HEADER PINOUT

The schematic for the ADPA1107-EVALZ is shown in Figure 6.
The ADPA1107-EVALZ contains four headers, TP1, TP2, J3,
and J4. Table 1 describes the pinout of these headers.
Table 1. TP1, TP2 J3, and J4 Header Connections on the ADPA1107-EVALZ
Header Header Pin Number
TP1 Not applicable
TP2 Not applicable
J3 1, 3, 5, 7, 9, 10, 11, 12, 13, 14, 15, 17, 19, 21, 22, 23, 24
4, 16, 18
8
6
2
20
J4 1, 2, 3, 4, 5, 7, 9, 11, 12, 13, 14, 15, 16, 17, 19, 21, 23
8, 10, 22
6
18
20
24
