CellCOM Prime 7
* ALWAYS TEST THE UNIT ON SITE BEFORE

Wiring Connections

USB
RVT RVT
RVT RVT
101 101 RVT RVT
8.000
RVT RVT Relay 1
Relay 2
Tip: See the full
manual for more
detail on slave
connections
PROX PCB
12-24v 1 2 3
SLAVE IN
IN
SLAVE
POWER
------------
CONNECTIONS
COMMs
12-24v SLAVE OUT
OUT 1 2 3
ALTERNATIVE WIRING EXAMPLE
Relay
LOCK POWER
SUPPLIES
ARE NOT
INCLUDED AS
2
PART OF THE
KIT.
- Advanced GSM Intercom
INSTALLATION TO AVOID RE-STOCKING FEE *
Tip: All main connections are pre-wired. Below are
Tip: Keypad and
optional wiring additions for 3
Prox are only
available on
selected models
SOLID RED
SOLID RED
Keypad
PWR | COMMs
SLAVE CONNECTIONS
ALTERNATIVE WIRING EXAMPLE
Relay
STRIKE
LOCK
SECONDARY
These diagrams are provided for
guidance only. Please refer to the lock
wiring instructions before connecting.
See full T&C's on our website
rd party controllers.
PCB Status LEDs
= PCB POWERED ON
+BLUE FLASHING = SEARCHING
SOLID RED + BLUE FLASHING + GREEN FLASHING = SUCCESSFULLY CONNECTED
Relay 1
Relay 2
OPEN
DETECT
Exit Button
Gate Position
(optional)
Limit switch
(optional)
MAGNETIC LOCK
SIM ORIENTATION
ALWAYS ensure the system is
switched OFF when adding or
removing your SIM card and ensure
the orientation is correct.

CONNECTION TO NETWORK

4G: Quick Flashing = Standby | Constant ON/OFF =
CHANGE APN (for VoLTE / 4G services)
The system will be pre-programmed with the APN for the
use a different network then the correct APN must be set for full operation.
Check with your network provider for the correct APN for 4G data.
Once you have confirmed the APN enter it in place of 'APNinfo' in an SMS to the intercom.
via SMS
(if connected to network)
1. Power off the unit, then press and hold the call
Ensure the PCB is powered on and connected
to the network with a GREEN flashing LED.
button and power the unit on again.
Then send the below text as an SMS to the 2. Upon power up, a long tone will be emitted from
intercom Sim number. A power reboot is
the speaker and the blue LED will remain solid - it is
required after the 'OK' reply message is
now in the APN setting mode.
received back.
3. After this, enter the APN serial number through
9999#97APNinfo#
the keypad then press #.
(e.g. if you want to set APN No. 18, press 1 - 8, then #.
A long beep will again be heard).
Passcode
APN info
4. Reboot unit.
for SIM
Command
(add APN) network
STILL HAVING TROUBLE?
Find all of our support options such as Web Chat,
Full Manuals, Customer Helpline and more on
our website:
WWW.AESGLOBALONLINE.COM
SIM
MODEM LED
INDICATOR
Searching
Vodafone
network. If you wish to
via Keypad (if no 3G signal)
Contact Technical Support or check our resource page
for a list of the APN serial number.
PB Terminals
24v DC IN
