Item
15 1
16 3
17 1
18 1
19 3
20 1
21 1
22 1
23 5
24 1
25 1
26 2
27 1
28 1
29 1
30 1
31 1
32 1
33 1
34 2
35 1
36
37 1
38 1
UM3024 - Rev 1
Q.ty Ref.
BAT46WFILM,SOT
D2
323
FS1, FS2, FS4 NC
J5 10 pins x 2.54 mm
XGL-5050-822MEC
L2
ind_XGL_5050
L1, L4, L5 NC
ZC1818-822M
L3
XAL1510
stl90n10f7
QH
MOS_SO8_PFLAT
STL110N10F7,
QL
PowerFLAT 5x6
R2, R22, R3,
0 r 0603 100 m
R11, R25
R1 2.2 r 0603 100 m
R5 510 r 0603 100 m
R7, R8 20 k 0603 100 m
R9 200 K 0606 100 m
R10 46.4 k 0603 100 m
R12 13k30603 100 m
R13 2.49 k 0603 100 m
R14 820 0603 100 m
R16 6k65 0603 100 m
R21 1.5 k 0603 100 m
R17, R18 NC
R19 18K 0603 100 m
R20 20 K 0603 100 m
R15 2.2 1206 500 m
L3751PUR, QFN
U1 3.5X4.5X1.0 20L
PITCH 0.50
Part/value Description
100 V, 150 mA
SMD general
purpose signal
Schottky diode
Not mounted
Strip
Power coil
Not mounted
High-power coil
N-channel 100
V, 0.007 Ohm
typ., 70 A
STripFET F7
power MOSFET
in a PowerFLAT
5x6 package
N-channel 100
V, 5 mOhm typ.,
107 A STripFET
F7 power
MOSFET in a
PowerFLAT 5x6
package
SMD resistors
SMD resistor
SMD resistor
SMD resistors
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
SMD resistor
Not mounted
SMD resistor
SMD resistor
SMD resistor
6 to 75 V wide
input voltage
synchronous
buck controller
Bill of materials
Manufacturer Order code
ST BAT46WFILM
- -
TE connectivity 1872200
Coilcraft XGL-5050-822MEC
- -
Coilcraft ZC1818-822M
ST STL90N10F7
ST STL110N10F7
YAGEO RC0603JR-070RL
Vishay CRCW06032R20FKTA
Bourns CRT0603FY5100ELF
Bourns CRT0603FY2002ELF
Bourns CR0603-FX-2003ELF
Bourns CR0603FX-4642ELF
TE connectivity CPF0603F13K3C1
Bourns CR0603-FX-2491ELF
Vishay RCWE0603R820FKEA
Vishay CRCW0603-6.65K-E3
TE connectivity CPF0603F1K5C1
- -
Bourns CR0603-FX-1802EL
Bourns CR0603-FX-2002ELF
Bourns CRM1206FX2R20ELF
ST L3751PUR
UM3024
