UG-1962
VDD_DRVR
C5 C6
10µF 0.1µF
50V 50V
J4
PULSE
VDET
VDET
GND
J3 J2
VG1 SENSE
J1
VDD
+ +
C11
3300µF
U1
MIC5021YN
1 8
VDD VBOOST
2 7
INPUT GATE
NC 3 6
CT SENSE–
4 5
GND SENSE+
MBRB2535CTLT4G
VDETBIAS
VDET_BIAS
1 2
3 4 PULSED_VDD
5 6
7 8
9 10
11 12
13 14 VG1
15 16
17 18
19 20
21 22
VREF
23 24
P1 P1
GND
Figure 4. Analog Devices, Inc., Pulser Board Schematic
C3
C10
180pF
100µF
100V
R5 R1
0Ω
0Ω
SENSE
D
Q1
IRFZ48NSTRLPBF
G
S
C1
4700pF
PULSED_VDD
4
R3
D1 1kΩ
1 3
GND
1 2
3 4
5 6
7 8
9 10
11 12
13 14
15 16
17 18
19 20
21 22
23 24
P2 P2
GND
VREF
Rev. 0 | Page 8 of 14
ADPA1107-EVALZ
C2 C4 C7 C8
0.1µF 10µF 10µF 10µF
100V 100V 50V 50V
J5
GND
VG1
VREFBIAS
PULSED_VDD
5015
VREF_BIAS
GND
User Guide
C9
10µF
50V
