STM32W108 SimpleMAC demonstration applications
4.4.6

Button description

Table 22.
S1
S2, if available
S3, if available
S4, if available
S5, if available
4.4.7

Usage

The mouse demo is based on the detection of the MEMS axis accelerations that are
translated to mouse movement and sent to the receiver attached to the PC. Flash one of the
supported boards with the tx image and Flash another board with the rx image. Connect the
mouse receiver to the PC and to use the mouse transmitter as a mouse for your PC. Tilt the
mouse transmitter in a direction and the speed of the mouse is proportional to the tilt angle.
●
Tilting towards the ground moves the mouse down
●
Tilting towards the ceiling moves the mouse up
●
Tilting left moves the mouse left
●
Tilting right moves the mouse right
The mouse demonstration puts the device in deep sleep after 10 seconds of inactivity. To
wake the mouse up, push any button.
4.5

SimpleMAC OTA bootloader demonstration application

The SimpleMAC OTA bootloader demonstration application is a simple program that
demonstrates the Over the Air (OTA) ST bootloader protocol (see AN3262).
34/54
Button description
Button name
Doc ID 16995 Rev 10
STM32W108xB_TX
Left click, Wakeup
Left click, Wakeup
Right click, Wakeup
Right click, Wakeup
Wakeup
UM0893
STM32W108xB_RX
Not used
Not used
Not used
Not used
Not used
