J3
COM3/4 12/5V select
J3
Part number
Footprint
Description
Setting
(1-2)
(2-3)
EPC-R4710 User Manual
COM5 and COM6 power 12 and 5V level select
1653003101
HD_3x1P_79_D
PIN HEADER 3x1P 2.0 mm (.078 in) 180D(M) DIP 2000-13 WS
Function
5V
12V
