How will this Alarm.com Flex IO™
sensor be used?
Contact Sensor using built-in reed
switch
Wired Contact Sensor using wired
loop input
Pull-Apart Sensor using pull-apart
or Magnapull sensor
Gate control using a compatible
gate controller
For more information about use cases, see
Expand all
Equipment
In the box:
• Alarm.com Flex IO™ sensor
• Magnet
• 4x AA 1.5V lithium batteries
• Installation guide
• 300 kΩ resistor (optional)
Recommended tools and supplies (not included):
https://answers.alarm.com/Partner/Installation_and_Troubleshooting/Cellular_Sensors/Alarm.com_Flex_IO%E2%84%A2_sen...
Description
Selecting Contact Sensor allows you
to use the Flex and built-in reed
switch to monitor if something is
opened or closed.
Selecting Wired Contact Sensor
allows you to wire a contact sensor
to the Flex using the loop input
terminal.
Selecting Wired Contact Sensor
allows you to use the Flex with a
pull-apart or Magnapull sensor. This
could be used to determine if
something is moved from its
location.
Selecting Gate Control & Contact
Sensor or Gate Control & Wired
Contact allows you to use the Flex
with a compatible gate controller.
This allows you to monitor and open
the connected gate controller.
Alarm.com Flex IO™ sensor - Supported Use
Installation guide
• Using the Alarm.com Flex IO™
sensor as a contact (built-in
reed switch)
• Alarm.com Flex IO™ sensor -
Wired Contact (Loop Input)
Installation Guide
• Alarm.com Flex IO™ sensor -
Pull-Apart Installation Guide
• Alarm.com Flex IO™ sensor -
Ghost Controls TSS1
Installation Guide
• Alarm.com Flex IO™ sensor -
LiftMaster LA400/500
Installation Guide
• Alarm.com Flex IO™ sensor -
Mighty Mule MM371W
Installation Guide
Cases.
