9.2.11 Settings

It is possible to change the various time settings for Start, Stop and Alarm, plus delayed start-up of pumps.
Use of DIP-switch:
No. 1 High-pressure pump
No. 2 Transport pump
No. 3 Selection of BWT PERMAQ
No. 4-6 Transport pump
10.

TECHNICAL SPECIFICATION

10.1 Technical specifications

Tag number
P1
P2
FI 1
PI 1
V1
V2
Y1
PS 1
PS 2
QIS 1(Option)
®
Compact 51 model
BWT PERMAQ
Designation
High-pressure pump
Transport pump
Flow meter
Manometer
Needle valve
Needle valve
Solenoid valve NC
Pressure switch NO
Pressure switch NC
Conductivity meter
®
Compact
51
Type/data
14 bar, 1x230V, 0.64kW
1x230V, 0.85 kW
Ø20 PVC
0-40 bar, ¼"
Brass
Brass
POM
¼" 0.5 bar
¼" -0.2-8 bar
½" Connection for sensor
