EVAL-AD5326DBZ User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 5. Components List for Motherboard
Qty Reference Designator
4 C1, C6, C7, C9
7 C2, C5, C8, C10, C15 to C17
2 C3, C4
1 C11
4 EXT_REF_1 to EXT_REF_4
1 J1
1 J2
3 J3, J7, J8
1 J4
1 J5
1 J6
1 J9
1 J10
1 L1
1 LK5
2 LK6, LK7
4 REF1, REF2, REF3, REF4
1 R1
2 R2, R3
11 R5 to R15
1 U2
1 U3
1 U4
1 U5
1 U6
1 U7
1 U10
2 U11, U12
1 FEC refers to Farnell electronic component distributors.
GRM refers to Murata electronic component distributors.
2
Description
6.3 V, tantalum capacitor (Case A), 10 µF, ±20%
50 V, X7R, ceramic capacitor, 0.1 µF, ±10%
10V, X5R, cepramic capacitor, 1 μF, ±10%
6.3 V, tantalum capacitor (Case A), 4.7µF, ±20%
Straight PCB mount, SMB jack, 50 Ω
Header, 2.54 mm, 2 × 8-way
Header, 2.54 mm, 2 × 5-way
Header, 2.54 mm, 1 × 6-way
Header, 2.54 mm, 1 × 8-way
3-pin terminal block
2-pin terminal block
Header, 2.54 mm, 2 × 4-way
120-way connector
Inductor, SMD, 600 Ω
6-pin (3 × 2), 0.1 inch header and shorting block
4-pin (2 × 2), 0.1 inch header and shorting block
10-pin (5 × 2), 0.1 inch header and shorting block
Resistor, surge, 1.6 Ω, 1%, 0603
SMD resistor, 100 kΩ, 1%, 0603
SMD resistor, 100 Ω, 1%, 0603
3.3 V linear regulator
32 kb I 2 C serial EEPROM
5 V reference, 8-lead MSOP
Ultralow noise XFET® voltage reference
4.096 V reference
Dual op amp
Quad op amp
Op amp
Rev. 0 | Page 13 of 14
UG-977
Stock Code/Part Number 1, 2
FEC 1190107
FEC 1759122
GRM188R61A105KA61D
FEC 1432350
FEC 1206013
FEC 2308428
FEC 9689583
FEC 9689508
FEC 1766172
FEC 1667472
FEC 151789
FEC 1667509
FEC 1324660
FEC 9526862
FEC 148-535 and 150-411 (36-pin strip)
FEC 148-535 and 150-411 (36-pin strip)
FEC 1022227 and 150-411
FEC 1627674
FEC 9330402
FEC 9330364
Analog Devices ADP121-AUJZ33R7
FEC 1331330
Analog Devices ADR445ARMZ
Analog Devices ADR431BRZ
Analog Devices REF198ESZ
Analog Devices AD8616ARZ
Analog Devices AD8608ARMZ
Analog Devices AD8655ARMZ
