Cleveland (T) MKDL-100-T (-CC) Operator's Manual page 51

MRC 7000 ENABLE MODE
PROCEDURE (1&2 PEN)
For Cook Chill Direct Steam Mixer Kettles
Reference page #36 in the MRC 7000 Installation,
Wiring, Operation Manual, Form 2877, Edition 6,
May 1994 update.
To prevent tampering, your programmer comes
from the factory with the programming modes
turned "oFF ".
If adjustment is required then the modes must be
turned "ON " before they are accessible. We
recommend that when the adjustments have been
completed you turn off the programming modes again.
To turn on the mode required perform the
following steps:
AUTO
MAN
AUTO
MAN
MAN OUT1 OUT2 ALRM
SP
CAL 9900 Controls Drawing
1. Turn MAIN POWER SWITCH to "ON ".
2. Press the scroll key "
3. Press and hold the "
same time. All the display lamps will light.
4. After 10 seconds the display lights will go out
and "EnAb " will be displayed. Release the
" " and " " keys. "EtSt " will appear.
5. Repeatedly press the "
desired mode is displayed.
6. Press the scroll key "
mode's setting ("ON " or "oFF ").
7. Press the " " key to turn the desired mode
"ON ".
8. To turn desired mode "oFF " follow steps 1-5
and then press "
Pen1 key -
AUTO/MAN
SCROLL Key
UP Key
DOWN Key
Pen 2 key -
AUTO/MAN
" until "CtrL" is displayed.
" and " " keys at the
" key until the
" once to display the
" key.
Test
EtSt
Mode
Calibration
ECAL
Mode
Program
EPro
Mode
Tune
Etun
Mode
Manual
ESbY
(Stby)Mode
Setpoint Select
ESPS
Mode (optional)
Setpoint
ESPC
Change
Note: Pressing the up key while
any of the modes are displayed will
exit you from the "EnAb" program.
MRC 7000 Enable Mode Flow Chart
Press and hold both keys until " EnAb " appears
(about 10 seconds).
When you release the keys " EtSt " will appear.
EnAb
Push to turn " on "
Push to turn " oFF "
oFF
Factory
Setting
oFF
Factory
Setting
oFF
Factory
Setting
oFF
Factory
Setting
oFF
Factory
Setting
oFF
Factory
Setting
on
Factory
Setting
