9.4

Settings

It is possible to change the various time settings for Start, Stop, flush time and Alarm, plus delayed start-up of
pumps.
Use of DIP-switch:
No. 1 Pump
No. 2 Pump
No. 3 Selection of BWT PERMAQ
No. 4-8 Flush time (The seconds added together gives the flush time)

10 TECHNICAL SPECIFICATIONS

10.1 Technical data

BWT PERMAQ ® Compact 41
Capacity *
Maximum water recovery
Hydrophore
(total volume/capacity at 2.7 bar)
Salt retention
Conductivity
Electrical connection:
Electrical frequency/ Hz
Electricity consumption maximum
Pipe inlet
Concentrate outlet, diameter
Permeate outlet pipe
Height x Length x Width
Water temperature (Min. / Max.)
Water pressure (Min. / Max.)
Weight (empty/full)
Number of membranes
* At drinking water quality 10°C, 3 bar, max. 500 mg/l total salt content.
® Compact 41 model
Units
l/h
%
l
μS/cm
μS/cm
V / Hz
kW
inch
mm
inch
mm x mm x mm
ºC
bar
kg
pcs
Values
130
40-75
11 / 3.5
>98
< 50
230 / 50
1.0
¾"
10
¾"
445 x 570 x 295
5 / 25
2 / 7
42 / 45
1
