain ensures regularity in the
dose and reduces static electricity. Located
inside the coffee spout, can be replaced
once the regulator has been removed from
the grinder (Fig. 5). Using a #3 Allen Key,
untighten the three top screws (Fig. 17).
Fig. 17
Using a # 3 Allen key, the screw is loosened
and the curtain support is removed to gain
access to the silicone curtain, being able to
replace it with a new one or of a different
thickness according to the needs of each
coffee. (Fig. 18).
Fig. 18
K09650H00 | PROC-CAL/002/03 USER MANUAL | V. 06/04/2022
12. MAINTENANCE
12.5. BATTERY REPLACEMENT
This grinder has a built-in battery back-up
for saving operating information when the
grinder is shut down. When this battery is
spent, it must be replaced by another of the
same characteristics: CR2032 (Lithium Cell
3V). The battery must be changed when the
grinder does not keep dose times.
The procedure to replace the battery without
losing the operating data stored in the
grinder is as follows:
•
Loosen the tamper, according to (Fig. 19).
Remove the lower aluminium cover by
loosen the 2 screws using a #2.5 Allen key,
according to (Fig. 20).
Fig. 19
Remove the 2 screws that hold the tamper
support with a #5 Allen key, according to
(Fig. 21) loosen the last screw T20 Torx and
pull to remove it (Fig. 22).
Fig. 21
Remove the top screw that hold the plastic
support with a #4 Allen key (Fig. 23) and pull
to remove it (Fig. 24).
Fig. 20
Fig. 22
29
